Montpellier MITF122 Manuel utilisateur

Integrated Freezer - In Column

MITF122 - 122cm - Slider Fixings

Please read these instructions carefully before attempting to install or use this appliance.

We recommend that you keep these instructions in a safe place for future reference.

Installation and Operating Instructions

THE PERFECT BALANCE OF FUNCTION AND STYLE

LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Integrated Freezer.

Our refrigeration products have been designed to provide you with the best combination of style, reliability and

performance to give you years of trouble-free use.

You may be familiar with a similar product, but please take time to read these instructions carefully before installing

or using your Freezer to ensure you get the most from your purchase.

We recommend that you keep this manual in a safe place for future reference.

Your Integrated Freezer is covered by a comprehensive 5Year Parts & Labour

Guarantee. In the unlikely event that you experience a problem with your

Freezer, you can rest assured that you are fully protected against the cost of

repairs for the first 5 Years. Please note that any claim must be accompanied

by the model reference number, serial number and proof of purchase.

To activate your guarantee, you will need your product serial number. This can

be found inside your appliance on the left hand wall on a small sticker.

There are two ways to register your Guarantee:

•Online: Visit the Support page on our website and complete the online Product

Registration form. www.montpellier-appliances.com

•By Post: Simply detach and ll in the form provided, attach a stamp and send

it in the post. Don’t forget to include your e-mail address so that we can send

conrmation through to you.

Welcome

Note: We are unable to take registrations over the phone.

ACROSS INTEGRATED COOLING

YEAR

GUARANTEE

PA R T S & L A B O U R

www.montpellier-appliances.com

Contents

………………………………………. 3-4

………………………………………. 4

………………………………………. 5

………………………………………. 6

………………………………………. 7

………………………………………. 8-9

………………………………………. 10-17

………………………………………. 18-20

………………………………………. 21

………………………………………. 22

………………………………………. 23

………………………………………. 24

………………………………………. 25-26

………………………………………. 27

………………………………………. 28

………………………………………. 29

Safety Instructions

Electrical Safety

Transportation & Handling

Installing & Switching on your Appliance

Before Switching On

Product Overview

Unit & Spare Parts

Usage

Temperature Selection

Installation

Door Reversal

Energy Saving Advice

Freezer Storage Advice

Power Failure

Maintenance & Cleaning

Internal Cleaning

External Cleaning

When the appliance is not in use

Defrosting

Trouble Shooting

Connection to the Mains Supply

Technical Specification

Guarantee

Safety Instructions

Important note: Please read this booklet before installing and switching on this

appliance. The manufacturer assumes no responsibility for incorrect installation

and usage as described in this booklet.

•This model uses natural refrigerant gas as part of its cooling system. This

gas is known as R600a (Isobutene) and is environmentally friendly but can be

combustible. Care should therefore be taken when handling or transporting the

product to ensure that none of the refrigeration circuit components are

damaged,

•Do not obstruct ventilation openings in the appliance

•The appliance must not be placed or rested on its power cord.

•Do not use mechanical devices or other artificial means to accelerate the

defrosting process, such as a heater or a hair dryer.

•Do not use electrical appliances in the refrigerator compartment of the

appliance.

•If this appliance is to replace an old refrigerator with a lock, the lock must be

removed as a safety measure before storing it or disposing of it. This is to

protect children from locking themselves inside the appliance.

•Old refrigerators and freezers contain insulation gases and refrigerant, they

must be disposed of properly. Contact your local authority or your dealer if

you have any questions. Please ensure that you do not damage the scrapunit

prior to being picked-up by the relevant waste disposal service.

•Do not use adaptors or extension leads when connecting the appliance to the

electrical power supply

•Do not plug in damaged plugs

•Do not pull, twist or damage the power cable.

•Do not plug-in or un-plug the appliance with wet hands to prevent electrical

shock.

•This appliance can be used by childrenaged from 8 years and above and

persons with reduced physical, sensoryor mental capabilitiesor lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children should not play with the appliance.

•This appliance is designed to be used by adults, do not allow childrento play

with the appliance or letthem hang over the door.

•Do not place explosive or flammable material in your appliance for your own

safety.

•Bottles containing a high percentage of alcohol must be sealedwell and placed

vertically in the refrigerator.

•Do not cover the body or the top of the appliance

•Fix down the accessories in the appliance during transportation to prevent

damage to them.

Electrical Safety

THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET

•Before switching on, make sure that the voltage of your electricity supply is the

same as that indicated on the rating plate. This product is designed to operate

on 220 –240V AC; 50Hz. Connection to any other power source may damage

the unit.

•This product may be fitted with a non re-wireable plug. If it is necessary to

change the fuse in the plug, the fuse cover must be refitted. If the fuse cover

becomes lost or damaged, the plug must not be used until a suitable

replacement is obtained.

•If the plug has to be changed because it is not suitable for your socket, or

becomes damaged in any way, it should be cut off and an appropriate plug

fitted following the wiring instructions. This should be carried out by a qualified

electrician. The plug removed must be disposed of safely, as insertion into a 13

Amp socket is likely to cause an electrical hazard.

Transportation and Handling

For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the

base and rear corners of cabinet. Lift the refrigerator carefully. Never use the door

handles for lifting. To move the refrigerator on a flat level surface, tilt it slightly

backwards and push backwards.

This unit is heavy and could cause injury –ensure there are adequate people

present to move the appliance.

Installing and Switching on Your Appliance

•Operating voltage for your appliance is 220-240Vat 50Hz.

•Before plugging in the power supply, ensure that the voltage on the rating label

corresponds to the working voltage of your electrical system in your home.

•Insert the plug into an efficient Ground (Earth) connection. If the socket hasno

Ground (Earth) contact or the plug does not match, we suggestyou call an authorised

electrician for assistance.

•Place your appliance in an area that is not exposed to direct sunlight.

•Your appliance should be placed at least 10cm away from stoves, ovens and other

heating cores.

•This appliance should never be used outdoors or left in the rain.

•When your appliance is placed nextto achest freezer or freezer, there should be at

least 10cms betweenthem to prevent humidityon the outer surface.

•The appliance must be used in the vertical position and on a flat surface.

•To level the appliance, use the adjustable feet at the front of the appliance.

•Do not place your appliance on a carpeted surface as this will prevent adequate

ventilation.

•Keep ventilation openings in the appliance enclosure or in the built in structure clear of

obstruction

•This appliance should only be placed on a flat, firm surface.

•It is recommended the appliance is installed by a qualified kitchen fitter or joiner.

•Choose a dry and well-ventilated space.

•The appliance should be positioned so that the plug is easily accessible.

Before Switching On

•Before using your appliance, add a teaspoon of bicarbonate of soda to warm

water and with a damp cloth wipe down all parts of the new appliance, then

repeat the process with a clean damp cloth and dry. (ensure the appliance is

not connected to the power when performing this task).

•Remove all transport tapes and foam protection pieces . Clean the interior with

a cloth dampened in lukewarm soap and water. Wipe with clean water and

wipe dry.

•There may be an odour when you first switch on the appliance, it will disappear

when the appliance starts to cool.

•When the appliance has been positioned, adjust the feet to ensure the unit is

stable. This is essential to ensure quiet running and proper door opening

/closing.

•Connect to the electrical socket but do not switch the power to the refrigerator

on for at least 3 hours. The coolant within the product needs time to settle after

it has been transported and put in to position, failure to do this will affect the

cooling performance of your appliance.

•Once the appliance has settled locate the thermostat dial on the product and

set to “5" and switch on the power. The compressor will begin to work. Close

the door.

•We recommend that the door is not opened for a minimum of 4 hours to allow

the appliance to reach the standard operating temperature.

•You may hear faint gurgling or bubbling sounds when the refrigerant is pumped

to the cooling system and through the coils or tubing at the rear of the

appliance. When the compressor is in operation you may hear a slight whirring

sound or pulsating noise. The thermostat controls the operation of the

compressor, and you may hear a slight click as it cycles in and out (this is

normal).

•To save energy, you should minimize the frequency and duration of door

opening.

Unit Parts & Spare Parts

Before installation, check that all parts detailed in the product overview are

present.

Product Overview

1. Thermostat

2. Drawers

3. Feet (adjustable feet at the front)

4. 1 x ice cube tray, 1 x ice scraper

5. Installation accessories

The temperature in the appliance is controlled by the temperature control dial

or thermostat located at top of the appliance. Rotate the control dial anti-

clockwise and clockwise to regulate the temperature inside the freezer.

1. Temperature control - on the temperature control, OFF is the off setting, 1 is

the warmest setting and 5 is the coldest setting.

2. Power indicator - the green light will illuminate when the freezer is switched

on.

3. High temperature warning indicator - the red light will illuminate when the

temperature inside the freezer is too high. This may illuminate after the

door has been opened or when fresh food is added, and should switch off

again once the temperature within the freezer has stabilised.

4. Super freeze indicator - the yellow light will illuminate when the super

freezer function has been activated with the super freeze button.

5. Super freeze button - should only be set 2 hours before a large amount of

food is placed in the freezer so the appliance will be at its coldest so it can

rapid freezer the food that is added. After 24 hours, the function will be

switched off automatically. During fast freezing, press and hold the fast

freezing button for 3 seconds, then the function will be manually switched

off immediately.

Allow to stand for a minimum of 3 hours before plugging in to the mains

Usage

1 2 3 4 5

Depending on the ambient temperature of the room the appliance is situated in,

you may need to adjust the temperature control dial; in a room with a high

ambient temperature the temperature control dial may need to be adjusted to a

colder setting (moved towards setting 5) or in a room with a low ambient

temperature the temperature control dial may need to be adjusted to a warmer

setting (moved towards setting 3).

Once the temperature control has been set, close the door and plug in the

appliance. We recommend that the door is not opened for a minimum of 4

hours to allow the appliance to reach the standard operating temperature.

Note: The standard operating temperature for the freezer compartment should

be between -18°C and -25°C.

Note: The temperature of the freshly stored food and how often the door is

opened affects the temperature in the refrigerator compartment. If

required, change the temperature setting.

Allow to stand for a minimum of 3 hours before plugging in to the mains

Usage

Table des matières

Autres manuels montpellier Congélateur

montpellier

montpellier MS183W/S Manuel utilisateur

montpellier

montpellier MS318MX/W Manuel utilisateur

montpellier

montpellier MBUF300 Manuel utilisateur

montpellier

montpellier MON-MZF48W Manuel utilisateur

montpellier

montpellier MIFF505LF Manuel utilisateur

montpellier

montpellier MICF88 Manuel utilisateur

montpellier

montpellier MITF125 Manuel utilisateur

montpellier

montpellier MON-M604DDAP Manuel utilisateur

montpellier

montpellier MZF54W/BK Manuel utilisateur

montpellier

montpellier MAB386K Manuel utilisateur

montpellier

montpellier MFD71X Manuel utilisateur

montpellier

montpellier MITF215 Manuel utilisateur

montpellier

montpellier MIFF701 Manuel utilisateur

montpellier

montpellier M537DDAP Manuel utilisateur

montpellier

montpellier WS7SDX Manuel utilisateur

montpellier

montpellier MFF170W Manuel utilisateur

montpellier

montpellier MFF145W Manuel utilisateur

montpellier

montpellier MNF167EW Manuel utilisateur

montpellier

montpellier MIFF703LF Manuel utilisateur

montpellier

montpellier MIFF7030AP Manuel utilisateur

montpellier

montpellier MLF1770EW Manuel utilisateur

montpellier

montpellier MLF1770EWWD Manuel utilisateur

montpellier

montpellier MZF48W Manuel utilisateur

montpellier

montpellier MLF1770WWD Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur

montpellier MITF122 Manuel utilisateur

Manuels Congélateur populaires d'autres marques
