Freestanding 21 litre Combi Microwave

MCM21WSC/SSC

White/Silver

Thank you for choosing this Montpellier Freestanding Combi Microwave.

Our Microwaves have been designed to provide you with the best combination of style, reliability and

performance to give you years of trouble-free use.

You may be familiar with a similar product, but please take time to read these instructions carefully before installing

or using your Microwave to ensure you get the most from your purchase.

We recommend that you keep this manual in a safe place for future reference.

Your Microwave is covered by a comprehensive two year Parts & Labour

Guarantee. In the unlikely event that you experience a problem with your

Microwave, you can rest assured that you are fully protected against the cost of

repairs for the first 24 months . Please note that any claim must be

accompanied by the model reference number, serial number and proof of

purchase.

To activate your guarantee, you will need your product serial number. This can

be found on the rear of the machine.

There are two ways to register your Guarantee:

•Online: Visit the Support page on our website and complete the online Product

Registration form. www.montpellier-appliances.com

•By Post: Simply detach and ll in the form provided, attach a stamp and send

it in the post. Don’t forget to include your e-mail address so that we can send

conrmation through to you.

Welcome

Note: We are unable to take registrations over the phone.

ACROSS ALL OUR MODELS

YEAR

GUARANTEE

PA R T S & L A B O U R

www.montpellier-appliances.com

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since this can

result in harmful exposure to microwave energy. It is important not to

break or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow

soil or cleaner residue to accumulate on sealing surfaces.

operated until it has been repaired by a competent person.

ADDENDUM

If the apparatus is not maintained in a good state of cleanliness, its surface could

be degraded and affect the lifespan of the apparatus and lead to a dangerous

situation.

Specifications

The appliances are not intended to be operated by means of an external timer or

separate remote-control system.

This appliance is intended to be used in domestic household and similar

applications only !!:

Model:

Rated Voltage:

Rated Input Power(Microwave):

Rated Output Power(Microwave):

Power of hot air convection(Grill):

Oven Capacity:

Turntable Diameter:

External Dimensions:

MCM21SSC / MCM21WSC

1300W

800W

1200W

21L

270mm

484x336x280mm

240V~/50Hz

IMPORTANT SAFETY INSTRUCTIONS

WARNINGTo reduce the risk of fire, electric shock, injury to

persons or exposure to excessive microwave oven

energy when using your appliance, follow basic

precautions, including the following:

1. Warning: Liquids and other foods must

not be heated in sealed containers since

they are liable to explode.

2. Warning: It is hazardous for anyone other

than a competent person to carry out any

service or repair operation that involves

the removal of a cover which gives prote-

ction against exposure to microwave

energy.

3. Warning: Only allow children to use the

oven without supervision when adequate

instructions have been given so that the

child is able to use the oven in a safe way and

understand the hazards of improper use.

4. Warning: When the appliance is operated

in the combination mode, children should

only use the oven under adult supervision

due to the temperatures generated.

(only for grill series)

5. Only use utensils suitable for use in

microwave ovens.

6. The oven should be cleaned regularly and

any food deposits should be removed.

7. Read and follow the specific:"PRECAU-

TIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY".

8. When heating food in plastic or paper

containers, keep an eye on the oven due

to the possibility of ignition.

9. If smoke is observed, switch off or unplug

the appliance and keep the door closed

in order to stifle any flames.

10. Do not overcook food.

11. Do not use the oven cavity for storage

purposes. Do not store items,

such as bread, cookies, etc. inside the

oven.

12. Remove wire twist-ties and metal handles

from paper or plastic containers/bags

before placing them in the oven.

13.

Install or locate this oven only in

accordance with the installation

instructions provided.

14.

Eggs in the shell and whole hard-boiled

eggs should not be heated in microwave

ovens since they may explode, even

after microwave heating has ended.

15.

Use this appliance only for its intended

uses as described in manual. Do not

use corrosive chemicals or vapors in

this appliance. This oven is especially

designed to heat. It is not designed for

industrial or laboratory use.

16.

If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid a hazard.

17.

Do not store or use this appliance

outdoors.

18. Do not use this oven near water, in a wet

basement or near a swimming pool.

19. The temperature of accessible surfaces

may be high when the appliance is

operating. Keep cord away from heated

surface, and do not cover any events on

the oven.

20. Do not let cord hang over edge of table or

counter.

21. Failure to maintain the oven in a clean

condition could lead to deterioration

of the surface that could adversely affect

the life of the appliance and possibly result

in a hazardous situation.

22. The contents of feeding bottles and

baby food jars shall be stirred or shaken and

the temperature checked before

consumption, in order to avoid burns.

23. Microwave heating of beverages can

result in delayed eruptive boiling,

therefore take care when handling the

container.

24.

The appliance is not intended for use by

persons (including children) with reduced

physical , sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their

safety. (for

market beyond European market)

25.

Children should be supervised to ensure

that they do not play with the appliance. This

appliance can be used by children aged from

8 years and above and persons

with reduced physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given

supervision or instruction concerning use of

the appliance in a safe way and understand

the hazards involved. Children shall not play

with the appliance. Cleaning and user

maintenance shall not be made by children

without supervision. (for European market.)

26. The microwave oven shall not be placed in

a cabinet.

27. The microwave oven is intended for heating

food and beverages. Drying of food or

clothing and heating of warming pads,

slippers, sponges, damp cloth and similar

may lead to risk of injury, ignition or fire. The

microwave oven is intended to be used

freestanding.

The appliance must be placed against

the wall.

Don’t immerse the appliance in water or other

liquid when cleaning.

The appliance shall not be cleaned with a

steam cleaner.

To Reduce the Risk of Injury to Persons

Grounding Installation

DANGER

Electric Shock Hazard Touching

some of the internal

components can cause serious

personal injury or death. Do not

disassemble this appliance.

WARNING

Electric Shock Hazard Improper

use of the grounding can result

in electric shock. Do not plug into

an outlet until appliance is

properly installed and grounded.

CLEANING

Be sure to disconnect the oven

from the power supply.

1. Clean the inside of the oven after

using with a slightly damp cloth.

2. Clean the accessories in the usual

way in soapy water.

3. The door frame and seal and

neighbouring parts must be cleaned

carefully with a damp cloth when they

are dirty.

1. A short power-supply cord is provided to

reduce the risks resulting from becoming

entangled in or tripping over a longer cord.

2. If a long cord set or extension cord is used:

1)The marked electrical rating of the cord set

or extension cord should be at least as great as

the electrical rating of the appliance.

2)The extension cord must be a grounding-

type 3-wire cord.

3)The long cord should be arranged so that it

will not drape over the counter top or tabletop

where it can be pulled on by children or tripped

over unintentionally.

This appliance must be grounded. In the event of

an electrical short circuit, grounding reduces the

risk of electric shock by providing an escape wire

for the electric current. This appliance is equipped

with a cord having a grounding wire with a

grounding plug. The plug must be plugged into an

outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the

grounding instructions are not completely

understood or if doubt exists as to whether the

appliance is properly grounded. If it is necessary

to use an extension cord , use only a 3-wire

extension cord.

Plug

1. Fill a microwave-safe container with 1 cup of cold

water (250ml) along with the utensil in question.

2. Cook on maximum power for 1 minute.

3. Carefully feel the utensil. If the empty utensil is

warm, do not use it for microwave cooking.

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of

meat or poultry to prevent overcooking. Arcing can occur if foil is too

close to oven walls. Thefoil should be at least 1 inch (2.5cm) away from

oven walls.

Follow manufacturer’s instructions. The bottom of browning dish must be

at least 3/16 inch (5mm) above theturntable. Incorrect usage may cause

theturntable to break.

Microwave-safe only. Follow manufacturer's instructions. Do not use

cracked or chipped dishes.

Always remove lid. Use only to heat f

ood until just warm. Most glass jars

are not heat resistant and may break.

Heat-resistant oven glassware only. Make sure there is no metallic trim.

Do not use cracked or chipped dishes.

Follow manufacturer’s instructions. Do not close with metal tie. Make

slits to allow steam to escape.

Use for short–term cooking/warming only. Do not leave oven unattended

while cooking.

Use to cover food for reheating and absorbing fat. Use with supervision

fora short-term cooking only.

Use as a cover to prevent splattering or a wrap for steaming.

Microwave-safe only. Follow the manufacturer’s instructions. Should be

labeled "Microwave Safe". Some plastic containers soften, as thefood

inside gets hot. "Boiling bags" and tightly closed plastic bags should be

slit, pierced or ventedas directed by package.

Microwave-safe only. Use to cover food during cooking to retain

moisture. Do not allow plastic wrap to touch food.

Thermometers Microwave-safe only (meat and candy thermometers).

Wax paper Use as a cover to prevent splattering and retain moisture.

Browning dish

Glass jars

Glassware

UTENSILS

CAUTION

Personal Injury Hazard

It is hazardous for anyone

other than a compentent person to

carry out any service or repair

operation that involves the removal

of a cover which gives protection

against exposure to microwave

energy.

See the instructions on "Materials you can use in

microwave oven or to be avoided in microwave oven."

There may be certain non-metallic utensils that are not

safe to use for microwaving. If in doubt, you can test the

utensil in question following the procedure below.

Utensil Test:

Oven cooking

bags

Paper plates

and cups

Paper towels

Parchment

paper

Plastic

Plastic wrap

Dinnerware

A) Control panel

B) Turntable shaft

C) Turntable ring assembly

D) Glass tray

E) Observation window

F) Door assembly

G) Safety interlock system

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray

Food carton with

metal handle

Metal or metal-

trimmed utensils

Metal twist ties

Paper bags

Plastic foam

Wood

C B

E D

SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton and oven cavity.

Your oven comes with the following accessories:

Glass tray 1

Turntable ring assembly 1

Instruction Manual 1

Metal shields the food from microwave energy. Metal trim may

cause arcing.

May cause a fire in the oven.

Plastic foam may melt or contaminate the liquid inside when exposed

to high temperature.

Wood will dry out when used in the microwave oven and may split

or crack.

May cause arcing. Transfer food into microwave-safe dish.

May cause arcing and could cause a fire in the oven.

Shut off oven power if the door is opened during operation.

Grill Rack ( Only for Grill series )

Countertop Installation

Remove all packing material and accessories.

Examine the oven for any damage such as

dents or broken door. Do not install if oven is

damaged.

Cabinet: Remove any protective film found

on the microwave oven cabinet surface. Do

not remove the light brown Mica cover that

is attached to the oven cavity to protect

the magnetron.

Installation

1. Select a level surface that provide

enough open space for the intake

and/or outlet vents.

A minimum clearance of 3.0 inches

(7.5cm) is required between the oven and any

adjacent walls. One side must be open.

(1) Leave a minimum clearance of 12

inches (30cm) above the oven.

(2) Do not remove the legs from the

bottom of the oven.

(3) Blocking the intake and/or outlet

openings can damage the oven.

(4) Place the oven as far away from

radios and TV as possible. Operation

of microwave oven may cause

interference to your radio or TV

reception.

2. Plug your oven into a standard household

outlet. Be sure the voltage and the

frequency is the same as the voltage

and the frequency on the rating label.

Turntable ring assembly

3.0 inch(7.5cm)

12 inch(30cm)

OPEN

a. Never place the

glass tray

upside down. The glass

tray should never be restricted.

b. Both

glass tray

and

turntable ring assembly

must

always be used during cooking.

All food and containers of food are always placed

on the

glass tray

for cooking.

d. If

glass tray

turntable ring assembly

cracks or

breaks, contact your nearest authorized service

center.

Turntable Installation

Hub (underside)

Glass tray

Turntable shaft

WARNING: Do not install oven over a

range cooktop or other heat-producing

appliance. If installed near or over a heat

source, the oven could be damaged and

the warranty would be void.

The accessible surface

may be hot during

operation.

1) Press " " once, the screen display "P100".

to adjust the hour figures, the input time should be within 0--23.

3) Press " Timer/ Clock ", the minute figures will flash.

3) Turn " to adjust the cooking time until the oven displays "20:00".

4) Press

to start cooking .

Operation Instructions

1. Clock Setting

When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.

1) Press " Timer/ Clock " twice, the hour figures will flash.

4) Turn " to adjust the minute figures, the input time should be within 0--59.

5) Press " Timer/ Clock " to finish clock setting. ":" will flash, and the time will light.

Note: the step quantities for the adjustment time of the coding switch are as follow:

0---1 min : 5 seconds 1---5 min : 10 seconds

5---10 min : 30 seconds 10---30 min : 1 minute

30---95 min : 5 minutes

2) Press " " once again to choose 80% microwave power.

Note: 1) If the clock is not set, it would not function when powered.

2) During the process of clock setting, if you press " ", the oven

will go back to the previous status automatically.

for times to choose

the power you want, and "P100", "P80" "P50", "P30 " or "P10" will display for each.

added

Then turn

cooking time from 0:05 to 95:00. Press

" "

again to start cooking.

Microwave

START/+30sec.

to set

2) Turn "

STOP/Cancel

START/+30sec.

turn

2. Timer

1) Press " Timer/Clock " once, and the LED will display " 0:00 ".

2) Set timer. (Consult the instruction of clock setting.)

3) Press

" "

to start the timer.

4) The buzzer will ring 5 times when the time count down.

3. Microwave Cooking

Press " Microwave" the LED will display "P100".Pres Mis crowave

START/+30sec.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels montpellier Four à micro-ondes

montpellier

montpellier MMW20W Manuel utilisateur

montpellier

montpellier MCM20WSC Manuel utilisateur

montpellier

montpellier MON-MWBI90025 Manuel utilisateur

montpellier

montpellier MON-MWBI9000 Manuel utilisateur

montpellier

montpellier MWBI72X Manuel utilisateur

montpellier

montpellier MWBI90025 Manuel utilisateur

montpellier

montpellier MON-MMW20GTW Manuel utilisateur

montpellier

montpellier MWBIC90029 Manuel utilisateur

montpellier

montpellier MWBI20BK Manuel utilisateur

montpellier

montpellier MON-MMW25STW Manuel utilisateur

montpellier

montpellier MON-MWBIC90029 Manuel utilisateur

montpellier

montpellier MMW21SIL Manuel utilisateur

montpellier

montpellier MON-MMW23SSS Manuel utilisateur

montpellier

montpellier MON-MBIC250 Manuel utilisateur

montpellier

montpellier MCM21WSC Manuel utilisateur

montpellier

montpellier MON-MMW25CTWW Manuel utilisateur

montpellier

montpellier MWBIC90044 Manuel utilisateur

montpellier

montpellier MWBI17-300 Manuel utilisateur

montpellier

montpellier MMW21W Manuel utilisateur

montpellier

montpellier MWBIC74B Manuel utilisateur

montpellier

montpellier MOR-20C Manuel utilisateur

montpellier

montpellier MON-MWBIC90044 Manuel utilisateur

montpellier

montpellier MON-MMW25CTKB Manuel utilisateur

montpellier

montpellier MON-MCG259 Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur

montpellier MCM21SSC Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques
