Monster 10R Manuel utilisateur

280w Pointe BEAM –SPOT

moving head light

User Manual

This manual contains important information.

Please read before operating fixture.

1 SECURITY TIPS

WARNING!!! To reduce the risk of fire, electric shock, or

injury to persons, follow these important safety instructions:

non-professionals, not to disassemble the light arbitrarily and

lighting accessories inside.

rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ

(to be selected).

not beam irradiate the flammable materials, flammable materials

and the lamp should be maintained at least 1M over the distance.

lamps used in ambient temperature: -15 ℃-40 ℃, the

temperature of the surface of the lamp: 60 ℃.

to keep away from the liquid substance and humid environment.

before using the lights must ensure the good grounding, can not

install charging and remove any parts.

the installation of lamps, must be fixed screw fasteners with

additional security cable and regular inspection.

lamps consecutive working hours is not recommended more than

10 hours.

should stop using the lights in time when happens unusual

conditions during the process

lamp parts of the rotation, external accessories and paste parts

should be regular inspected, such as the emergence of loose and

rock, should be reinforced in a timely manner to prevent the

accident.

lamps adopt strong winds to refrigerate, it is easy to accumulate the

dust, so you have to clean it weekly especially the cooling air

opening, otherwise the dust will plug leading to poor light

2 TECHNOLOGY REFERENCE

Electrical:

Power supply:electronic auto-ranging

Input voltage range:supply 100-240V, 50/60Hz

Live Fuse: T 5 A/250V,

Neutral Fuse: T 5 A/250V

Max. power consumption: 470 W at 230V (I=2,05A,power factor 0.96)

Typical power consumption: 390W at 230V (I=1.8A, power factor 0.95)

*Allow for a deviation of +/-10%

Lamp:

Approved model: YODN HRI 280W RO

Base FaP2.5

Lamp life: 2000 hrs (Standard mode)

3000 hrs (Eco mode)

Ballast:Electronic

Optical System:

High luminous-efficiency glass reflector

Beam range: 5°-20°(spot application)

2.5°-10°(beam application)

Colour wheel:13 dichroic filters + white

Static gobo wheel:10 metal gobos & 4 beam reducers

Rotating gobo wheel:

9 glass gobos can be indexed and rotated in both directions at different

speeds

Gobo wheel continuous rotation

Glass gobos: outside diameter=15.9 mm, image diameter=12.5 mm,

thickness=1.1 mm,

high temperature borofloat or better glass

"Slot&lock" system for easy replacement of gobos

Prisms:

Rotating 6-facet linear prism with continuous rotation in both directions

Rotating 8-facet circular prism with continuous rotation in both

directions

Frost filter:Separate,variable frost filter

Zoom:Linear motorized zoom

Strobe:Strobe effect with variable speed (max.15 flashes/sec.)

Dimmer:Smooth dimmer from 0 - 100 %

Control:

Graphic touch screen for fixture setting and addressing

Gravitation sensor for auto screen positioning

Battery backup of the touch screen

Readout fixture and lamp usage, receiving DMX values, temperatures,

etc

Built-in analyzer for easy fault finding, error messages

Remotely switching on/off the lamp

Built-in demo sequences

Black-out while head moving, colour or gobo changing

Self-resetable thermo-fuse

Stand-alone operation

3 user editable programs, each up to 100 steps

Supported protocols: USITT DMX 512, RDM, ArtNet, MANet, MANet2,

sACN

Support of RDM (Remote Device Management)

3 DMX modes (24,16, 30 control channels)

Wireless DMX/RDM module (only for wireless DMX version):

Compliance with USITT DMX-512 (1986 & 1990) and 512-A

Full DMX fidelity and frame integrity

Auto sensing of DMX frame rate and frame size

<5ms DMX latency

Operational frequency range of 2402-2480 MHz

Producer: LumenRadio

Pan/Tilt:

Pan movement range 540°

Tilt movement range 270°

1 6 bit movement resolution

Automatic Pan/Tilt position correction

Remotely controllable speed of pan/tilt movement for easy programming

Movement control: tracking and vector

Pan/tilt-lock mechanism

Connection:

DMX in/Out: 3-pin and 5-pin XLR

Ethernet: RJ 45

Power In: Chassis connector Neutrik PowerCon, A-type, NAC3MPA

Rigging:

Mounting points: 2 pairs of 1/4-turn locks

Mounting horizontally or vertically via 2 Omega brackets

Temperatures:

Maximum ambient temperature : 45°C

Maximum housing temperature : 90°C

Minimum distances:

Min. distance from flammable surfaces: 1 m

Min. distance to lit objects (Standard mode-280W): 10 m

Min. distance to lit objects (Eco mode-230W): 7.5 m

Total heat dissipation:

1 600 BTU/h (calculated)

469 Wh (calculated)

Weight (net):

15 kg

3 Board Instruction

Control menu:

Control menu map:

ESCAPE

ENTER

DISPLAY ON

FEATURES SETTING

Run Mode WIRE/AUTO/DMX

ChanMode SMAL/STANDEFE

X Reverse

ON/OFF

Y Reverse ON/OFF

XYspeed NORM/FAST/SLOW

X angle 360/540/630

XY Fback ON/OFF

SignalClear ON/OFF

Full Color ON/OFF

Shortcut ON/OFF

ADVANCEO FUNCTION:

Zero. Set Plane(0-255)

Tilt(0-255)

FixeGobo(0-255)

RotGobos(0-255)

Color(0-255)

Focus(0-255)

Zoom(0-255)

Shutter(0-255)

Prism(0-255)

Prism2(0-255)

GobosRot(0-255)

ADV.

RST.

SAVE

ESC

Frost(0-255)

gobosRowRot(0-255)

Frost2(0-255)

Chan. Def. Color

Shutter

Dimmer

Gobo1

prismInt

PrismRot

Gobo2

Frost

Focus

Plane

PlaneFine

Tilt

TiltFine

Reset

XY speed

Fact. Set (0-255)X Master

(0-255)X Slave

(0-255)Y Master

(0-255)Y Slave

Lamp GND/5V

(0-255)YAngle

Logo Neutral/Custom

KEY 4KEY/SHUTTLE

(0-255)UsePassWord1

(0-255)UsePassWord2

FactPassWord1

(0-255)FactPassWord2

Use. Mang. Limit

Defaults

MANUAL

LAMP REST ALL MOTER

PART MOTER

XY MOTER

TEST RUN AUTO

SOUND

SMULATE DMX CH1-CH32(0-255)

SYSTEM INFO

DMX VALUE

CH1-CH32(0-255)

OTHER INFO (0-9999)Run Time

(0-9999)Run Count

(0-9999)Residue T

(0-9999)Residue C

(0-9999)Fan 1

(0-9999)Fan 2

(0-100)Temp 1

(0-100)Temp 2

PCB1 Ver

PCB2 Ver

PCB3 Ver

ERROR INFO Color

RotGobos

FixeGobos

Plane

Tilt

RotGobs1

Prism

Effect

Prism.R

Effect.R

Zoom

focus

DISPLAY SETTING

Brightness 1-7 Level

LightDelay Sec/On

Menuback Sec/Off
