Health Fryer

Please read and keep these instructions for future use

GUARANTEE

YEAR

* Register online for your 2 year guarantee. See the back of this instruction book for details (UK and Ireland customers only).

www.facebook.com/morphyrichardsuk

@loveyourmorphy

www.morphyrichards.co.uk/blog

For competitions, product hints and tips

and more join us at

Download the Morphy Richards Cook & Create app for recipe ideas

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 1

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

•This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and if

they understand the hazards involved.

•Keep the appliance and its cord out of the reach of children aged less

than 8 years.

•This appliance is intended to be used in household and similar

applications such as: farm houses, by clients in hotels, motels and

other residential type environments, bed and breakfast type

environments. It is not suitable for use in staff kitchen areas in shops,

offices and other working environments.

•If the supply cable is damaged, it must be replaced with a special

cable assembly available from the manufacturer or its service agent in

order to avoid a hazard.

•For care and cleaning refer to page 10.

•This appliance is not intended to be operated by means of an external

timer or separate remote control system.

Health And Safety

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 2

In addition, we offer the following safety advice.

ocation

•Place the appliance on a horizontal, flat and

stable heat resistant surface, away from a heating

source and where it cannot be splashed by water.

•Allow adequate air space above and on all sides

for air circulation.

•Do not use outdoors or near water.

Mains cable

•The mains cable should reach from the socket to

the base unit without straining the connections.

•Do not let the cable hang over the edge of the

table or the counter and keep it away from any

hot surface.

•Do not let the cable run across an open space

e.g. between a lower socket and table.

Personal safety

•WARNING: Never attempt to move your Health

Fryer until it is completely cool. This can take up

to three hours.

•Be careful not to touch those surfaces of the

Health Fryer which become hot when in use.

•WARNING: To protect against the risk of electric

shock, do not immerse the control unit in water

or other liquid.

•Unplug from the electrical outlet when not in use

and before cleaning. Allow to cool before putting

on or taking off parts, and before cleaning the

appliance.

•WARNING: Misuse can cause personal injury.

•Never leave the Health Fryer unattended when

connected to the electricity supply.

•Never lean over the Health Fryer when it is in use.

Other safety considerations

•The use of attachments or tools not

recommended or sold by Morphy Richards may

cause fire, electric shock or injury.

•Do not operate any appliance with a damaged

cord or plug or after the appliance malfunctions

or has been damaged in any manner.

•Do not use the Health Fryer for anything other

than its intended purpose.

Electrical requirements

Check that the voltage on the rating plate of your

appliance corresponds with your house electricity

supply which must be A.C. (Alternating Current).

If the socket outlets in your home are not suitable

for the plug supplied with this appliance, the plug

should be removed and the appropriate one

fitted.

WARNING : The plug removed from the mains

lead, if severed, must be destroyed, as a plug

with a bared flexible cord is hazardous if engaged

into a live socket outlet.

Should the fuse in the 13 amp plug require

changing, a 13 amp BS1362 fuse must be fitted.

WARNING: This appliance must be earthed.

Health And Safety (Continued)

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 3

Health And Safety ......................................................... 2

Introduction .................................................................. 4

Product Overview ........................................................ 5

Touch Control Panel .................................................... 6

Before First Use ........................................................... 7

Using your Health Fryer Manually ............................... 7

Using your Health Fryer Pre-set Programs ................ 9

Hints And Tips ............................................................. 10

Care And Cleaning ....................................................... 10

Cooking Guide ............................................................. 11

Troubleshooting ........................................................... 12

Recipes ......................................................................... 14

Guarantee ..................................................................... 32

Contents

Thank you for your recent purchase of this

Morphy Richards Health Fryer.

Please read the instructions thoroughly before use.

Remember to visit www.morphyrichards.co.uk to register your

product’s two year guarantee.

Introduction

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 4

REVERSE

ADDITIONAL ACCESSORIES

Features

(1) LED Display

(2) Touch Control Panel

(3) Main Body

(4) Drawer

(5) Basket Release Button Cover

(6) Basket Release Button

(7) Frying Basket or Frying Pan Handle

(8) Mains Power Cord Socket

(9) Air outlet and filter

(10) Frying basket

(11) Frying pan (certain models only)

(12) Cake tin (certain models only)

Product Overview

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 5

Touch Sensitive Control Buttons

(A) Increase Temperature Button (5°C)

(B) Decrease Temperature Button (5°C)

(D) Decrease Time Button

Touch Control Panel

HG22E

13 16 17 18 191514

Touch Control Panel Icons

(13) Delay Timer Icon. When displayed, you can adjust the timer using (C) & (D).

(14) Cooking Time Icon. When displayed, you can adjust the cooking time using (C) & (D).

(15) Program Icon. When displayed, you may select your desired program.

(16) Temperature adjust Icon. When displayed, you can adjust the temperature using (A) & (B).

(17) Temperature Read-out. Displays the current selected temperature and the actual

temperature (when 19 is flashing).

(18) Time Read-out. Displays the current selected time.

(19) Heating Icon. When displayed, the Health Fryer is in operation. When flashing, the

temperature is increasing to the set temperature.

(20) Temperature Icon. Highlights the temperature-adjust area of the panel.

(21) Time Icon. Highlights the time-adjust area of the panel.

(22) Fan Icon. When displayed, the fan motor is in operation.

(E) On / Stop Button

(F) Start / Pause Button

(G) Pre-program Function Button

(H) Delay Timer Function Button

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 6

Using Your Health Fryer Manually

Place the Frying Basket (10) or Frying Pan (11)

into the Drawer and re-insert the Drawer into the

Main Body (3) until it clicks into place. Ensure

the Drawer is fully closed. A safety switch will

prevent it working if not closed properly.

If using the cake tin, place inside the Frying

Basket.

Remove the Drawer (4) from the Main Body (3).

Pull the Drawer fully out from the Health Fryer.

Ensuring the lead is inserted into the back of

the Main Body (3), plug the Health Fryer into

the mains.

1Remove all packaging materials.

2Remove all stickers and labels from the appliance

(excluding the rating label).

3Clean all parts to remove any dust or

manufacturing residues.

4Thoroughly wash all parts by hand with hot water,

washing-up liquid and a non-abrasive sponge.

•PLEASE NOTE: All parts are NOT dishwasher

safe.

5Wipe the inside and outside of the appliance with

a moist cloth.

6Dry all parts of your Health Fryer thoroughly.

When replacing the Drawer, ensure it is aligned

correctly.

7Use the appliance on a horizontal, flat and stable

heat resistant surface, away from a heating

source and where it cannot be splashed by water.

Before First Use

Remove the Frying Basket (10) from the Main

Drawer (4) by lifting the Basket Release Button

Cover (5) and pressing the Basket Release

Button (6). Use the Frying Basket Handle or

Frying Pan Handle (7) to pull the basket fully

out from the Drawer.

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 7

Using Your Health Fryer Manually (Continued)

Press the Program Button

(G)

and select

program 1 within the pre-programmed

settings. This will activate the pre-heat

function. When the pre-heat is complete, it will

automatically switch off the Health Fryer.

Remove the Drawer from the Health Fryer

(see Step 1).

Place the food into

the Frying Basket (10),

Frying Pan (11) or Cake Tin (12) and repeat Step

3. Do not put oil or food into the Drawer (4).

Repeat step 5 to switch back on. Using the

Temperature Adjust Buttons

(A & B)

, select the

correct temperature for the food to be cooked.

The temperature will be set at 180°C, and the

time at 10 minutes as an automatic default.

Using the Time Adjust Buttons

(C & D)

, select

the desired time for the food to be cooked.

Press the Start / Pause Button

(F)

and the

Health Fryer will begin cooking your food.

When the time is up on the timer, the Health Fryer will beep and automatically turn off.

If the food is not cooked to your desired requirements, repeat Steps 7-10.

Tip: Check your food at two minute intervals to ensure food is not overcooked.

Either remove the entire basket (see Step 2), or carefully use plastic or wooden utensils to remove

your food.

Press and hold the On / Stop Button

(E)

until

the Touch Control Panel

(2)

illuminates.

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 8

Using Your Health Fryer’s Pre-set Programs

Press the Start / Pause Button

(E)

and the

Health Fryer will begin cooking your food.

Repeat Steps 1-7 of ‘Using Your Health Fryer

Manually’ on pages 7 & 8).

Press the Program Button

(G)

until you reach

the desired program.

When the time is up on the timer, the Health

Fryer will beep and automatically turn off.

If the food is not cooked to your desired

requirements, repeat Steps 7-10 of ‘Using

Your Health Fryer Manually’ on page 7.

Tip: Check your food at two minute intervals

to ensure food is not overcooked.

Either remove the entire basket (see Step2,

page 7), or carefully use plastic or wooden

utensils to remove your food.

•This function is activated by selecting Preset 1

(see ‘Using Your Health Fryer’ on pages 7 and 9).

•For most manual and Preset cooking options, use

this Pre-heat function to ensure the Cooking

Drawer is pre-heated. Failure to do this could

result in the food being undercooked.

•The Pre-heat lasts for 3 minutes (see ‘Cooking

Guide’ on page 11).

•This function is activated by selecting Preset 8

(see ‘Cooking Guide’ on page 11 for examples of

suitable foods to be defrosted).

•The Preset 8 is for 5 minutes, this can be

increased as required (see ‘Using Your Health

Fryer’s Pre-set Programs’ above).

•Ensure the food is fully defrosted as required

before use.

•NOTE: The food will continue to defrost due to

residual heat, so check 5-8 minutes after

removing from the Drawer / Frying Basket.

Pre-heat Function Defrost Function

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 9

•Take into account the food to be cooked before

you select your frying temperature. As a general

guide pre-cooked food needs a higher cooking

temperature than raw food.

•Cook your food thoroughly. Remember that your

food may begin to turn golden brown before it is

cooked through.

•Select your cooking utensils with care. Do not

use utensils that may melt. Do not use metal

utensils as they may damage the pan coatings.

•Your Health Fryer has a maximum capacity for

food. This is dependant on food type (see the

‘Cooking guide’ for more information). As a guide

do not fill the basket more than half full.

•Smaller ingredients usually require a shorter

frying time than larger ingredients.

•A larger amount of ingredients requires only a

slightly longer frying time, a smaller amount of

ingredients requires only a slightly shorter frying

time.

•Do not leave the Drawer out for too long. The

temperature will drop.

•The optimal amount for preparing crispy fries is

500 grams.

•Use pre-made dough to prepare filled snacks

quickly and easily. Pre-made dough also requires

a shorter frying time than home-made dough.

•You can also use the Health Fryer to reheat

ingredients. To do this, set the temperature to

150°C for up to 10 minutes. Check that food is

hot before eating.

1Clean the appliance after each use, but remove

the mains plug from the wall and allow the

appliance to cool down - removing the Drawer (4)

from the Health Fryer allows it to cool down

quicker.

2Wipe the outside of the appliance with a moist

cloth.

3Remove the Drawer

(4)

Frying Basket (10), Frying

Pan (11) or Cake Tin (12) a

nd wash them by hand

in hot soapy water, using a non-abrasive sponge.

•If any stubborn dirt is stuck to the Drawer

(4)

Frying Basket (10), Frying Pan (11), half

fill the

Drawer with hot soapy water. Place the

Frying

Basket (10), Frying Pan (11)

in the Drawer and let

them soak for approximately 10 minutes. Do not

place inside the main unit.

•The Drawer

(4)

Frying Basket (10), Frying Pan (11)

and Cake Tin (12)

have a coating. Do not use

metal kitchen utensils or abrasive cleaning

materials to clean them, as this may damage the

coating.

4Clean the inside of the appliance with a moist

cloth.

5Dry all parts of your Health Fryer thoroughly and

replace the Drawer

(4)

Frying Basket (10)

. When

replacing the Drawer, ensure it is aligned

correctly.

6Remove the power cord and store it with your

Health Fryer.

Hints And Tips Care and cleaning

DF480001 MUK Re 1.qxp_Layout 1 12/04/2016 14:16 Page 10

Table des matières

Autres manuels Morphy Richards Friteuse

Morphy Richards

Morphy Richards DF45079 Manuel utilisateur

Morphy Richards

Morphy Richards Compact Fryer Manuel utilisateur

Morphy Richards

Morphy Richards IB45065 Manuel utilisateur

Morphy Richards

Morphy Richards 3-in-1 basket fryer Manuel utilisateur

Morphy Richards

Morphy Richards IB45460 Manuel utilisateur

Morphy Richards

Morphy Richards IB45410 Manuel utilisateur

Morphy Richards

Morphy Richards DF45040 Manuel utilisateur

Morphy Richards

Morphy Richards MRAF72BK Manuel utilisateur

Morphy Richards

Morphy Richards 45078 PROFESSIONAL STEEL FRYER Manuel utilisateur

Morphy Richards

Morphy Richards IBFRYDAY Manuel utilisateur

Morphy Richards

Morphy Richards Coffeemaker Manuel utilisateur

Morphy Richards

Morphy Richards 480003 Manuel utilisateur

Morphy Richards

Morphy Richards 7984 Manuel utilisateur

Morphy Richards

Morphy Richards ESSENTIALS COOLWALL FRYER Manuel utilisateur

Morphy Richards

Morphy Richards DF45070M Manuel utilisateur

Morphy Richards

Morphy Richards IB45470 Manuel utilisateur

Morphy Richards

Morphy Richards IB45061 Manuel utilisateur

Morphy Richards

Morphy Richards REMOVABLE BOWL FRYER - REV 1 Manuel utilisateur

Morphy Richards

Morphy Richards Harry Ramsden’s 45362 Manuel utilisateur

Morphy Richards

Morphy Richards bowl fryer Manuel utilisateur

Morphy Richards

Morphy Richards 45081 Manuel utilisateur

Morphy Richards

Morphy Richards 480002 Manuel utilisateur

Morphy Richards

Morphy Richards DF45075M Manuel utilisateur

Manuels Friteuse populaires d'autres marques

Innsky

Innsky 55SA1US Manuel utilisateur

Falcon

Falcon G350/11 Guide de l'utilisateur

GoWISE USA

GoWISE USA GW22612 Manuel utilisateur

Wolf

Wolf IF15/S Manuel utilisateur

Electrolux

Electrolux Thermetic 9CHG583284 Guide rapide

Gourmia

Gourmia GAF799 Manuel utilisateur

DeLonghi

DeLonghi D677UX Manuel utilisateur

SEVERIN

SEVERIN DEEP FRYER - Guide de l'utilisateur

Toastmaster

Toastmaster TMFG18-NAT Manuel utilisateur

Domo

Domo DO465FR Manuel utilisateur

Henny Penny

Henny Penny PFG-691 Manuel utilisateur

Farberware

Farberware FBW FT 43721 B Manuel utilisateur

GERMANICA

GERMANICA GEAF5L3LD Manuel utilisateur

Roller Grill

Roller Grill MF 120 R Manuel d'utilisation

Philips

Philips HD9211 Manuel utilisateur

Linea 2000

Linea 2000 Domo DO536FR Manuel utilisateur

Lakeland

Lakeland 31796 Manuel utilisateur

Dash

Dash Tasti-Crisp DFAF755 Manuel utilisateur
