Mostec M3020R Manuel utilisateur

Operating Manual

pH/mV-Controller

Type M3020R

M3020R Operating Manual

Warranty

Mostec warrants this product to be free of manufacturing defects for a 2-year period after

the original date of purchase. Within this period, defective products will be repaired free

of charge provided that the defect occurred during normal operation. This warranty does

not cover damage to the product resulting from ordinary usage such as front panel

scratches, broken control elements and corrosion, etc. The customer is responsible for

shipping and packing charges for products returned under warranty to Mostec. Mostec

warrants this product beyond the 2-year warranty period for an additional 2 years in case

of long term damages due to improper manufacturing. Such damages as poorly soldered

joints or other assembly problems are also covered by the warranty. Transportation

damages are not covered by the warranty and should be referred to the respective

delivery service.

M3020R Operating Manual

Index: Page

A. Front Elements And Keyboard..................................................................................................

B. Setup Menu...............................................................................................................................5

C. Customer Menu........................................................................................................................6

Measurement settings...........................................................................................................6

Controller settings..................................................................................................................6

Relay 3+4 settings.................................................................................................................6

Alarm settings........................................................................................................................6

USB settings..........................................................................................................................6

Device settings......................................................................................................................6

D. Measurement settings ..............................................................................................................7

Calibrate sensor.....................................................................................................................7

Sensor ty e............................................................................................................................7

Measure mode.......................................................................................................................7

In ut range.............................................................................................................................7

Out ut range..........................................................................................................................7

Tem erature mode.................................................................................................................7

Digital filter.............................................................................................................................7

E. Controller Settings.....................................................................................................................8

F. Relay Settings............................................................................................................................9

G. Alarm Settings.........................................................................................................................10

H. USB settings............................................................................................................................11

Clock setu ..........................................................................................................................11

Date setu ............................................................................................................................11

USB log eriod.....................................................................................................................11

Remove thumb drive............................................................................................................11

USB characteristics..............................................................................................................11

I. Device settings.........................................................................................................................12

Keyboard lock/unlock..........................................................................................................12

Language setting.................................................................................................................12

Custom label........................................................................................................................12

Factory setting.....................................................................................................................12

Device info...........................................................................................................................12

J. Calibrate The pH Sensor.........................................................................................................13

K. Operating Mode Of The Limits................................................................................................1

L. Typical Application...................................................................................................................1

M. Controller with two different set points [W] ............................................................................15

N. Controller with two identical set points, inactive zone = 10% p-band [W] .............................15

O. Controller mode – Adapting the controller to a titration curve ...............................................16

P. Factory settings ......................................................................................................................17

Q. Mechanical Dimensions..........................................................................................................18

Side view:............................................................................................................................18

Rear view:............................................................................................................................19

R. Technical Data........................................................................................................................20

M3020R Operating Manual

A. Front Elements And Keyboard

This listing only refers to the main screen, which shows up 3 seconds after power on.

Nr. element function page

a. LED1 error for Pt 100, limit contacts, 1Wire, USB and 

b. LED2 no function

c. LED3 limit contact 1..........................................................6,8,1

d. LED limit contact 2..........................................................6,8,1

F1 / F2 no function on home screen

F3 access to calibration menu pH7 and mV/pH............6,13

F relay operation manual/auto......................................1

ENT setup menu, enter.......................................................5

ESC main menu, exit...........................................................6

+ increase values......................................................5 to 1

- decrease values.....................................................5 to 1

M3020R Operating Manual

B. Setup Menu

Basically, all settings can be made in the user friendly customer menu. To change certain

parameters during the process, you can change them in the home screen using the key E T. If

an alarm message is displayed on the main screen, it first has to be acknowledged to enable

further parameter change. Adjusting the limit contact for the alarm relay in the setup menu is

only possible if in the "Alarm SP1 enable" is set in the user menu. Same for "Alarm SP2

enable."

The setup menu may be quitt by pressing the (ESC)-key, or, waiting a few seconds with no key

operation. Values can be altered with the (+) and (-)-key, or, depending on the menu, with the

(F3)-key as well.

access to the

menu item

menu item change values

press E T 1x Xt on 1 0.00...20.00s

press E T 2x Xt off 1 0.00...20.00s

press E T 3x Xp 1 pband 0.01...7.00pH or 1...1000mV

press E T x W1 set point 0.01...1 .00pH or -1000...1000mV

press E T 5x Xt on 2 0.00...20.00s

press E T 6x Xt off 2 0.00...20.00s

press E T 7x Xp 2 pband 0.01...7.00pH or 1...1000mV

press E T 8x W2 set point 0.01...1 .00pH or -1000...1000mV

press E T 9x set temperature to manual/Pt-100 F3 sets from Pt100 to manual, keys

+ and – sets the temperature to

+/- 0.1°C.

press E T 10x USB on/off Turn on and eject the USB data

logger.

press E T 11x Alarm 1 0.00...1 .00pH or -1000...1000mV

press E T 12x Alarm 2 0.00...1 .00pH or -1000...1000mV

M3020R Operating Manual

C. Customer Menu

Access to menu: press and hold E T for 3 seconds

Navigation in the menu: keys + and -

Access to a menu item: key E T = ENTER

Exit a menu item: key ESC = ESCAPE

Adjust values: keys + and -

menu item sub menu item function/comment

1/6

Measurement settings

Calibrate sensor

Sensor type

Measure mode

Input range

Output range

Temperature mode

Digital filter

See section D

2/6

Controller settings

Rel1/2: Xt on

Rel1/2: Xt aus

Rel1/2: X pband

Rel1/2: W set point

Rel1/2: acid/base

Rel1/2: norm/inv

Rel1/2: LED norm/inv

Rel1/2: min. valve time

Rel 1-2: label

See section E

3/6

Relay 3+4 settings

Rel 3/ : behavior

Rel 3/ : set point

Rel 3/ : norm/inv?

Rel 3/ : LED norm/inv?

Rel 3/ : turn on delay

Rel 3/ : turn off delay

Rel 3- : hysteresis

Rel 3- : reference

See section F

Alarm settings

Alarm SP1/2: on/off?

Alarm SP1/2: value

Alarm SP1/2: behavior

Alarm SP1/2:delay

Alarm Rel: norm/inv?

SP1-SP2: hysteresis

Pump monitoring

See section G

5/6

USB settings

Time setup

Date setup

Data log period

Remove thumb drive

See section H

6/6

Device settings

Keyboard lock/unlock

Language settings

Custom label

Factory setting

Device info

See section I

M3020R Operating Manual

D. Measurement settings

1) Press and hold ESC 3 seconds to enter the customer menu.

2) Go to menu item 1/6, ''Measurement settings'' with +.

3) Open menu item with E T

) Menu structure:

menu item change values function/comment

1/7

Calibrate sensor

See section J

2/7

Sensor type

Switch with + and - between

the three sensors and confirm

the selection with E T

Standard sensor types are

pH-sensor direct and ISM 1-

Wire sensor

2-Wire ...20mA input is

optional hardware

pH sensor direct:

via pH plug

4…20mA input:

mA equal -1000mV

20mA equal 1000mV

ISM 1-Wire Sensor digital input

Supported ISM InPro Sensor-

types:

- InPro 3250i

- InPro 3253i

- InPro 260i

- InPro 800i

- ...

3/7

Measure mode

Select with + between pH and

mV, confirm it with E T

The actual value, pH or mV, will

be displayed on the main screen

Input range

Change with + and - between

input range 0.00...1 .00pH or

-1000...1000mV , skip to next

parameter or confirm the

selection with E T

Set the input range which

corresponds to the selected signal

current output

5/7

Output range

Change with + and - between

output range 0.00...20.00mA ,

skip to next parameter or

confirm the selection with

E T

Sets the signal current output

range, which corresponds to the

input range

6/7

Temperature mode

Switch with F3 between Hand

and PT100 mode

If Hand mode is selected

change with + and – between

0.0...120.0°C, confirm the

selection with E T

Sets measure mode for

temperature compensation

7/7

Digital filter

Change with + and – between

0...100 digit

1 digit = 1mV or 0.01pH,

confirm the selection with

E T

Sets stabilization for measured

value

M3020R Operating Manual

E. Controller Settings

1) Press and hold ESC 3 seconds to enter the customer menu.

2) Go to menu item 2/6, ''Controller settings'' with +.

3) Open menu item with E T

) Menu structure:

Menu Item Change Values

1/17

Relay 1: "Xt" on

Turned on time relay 1 (mid of P-band)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

2/17

Relay 1: "Xt" off

Turned off time relay 1 (mid of P-band)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

3/17

Relay 1: "Xp"-band

P-band relay 1

Change the value with + and - , resolution is +/-

0.01pH.

/17

Relay 1: "W", set point

Set point relay 1

Change the value with + and - , resolution is +/-

0.01pH.

5/17

Relay 1: Acid/base

Acid or base type relay 1

Change the value with + to control upward (Base) or

to control downward (Acid), confirm the selection

with E T.

6/17

Relay 1: normal/inverted

Switch with + between normally open or normally

closed contact, confirm the selection with E T.

7/17

Relay 1: LED normal/inverted

Switch with + between normal or inverted indication,

confirm the selection with E T.

8/17

Relay 1: min. valve time

Minimal turned on time relay 1 (for slow valve)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

Should be 0.00s

9/17

Relay 2: "Xt" on

Turned on time relay 1 (mid of P-band)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

10/17

Relay 2: "Xt" off

Turned off time relay 1 (mid of P-band)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

11/17

Relay 2: "Xp"-band

P-Band relay 2

Change the value with + and - , resolution is +/-

0.01pH.

12/17

Relay 3: "W", set point

Set point relay 2

Change the value with + and - , resolution is +/-

0.01pH.

13/17

Rel 2: Acid/base

Acid or base type relay 2

Change the value with + to control upward (Base) or

to control downward (Acid), confirm the selection

with E T.

1 /17

Relay 2: normal/inverted

Switch with + between normally open or normally

closed contact, confirm the selection with E T.

15/17

Relay 2: LED normal/inverted

Switch with + between normal or inverted indication,

confirm the selection with E T.

16/17

Relay 2: min. valve time

Minimal turned on time relay 2 (for slow valve)

Change values with + and – to change in

+/- 0.01s steps, confirm the selection with E T.

Should be 0.00s

17/17

Relay 1-2 label

Shows a custom label for the relay 1 and 2

Change characters with + and -, switch position with

F3 and F4, confirm label with E T.

M3020R Operating Manual

F. Relay 3+4 Settings (optional relays)

1) Press and hold ESC 3 seconds to enter the customer menu.

2) Go to menu item 3/6, ''Relay 3+ settings'' with +.

3) Open menu item with E T

) Menu structure:

menu item change values

1/1 Relay 3 behavior Switch with + between upper and lower

limit, confirm the selection with E T

2/1 Relay 3 set point Change values with + and - ,

Resolution is +/- 1mV or 0.01pH

3/1 Relay 3 norm/inv? Switch with + between normal and

inverted operation, confirm the

selection with E T

/1 Relay 3 LED norm/inv? Switch with + between normal and

inverse operation, confirm the

selection with E T

5/1 Relay 3 turn on delay Change the time delay with + and -,

resolution is +/-1s

6/1 Relay 3 turn off delay Change the time delay with + and -,

resolution is +/-1s

7/1 Relay 4 behavior Switch with + between upper and lower

limit, confirm the selection with E T

8/1 Relay 4 set point Change the value with + and - , re-

solution is +/-1mV or 0.01pH

9/1 Relay 4 norm/inv? Switch with + between normally open

or normally closed contact, confirm the

selection with E T

10/1 Relay 4 LED norm/inv? Switch with + between normally open

or normally closed contact, confirm the

selection with E T

11/1 Relay 4 turn on delay Change the time delay with + and –,

resolution is +/-1s

12/1 Relay 4 turn off delay Change the time delay with + and –,

resolution is +/-1s

13/1 Relay 3-4 hysteresis Change the hysteresis of both set

points with + and –, resolution in range

from 5 to 200 is +/- 1mV or 0.01pH

1 /1 Relay 3-4 reference Switch with + between PT100 and

pH/mV as reference for relay 3+ ,

confirm the selection with E T

M3020R Operating Manual

G. Alarm Settings

1) Press and hold ESC 3 seconds to enter the customer menu.

2) Go to menu item /6 "Alarm settings" with +.

3) Open menu item with E T

) Menu structure

menu item change values

1/11 Alarm SP1 enable Switch with + between enable and disable,

confirm the selection with E T

2/11 Alarm SP1 value Change the value with + and - , the resolu-

tion is +/-1mV

3/11 Alarm SP1 behavior Switch with + between functions "lower limit"

and "upper limit", confirm the selection with

E T

upper limit Alarm relay is activated

when the measured value is

greater than the nominal

value

lower limit Alarm relay is activated

when the measured value is

smaller than the nominal

value

/11 Alarm SP1 delay Change the time delay with + and - , reso-

lution is +/-1s

5/11 Alarm SP2 enable Switch with + between enable and disable,

confirm the selection with E T

6/11 Alarm SP2 value Change the value with + and - , resolution is

+/-1mV

7/11 Alarm SP1 behavior Switch with + between functions "lower limit"

and "upper limit", confirm the selection with

E T

upper limit Alarm relay is activated

when the measured value is

greater than the nominal

value

lower limit Alarm relay is activated

when the measured value is

smaller than the nominal

value

8/11 Alarm SP2 delay Change the time delay with + and - , reso-

lution is +/-1s

9/11 Alarm Rel norm/inv? Switch with + between normal and inverse

operation, confirm the selection with E T

10/11 SP1-SP2 hysteresis Change the hysteresis of both set points

with + and –, resolution in range from 5 to

200 is +/- 1mV or 0.01pH.

11/11 Pump monitoring Change the value with + and - , to set the

maximum pump run time to alarm (from 0s

to 10800s, whereat 0s means “off”)

Note:

An alarm message can be acknowledged by pressing E T on main screen.

Table des matières

Autres manuels Mostec Contrôleurs

Mostec

Mostec M2120 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
