MONGOOSE M15
TOUCH-KEY AUTOMATIC DUAL IMMOBILISER
Features:
• Standards certified to AS/NZS4601 Amendment 1 2003
• Automatic dual circuit engine immobiliser
• User programmable touch keys with more than 16 million codes
• Up to 3 touch keys can be programmed
• Visual dashboard mounted LED indicator
• Automatic arming after ignition off
• Automatic re-arm if engine not started
• 5 digit PIN coded override
ARMING:
The engine will always automatically immobilise 30 seconds after the ignition has been turned off.
This feature cannot be turned off as it is a mandatory Standards feature.
When the ignition is turned OFF, the dashboard LED will start to fast flash for 30 seconds to indicate the automatic sequence has
commenced. At the end of the 30 seconds the dashboard LED will slow flash as confirmation of immobilisation.
DISARMING:
Momentarily place the ‘touch key’ in the dashboard receptacle. You can now start the engine.
If the engine is not started within 30 seconds, the system will automatically re-arm.
AUTO RE-ARM:
The LED will fast flash after disarming signifying auto re-arm has commenced.
The system will re-arm if the engine is not started whilst the LED is fast flashing.
ARM CONDITION MEMORY:
If the car battery is disconnected, the security system will return to the same state, armed or disarmed,
Upon power re-connection.
EMERGENCY OVERRIDE – 5 DIGIT PIN CODED:
The system can be disarmed by entering your the unique 4 digit PIN code shown on the ‘PIN Code Card’ issued
with this product. KEEP THE CARD IN A SAFE PLACE – NOT IN THE VEHICLE !
Following is an example using PIN code 45258
The code is entered by turning the ignition ON or OFF in sequence with the dash mounted LED.
Full sequence is printed on the rear of the PIN code card.
Turn ignition ON -LED will light permanently to commence override.
Turn ignition OFF -LED will start flashing. Count the number of flashes for the 1st number (4 in the example).
Turn ignition ON - when the LED lights the 4th time. The LED will light solid.
Turn ignition OFF - LED will start flashing again. Count the number of flashes for 2nd number (5 in the example).
Turn ignition ON - when the LED lights the 5th time. The LED will light solid.
Continue this sequence for all numbers
The system will now disarm and the vehicle can be started.
Note: If your PIN code contains a “0”, this equals ‘10’.
Should you miss the LED flashes or enter a digit incorrectly, wait for 11 flashes and simply repeat the procedure
from step 1).
PROGRAMMING TOUCH KEYS (maximum 3):
1. Disarm the system with existing touch key or by using the PIN code override
2. Within 20 seconds of disarm, turn the ignition off/on 5 times (OFF-ON, OFF/ON, OFF/ON, OFF/ON, OFF/ON) Leaving in the
ON position. The LED will light solid
3. Touch the receptacle with the 1st touch key for 1 second, LED will flash once
Touch the receptacle with the 2nd touch key for 1 second, LED will flash twice
Touch the receptacle with the 3rd touch key for 1 second, LED will flash three times
The system will complete the programming sequence after the 3rd touch key
is programmed or the ignition is turned OFF.
This product is manufactured, tested and certified to AS/NZS4601 1999 amendment 1 2003.
Manufactured for: Mongoose (Australia) Pty Ltd
Make & Model Number: Mongoose M15
Country of manufacture: Taiwan R.O.C.
Supply voltage: 12v DC nominal – negative ground
Current consumption: 0.3amps (see alarm module label)
Suitability: All vehicles with 12v negative earth batteries
Date of manufacture: Refer date code on alarm module case
Whilst this security system provides a deterrent, it may not prevent theft or damage through wilful criminal intent. Mongoose does not by inference, intent or any other
means guarantee that a vehicle fitted with one of it’s security systems will not be stolen, broken into, tampered with, or parts taken.
Mongoose does not offer nor will pay compensation for any loss. We recommend adequate vehicle insurance and the fitment of other security devices as deemed necessary.
Any loss or any associated costs in making the vehicle mobile due to loss of the touch keys or PIN code card are the responsibility of the vehicle owner/driver. Also see warranty conditions.
