Monster ABRA A5 V18.2 Manuel utilisateur
01
EN
A5 V18.2
USER MANUAL
KULLANIM KILAVUZU
MANUAL DE USUARIO
MANUEL DE L’UTILISATEUR
MANUALE UTENTE
BENUTZERHANDBUCH
EN
A5 V18.2
USER
MANUAL
TABLE OF CONTENT
CHAPTER 1 - Preface ...................................................... 02
1.1 Regulations Information..................................................02
FCC Information........................................................................03
RF Exposure Information(SAR).............................................04
1.2 Safety Information ............................................................05
1.3 Conventions For This Manual..........................................05
CHAPTER 2 - Getting To Know The Basics ..................... 06
2.1 Product Specifcation........................................................06
2.2 Preparing your Computer ................................................08
2.3 Product Overview...............................................................09
CHAPTER 3 - Getting Started ......................................... 14
3.1 AC Adapter...........................................................................14
3.2 Knowing The Keyboard .....................................................15
3.2.1 For Keyboard Users........................................................15
3.3 Using the touchpad / clickpad........................................17
CHAPTER 4 - Bios Setup ................................................. 18
4.1 About Bios Setup ...............................................................18
4.1.1 When To Use Bios Setup? ............................................18
4.1.2 How to Run BIOS Setup?..............................................18
4.2 BIOS Setup Menu ...............................................................18
4.2.1 Main Menu........................................................................19
4.2.2 Advanced Menu...............................................................20
4.2.3 Security Menu .................................................................20
4.2.4 Boot Menu........................................................................22
4.2.5 Exit Menu..........................................................................22
02
EN
The information in this user’s manual is protected by copyright laws, all parts of
this manual, including the products and software described in it, can not be
reproduced, transmitted, transcribed, stored in a retrieval system, nor
translated into any language.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR
OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY
CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR
USE OF THIS MANUAL.
The illustrations in this user’s manual are for reference only. Actual product
specifcations may vary with territories. The information in this user’s manual is
subject to change without notice.
CHAPTER 1
1.1 Regulations Information
NOTICE
Preface
•CE compliance
This device is classed as a technical information equipment (ITE) in class B
and is intended for use in living room and ofce. The CE-mark approves the
conformity by the EU-guidelines:
- EMC Directive 2014/30/EU,
- Low Voltage Directive 2014/35/EU(equals A2 : 2013),
- RF Directive 2014/53/EU
Rechargeable Battery Notice Do not
1. Throw into fire or a hot oven, or mechanically crush or cutting of a
BATTERY
2. Throw or immerse into water
3. Heat to more than 60°C
4. Repaire or disassemble
5. Leave in an extremely low air pressure environment
6. Leave in an extremely high-temperature environment A power cord
is connected to a socket-outlet with earthing connection.
03
EN
The unit can be operated at an ambient temperature of max. 35°C (95°F).
Do not subject it to temperatures below 5°C (41°F) or above 40°C (104 °F).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
PREVENTION OF HEARING LOSS
CAUTION: Listening to music at high volume levels and for extended durations
can damage one’s hearing. In order to reduce the risk of damage to hearing,
one should lower the volume to a safe, comfortable level, and reduce the
amount of time listening at high levels. Headsets should comply with EN
50332-2 requirements.
FCC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
Any changes or modifications not expressly approved
by the grantee of this device could void the user’s
authority to operate the equipment.
CAUTION:
04
EN
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to
radio waves. This device is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6
W/kg. Tests for SAR are conducted using standard operating positions
accepted by the FCC with the EUT transmitting at the specified power
level in different channels.
The FCC has granted an Equipment Authorization for this device with
all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this device is on file with the
FCC and can be found under the Display Grant section of www.fcc.gov/
eot/ea/fccid after searching on FCC ID: 2AKHFAX201NG .
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved
by the grantee of this device could void the user’s
authority to operate the equipment.
CAUTION:
05
EN
1.2 Safety Information
Do not apply heavy pressure to the computer or
subject it to any form of strong impact as this can
damage the computer’s components or otherwise
cause it to malfunction.
1
Never cover or block the air vents including those
located at the base of the computer. Never cover
your computer or AC adaptor with any object.
2
Do NOT expose to or use near liquid, rain, or
moisture.
Do NOT use the modem during electrical storms.
4
Do not use or expose this device around
magnetic felds as magnetic interference may
affect the performance of the device.
5
To keep your computer in prime operating
condition, protect your work area from direct
sunlight.
3
1.3 Conventions For This Manual
This message contains important information
that must be followed for safe operation.
CAUTION:
NOTE: This message contains information for special situations.
06
EN
2.1 Product Specifcation
CHAPTER 2
Getting To Know The Basics
This User’s Manual provides technical information of instructions and illustra-
tions on how to operate this notebook for the customer. Please read this manu-
al carefully before using this notebook.
Physical Characteristic
Processor-CPU
Graphic Card-GPU
Memory
I/O Port
Display
360.2x243.5x19.9mm(panel=2.6mm)
2kg +/- 5%
11. Generation i7-11800H
4 GB RTX 3050
DDR4 3200MHz
15.6’’ FHD 1920x1080 16:9 144Hz
x1
x2 USB 3.1 (Gen1)
x1 USB 3.1 Tip C (Gen2)+DP
x1 USB 2.0
x1
x1
x1
x1
x1 SD/SDHC/SDXC, UHS-50hz
Dimension
Weight
Support Processor
Graphic Card
RAM
LCD
DC-In
USB
RJ45
HDMI 2.1
Audio Out
Microphone In
Card Reader
07
EN
MODEL IS DESIGNED TO USE WITH THE
DC INPUT: 150 Watts (19V/7.89A)
CAUTION:
Input
Communication Port
Power
Webcam
Audio
Audio Codec Realtek ALC274CG *Azalia standard
support *D3 mode support *AMP support
*Build-in 2 speakers, Speaker: 2W/each
Digital Microphone Support
Memrane single zone RGB backlight support
340x109.2x3.6mm *US/UK plate
*TDA1470 (114.5x70x0.8mm) *TP mylar
*Enable/Disable area: 10mmx10mm
*Palm Rejection:Support
*Supports 10/100/1000/2500 Mb/sec *PCI-E
interface *Power Down Mode D1~D3 support
*PCIe ASPM L1.1, L1.2 support
*M.2 2230 w/CNVi interface, Intel WiFi6 AX201
IEEE802.11 a/b/g/n/ac/ax support
HD webcam with D-MICX1, Location: TOP side
Automatics Voltage adjustment between 100 and
240VAC 50/60Hz, 150 Watts (19V/7.89A), 3 Pins
Li- polymer Battery, SW Gas Gauge IC, soft pack,
3 cells (3S1P 4100mAh) 46.74 Wh
Audio Codec
Speaker
Microphone
Keyboard
Pointing Device
Lan
Wireless Lan+BT
Webcam
AC Adapter
Battery
08
EN
2.2 Preparing Your Computer
AConnect the AC adaptor’s DC output plug to the DC IN jack.
BThe display panel can be opened to a wide range of angles for optimalviewing.
CPress the power button to turn on your notebook computer.
09
EN
2.3 Product Overview
Please become familiar with each component before you operate the computer.
Top-Open View
The product’s color/ LED color, I/O port, indicator location, and
specification will depend upon the actually shipping product.
NOTE
When you are not using the computer, keep the
LCDscreen closed to protect it from dust.
CAUTION:
1
2
4
3
5
10
11
6
7
8
9
