P52DF with Satin Black surround* &
Opal Firestones shown on reverse
Fireplace BTU/H Input
Model# Natural Gas Liquid Propane
P38DF 25,000 25,000
P42DF 32,000 32,000
P52DF 40,000 40,000
Front View
Side View
Top View
P52DF without surround
P52DF with Stainless Steel surround*
Unit Dimensions
A B C D E F G H I J K
P38DF 37¾" 18⅛" 35¼" 6⅛" 20⅜" 29½" 26⅜" 33¾" 8" 5" 8"
P42DF 42" 19" 39½" 6¼" 21¼" 30½" 27½" 34⅝" 8" 5" 8"
P52DF 52" 20⅜" 47" 7½" 22⅞" 33¼" 28¾" 36⅛" 7¾" 5" 10"
E
F
G
H
"
J
K
I
C
B
A
D
N
1" clearance
to corners only
M
L
Framing Dimensions
Model# L M N O P Q
P38DF 55¼" 37¾" 78½" 20¼" 34¼" 41¼"
P42DF 59¾" 42" 84½" 21¼" 35" 42"
P52DF 69¼" 52" 98" 25" 37½" 43"
O
M
P
Non-combustible
header
Q
Available at: Printed in Canada
P/N XB2600 011112
Ferndale, Washington
TF 1.800.789.6236
FX 1.866.300.0927
Langley, British Columbia
TF 1.800.378.3115
FX 1.604.607.6462
®
Consult the owner’s manual for complete installation instructions and proper clearances to
combustible surfaces prior to installing fireplace.
All specifications, framing dimensions, product designs, materials and colors are subject to
change without notice. The actual flame pattern and color may vary slightly from the illustrations.
Diagrams and illustrations are not to scale.
Options & accessories may have an associated surcharge.
Warranty: The manufacturer warrants this fireplace to be free from defects in materials and
workmanship at the time of manufacture. There is a limited 10 year warranty on the firebox; 5 year
limited warranty on the burner and 1 year limited warranty on the pilot burner assembly and fan
motors (if included). The valve carries a limited 1 year warranty unless otherwise specified in the
installation manual. Glass, plated/painted finishes and refractory lining are exempt.
Features:
❏ Clean-Face design allows for brick or tile
installation over the fireplace frame
❏ Convertible using Top or Rear vent
❏ Concealed Ribbon burner comes standard with
White, Silver, Opaque Fire Stones‡
❏ Black Porcelain Panels
❏ Up-lighting to increase illuminance
❏ Fans equipped with fan speed control
❏ IPI Electronic Ignition remote control for flame
modulation, thermostatic control, & battery backup
for continuous operation during power failure
❏ Snap-Lock door system
❏ Hi/Lo control for adjusting flame level
❏ 100% fail-safe shut-off valve
* Surround sold separately.
‡ Go to www.montigo.com for colour images & other accessory options
P-Series Direct Vent ∙ Flush Face
Single Sided Fireplace
