Homeowner's Installation

and Operating Manual

WR / WC Series Woodburning Fireplace

20014528





Read all instructions and warnings carefully before starting installation. Failure to

follow these instructions may result in a possible fire hazard and will void the warranty.



The WR/WC Series fireplaces are solid fuel, woodburn-

ing premium fireplaces. The WR400/500 are radiant

clean-face models and the WC400/500 are circulating

models with removable grilles (louvres). Both models are

fully insulated fireplaces.



MHSC fireplaces and component parts have been highly

tested and will operate safely when installed in accor-

dance with instructions provided in this manual. Carefully

read and understand all instructions  beginning

installation.

If you notice any damage to fireplace or component

parts, immediately report damage to your MHSC dealer.

Only use MHSC components or the warranty will be

voided and a fire hazard may be created.

MHSC warranty will be voided by and MHSC disclaims

any responsibility for the following actions:

• 



• 



• 

(except for chase

flashings as detailed in Chimney Top installation

instructions).

• 



• 













Consult local building codes to ensure that you are in

compliance installing the fireplace.

Fireplaces must be vented to the out-of-doors.















 Fuels used in gas, wood-

burning or oil fired appliances, and the products of

combustion of such fuels, contain chemicals known to

the State of California to cause cancer, birth defects

and other reproductive harm.

California Health & Safety Code Sec. 25249.6









The fireplace should not be located in areas that create

drafts (ie: frequently opened doors and central heating air

inlets/outlets) that hamper the normal flow of air into the

fire.



If you plan to install a gas log, the gas line should be

installed  framing the fireplace. The gas line must

be installed by a certified gas line installer.











Safety Information . . . . . . . . . . . . . . . . . . 2

Specifications and Framing . . . . . . . . . . 3

Parts Identification . . . . . . . . . . . . . . . . . 5

Chimney Requirements . . . . . . . . . . . . . 6

Planning Information . . . . . . . . . . . . . . . . 7

Installation .......................8

Replacement Parts . . . . . . . . . . . . . . . . 19

Accessories ..................... 20



WR / WC Series Woodburning Fireplace

20014528

5/8" (16mm)

1/2" (13mm)

1/2"

36"

(914mm)

3856M"

(971mm)

40" (1016mm)

5/8"

(16mm)

226M"

(578mm)

16M"

(45mm)

3556O" (902mm)

24"

(610mm)

76M"

(197mm)

756O"

(191mm)

Recessed

Nailing

Flange

FP590

SC36 SPECS

10/28/98

11" Dia.

(279mm)

Rough Opening Width 41"

Rough

Opening

Height

Rough

Opening

Depth

Gas Line

Access

4856O" (1232mm)

6856O" (1740mm)

856M"

(210mm)

22"

(559mm)

2256O"

(572mm)

22" (559mm)

436M"

(1111mm)

146"

(372mm)

156"

(391mm)

11"

(279mm)

396"

(1006mm)

(76mm)

(203mm)

756O"

(191mm)

Outside Air

Gas Line

Access

(1041mm)

Electrical Access

8" Dia.

(203mm)

3456O" (876mm)

FP590

WC400 Series specifications and framing.



36"

(914mm)

146"

(372mm)

156"

(391mm)

11"

(279mm)

40"

(1016mm)

396"

(1006mm)

(76mm)

5/8"

(16mm)

5/8" (16mm)

4856O" (1232mm)

5/8”(13mm)

1/2"

6856O" (1740mm)

856M"

(210mm)

22"

(559mm)

2256O"

(572mm)

22" (559mm)

226M"

(578mm)

24"

(610mm)

436M"

(1111mm)

(203mm)

76M"

(197mm)

756O"

(191mm)

756O"

(191mm)

Outside

Air

Gas Line

Access

Gas Line

Access

Electrical

Access

Recessed

Nailing

Flange

FP589

SR36 SPECS

10/28/98

7/6/99 djt correct dims.

11" Dia.

(279mm)

Rough Opening Width 41"

Rough

Opening

Height

Rough

Opening

Depth

(1041mm)

8" Dia.

(203mm)

3456O" (876mm)

FP589



WR400 Series specifications and framing.

WR / WC Series Woodburning Fireplace

20014528

5/8" (16mm)

1/2" (13mm)

1/2"

42"

(1067mm)

3856M"

(971mm)

46" (1168mm)

5/8"

(16mm)

226M"

(578mm)

16M"

(45mm)

38" (965mm)

24"

(610mm)

76M"

(197mm)

756O"

(191mm)

Recessed

Nailing

Flange

FP592

SC42 SPECS

10/02

11" Dia.

(279mm)

Rough Opening Width 47"

Rough

Opening

Height

Rough

Opening

Depth

Gas Line

Access

50" (270mm)

50" (1270mm)

7056O" (1791mm)

856M"

(210mm)

22"

(559mm)

2256O"

(572mm)

2656M"

(667mm)

436M"

(1111mm)

146"

(372mm)

156"

(391mm)

11"

(279mm)

396"

(1006mm)

(76mm)

(203mm)

756O"

(191mm)

Outside Air

Gas Line

Access

(1194mm)

Electrical Access

8" Dia.

(203mm)

36" (914mm)

FP592

 WC500 Series specifications and framing.



42"

(1067mm)

46"

(1168mm)

396"

(1006mm)

5/8"

(16mm)

5/8" (16mm)

1/2" (13mm)

1/2"

226M"

(578mm)

24"

(610mm)

76M"

(197mm)

756O"

(191mm)

Gas Line

Access

Recessed

Nailing

Flange

FP591

SR42 SPECS

10/28/98

7/6/99 djt

correct dims.

11" Dia.

(279mm)

Rough Opening Width 47"

Rough

Opening

Height

Rough

Opening

Depth

50" (1270mm)

7056O" (1791mm)

856M"

(210mm)

22"

(559mm)

2256O"

(572mm)

2656M"

(667mm)

436M"

(1111mm)

146"

(372mm)

156"

(397mm)

11"

(279mm)

(76mm)

(203mm)

756O"

(191mm)

Outside

Air

Gas Line

Access

Electrical

Access

(1194mm)

8" Dia.

(203mm)

36" (914mm)



 WR500 Series specifications and framing.

FP591

WR / WC Series Woodburning Fireplace

20014528



Insulation methods shown are optional

for cold climate, not a requirement for

unit operation.

FP554

 Fireplace and chase parts identification.

FP554

BR/BC

Combo of IWF261 AND IWF265

11/10/97

Termination Cap

Storm Collar

Pan Flashing

Draftstop

Batt Insulation

(cut out around fiestop)

Firestop

Ceiling Level

Nailing Flange

Gas Line Access

(both sides)

Electrical Access

Outside Air Cover Plate Metal Safety Strips

(1, 2 or 3 pieces)

Firebox

Grate

Screen

Gas Line Knockout

(both sides)

Damper Control

Surround

Standoff

FP1531

hearth dimensions

9/04 djt

  

    

WR/WC400 31¹⁄₈" 19⁷⁄₈" 15¹⁄₂"

(791 mm) (505 mm) (394 mm)

WR/WC500 36³⁄₄" 22⁷⁄₈" 15¹⁄₂"

(934 mm) (581 mm) 394 mm)

FP1531

 Hearth dimensions.

WR / WC Series Woodburning Fireplace

20014528



0 0 0 0 0 3" 11"

1 0 0 0 0 8¹⁄₄" 20"

0 1 0 0 0 11¹⁄₄" 25¹⁄₄"

2 0 0 0 0 13¹⁄₂" 29¹⁄₄"

1 1 0 0 0 16¹⁄₂" 34¹⁄₄"

0 0 1 0 0 20¹⁄₄" 40³⁄₄"

2 1 0 0 0 21³⁄₄" 43¹⁄₂"

0 0 0 1 0 26¹⁄₄" 51¹⁄₄"

0 1 1 0 0 28¹⁄₂" 55¹⁄₄"

1 0 0 1 0 31¹⁄₂" 60¹⁄₄”

0 1 0 1 0 34¹⁄₂" 65¹⁄₂"

0 0 2 0 0 37¹⁄₂" 70³⁄₄"

1 1 0 1 1 41¹⁄₂" 77³⁄₄"

0 0 1 1 1 45" 83³⁄₄"

0 1 2 0 1 47¹⁄₄" 87¹⁄₂"

0 0 0 2 1 51" 94"

0 1 1 1 1 53¹⁄₄" 98"

0 0 3 0 1 56¹⁄₄" 103¹⁄₄"

0 1 0 2 1 59¹⁄₄" 108¹⁄₂"

0 0 2 1 1 62¹⁄₄" 113¹⁄₂"

0 1 3 0 1 64¹⁄₂" 117¹⁄₂"

0 0 1 2 1 68¹⁄₄" 124"

0 1 2 1 1 70¹⁄₂" 128"

0 0 0 3 1 74¹⁄₄" 134¹⁄₂"

0 1 1 2 2 78" 140³⁄₄"

0 0 3 1 2 81" 146"

0 1 0 3 2 84" 151¹⁄₄"

0 0 2 2 2 87" 156¹⁄₂"

0 1 3 1 2 89¹⁄₄" 160¹⁄₄"

0 0 1 3 2 93" 166³⁄₄"

0 1 2 2 2 95¹⁄₄" 170³⁄₄"

0 0 0 4 2 99¹⁄₄" 177³⁄₄"

0 1 1 3 2 101¹⁄₄" 181³⁄₄"

0 0 3 2 2 104¹⁄₄" 186¹⁄₄"

0 1 0 4 2 107¹⁄₄" 191¹⁄₂"

0 0 2 3 2 110¹⁄₄" 196³⁄₄"

0 1 3 2 3 114" 203¹⁄₄"

0 0 1 4 3 117³⁄₄" 209³⁄₄"

0 1 2 3 3 120" 213¹⁄₂"

0 0 0 5 3 123³⁄₄" 220"



 ¹⁄₂ 





 

 G + H cannot exceed 20 feet.

Air Space Clearances: SK8 (2-wall) = 1¹⁄₂" and "S" Series (3-wall) = 2"



The following safety rules apply to offset

installations (letters correspond with il-

lustration above):

 Height of the chimney is measured

from the hearth to the chimney exit.

WR/WC400 WR/WC500

Maximum: 90'0" 90'0"

Minimum:

Without Elbows 12' 6" 12' 6"

With 2 Elbows* 14' 6" 14' 6"

With 4 Elbows* 21' 0" 21' 0"

 Do not use more than 4 elbows per

chimney.

Attach the straps of the return (top) elbow

to a structural framing member.

The offset (first) elbow of any pair does

not have straps.

IWF269

The chimney cannot be more than 30˚

(45˚ in Canada) from the vertical plane in

any installation*.

The maximum length of the angled run

of the  chimney system is 20 feet. (G

plus H cannot exceed 20 feet.)

 A chimney support (Model SKCS8)

is required every 6 feet of angled run of

chimney. Chimney supports are required

for every 30 feet and 60 feet (SK8 pipe)

or 20 feet and 40 feet (3-wall pipe) of ver-

tical chimney height above the hearth.

Determine the offset distance of your

chimney arrangement from the centerline

of the fireplace to the centerline of the

chimney where it is to pass through the

first ceiling.

 This offset distance may not be

your full offset distance. See Examples 2

and 3.

FP282

MBUF

5/26/96

OFFSET

RISE

IWF282

* In Canada, two (2) SK845 are allowed.

 Chimney system requirements.

RISE

OFFSET

6 FT.

HEARTH

FLOOR

CHIMNEY

SECTION

CHIMNEY FLUE EXIT

ELBOW

FP269

MBUF

5/16/96

rev. 5/25

30°

OFFSET

ELBOW

30°

OFFSET

ELBOW

30°

RETURN

ELBOW

30°

RETURN

ELBOW

SKCS8

SUPPORT

Example 1 Example 2 Example 3

WR / WC Series Woodburning Fireplace

20014528

LTMODEL SK

2 WALL CHIMNEY

TOTAL

LENGTH

(LT)

INSTALLED

LENGTH

(L1)

SK81

SK818

SK83

SK84

1156O"

1756O"

3556O"

4756O"

1056O"

1656O"

3456O"

4656O"

FP288

MBUF-INSTALLED LENGTH

6/17/96

Installed lengths of chimney sections.



Preplanning an installation is very important to ensure

safety and to save time and money. An installer must

predetermine where a fireplace will be set and how the

chimney system will be run.



A fireplace may only be mounted on the following sur-

faces:

1. A flat combustible surface.

2. A raised wooden platform.

3. A concrete block or other solid object placed beneath

each of the four (4) corners of the fireplace.

The fireplace  be spaced 1/2" (13 mm) from a

combustible back wall and 1/2" (13 mm) from a com-

bustible side wall or support. (Page 14, Fig. 20)





Major U.S. building codes specify a minimum chimney

height above the roof top. The “Ten Foot Rule” is a fire

safety rule and not a draft rule. To ensure proper draft,

it is recommended that you always meet or exceed the

“Ten Foot Rule,” especially when installing a termination

on a high pitch roof. (Fig. 8)

The key points of the "Ten Foot Rule" are:

1. If the horizontal distance from the chimney to the

peak of the roof is 10' (3m) or less, the top of the

chimney must be at least 2' (610mm) above the peak

of the roof, but never less than 3' (914mm) in height

above the highest point where it passes through the

roof.

2. If a horizontal distance from the chimney to the peak

of the roof is more than 10' (3m), a chimney height

reference point is established on the surface of the

roof a distance of 10' (3m) from the chimney in a

horizontal plane. The top of the chimney must be

at least 2' (610mm) above the reference point, but

never less than 3' (614mm) in height above the high-

est point where it passes through the roof.

Determine how the chimney will be run, length of run

and chimney components required to complete the

job. (Fig. 6)  install a chimney below minimum

heights.

In planning a chimney system, it is important to know:

1. The height of a chimney is measured from the hearth

to the exit point on the termination.

2. A chimney cannot be offset more than 30° from a

vertical plane.

3. A chimney may run straight up or it may be neces-

sary to offset it to avoid obstructions.

4. The maximum length of an angled run (total chimney

system) is 20' (6m).

5. No more than 2 offsets (4 total 30° elbows in U.S./or

2 total 45° elbows in Canada) per fireplace may be

used.

6. A guy wire stabilizer is required for chimneys extend-

ing more than 6' (1.8m) above a roof line.

WF288

AC246

 Ten Foot Rule illustration.

2' Min.

Min.

0 To 10'

Min.

0 To 10'

AC246

4/1/96

Reference

Point

WR / WC Series Woodburning Fireplace

20014528





If you live in a cold climate, it is not required but

 that you insulate fireplace

enclosure to eliminate cold air penetration as much

as possible.

Insulate base of fireplace with a noncombustible in-

sulation rated for a minimum of 300°F. Insulating is

 for outside wall installations over a

concrete slab. If fireplace is installed on a platform,

insulation should be placed on top of the platform

fireplace is set. (Fig. 10)

When a fireplace is installed in a chase or on an

outside wall, enclosure should be treated like any

outside wall in a home. Insulation should be in-

stalled on the inside wall as well as the outside

wall(s). In a chase, it is also a good idea to install a

firestop at the first ceiling level above the fireplace

and enclose the chase with sheeting material. Insu-

lation may then be installed above sheeting material

to assure the space around the fireplace is totally

protected. (Fig. 5)

When installing the chimney,  caulk be-

tween outer pipe and firestop. It is vital that some

air be allowed to flow through this very thin gap.





(Page

14, Fig. 20)





The chimney system is supported by the fireplace for

vertical chimney heights less than 30' (9m) above the

hearth. Chimney supports are required if the vertical

height exceeds 30' (9m) with SK8 chimneys or 20' (6m)

with 3-wall chimneys. Locate chimney supports at ceil-

ing holes or other structural framing at 30' (9m) (SK8)

or 20' (6m) (3-wall) heights. Spacing between chimney

supports  exceed 30' (9m) (SK8) or 20' (6m)

(3-wall). Use Chimney Support Model SKCS8. 



 Support provided by elbow straps fulfills the

support requirement only if they are spaced as previ-

ously described. (A chimney support is 2¹⁄₂" (64mm)

long when installed.)

Angled chimney runs require a support every 6' (1.8m)

in addition to the elbow straps. Chimney supports are

used for this function. (Fig. 9)



A chase is a vertical box like structure which encloses

the fireplace and/or chimney. Chases are typically built

on the outside of the house with fireplace opening cut

into the outer wall of a room. (Page 5, Fig. 5)

If you need help in determining fireplace location or how

the chimney system should be run, contact your MHSC

dealer for assistance.

FP284

 Chimney support installation

FP284

MBUF

5/25/96

Chimney Sup-

port Strap

SKCS8

WR / WC Series Woodburning Fireplace

20014528



Framing can be constructed before or after the fireplace

is set in place, however, most installers build the frame

before setting the fireplace.

Frame fireplace with 2 x 4 lumber or heavier materials.

Refer to framing dimensions in Figures 1, 2, 3 or 4 for

basic fireplace specifications.

 Framing should be positioned to accommodate

wall covering and fireplace facing material.





If a circulating fireplace is to be installed, run the 120

VAC, 60 Hz wiring to the left side of installation. Wiring

must be completed  the fireplace is secured and

finish material applied.

Remove the cover plate and electrical knockout on the

lower left side of the fireplace and set aside. Follow the

instructions on Page 10 for proper wiring and installation

of the EB1.

If the fan kit is not being installed with the fireplace, it

is highly recommended that 120 VAC supply be made

available since someone may elect to install a blower at

a later date.





• Wiring should be installed by a certified

electrician.

• Turn off circuit breaker before wiring models.

Once fireplace is secured, complete wiring the fan

kit. Remove knockout in the center of the back of

the EB1 and install listed cable clamps. Feed electri-

cal wire through listed cable clamp leaving approxi-

mately six (6) inches of wire exposed through the

EB1. Secure listed cable clamp to the wire.

Attach white wire from power source to one (1) wire

of receptacle and secure with nut. Attach black

wire from power source to the other wire of recep-

tacle and secure with nut. Be sure nuts are secured

tightly.

Secure EB1 assembly to inside of electrical box

coverplate using two screws. Attach cover to face of

the EB1 while being careful to position excess wire

completely within the EB1, then attach coverplate to

fireplace.



Refer to optional Model FK12 fan kit assembly in-

stallation instructions for field installation.



Since you have already preplanned the chimney run,

you should know exactly how the installation is to be ac-

complished — how much pipe is required, the number

of elbows, if any, and type of termination to be used.

REPORT TO YOUR DEALERS ANY

PARTS DAMAGED IN SHIPMENT, SPECIFICALLY

CHECK THE END CONNECTION OF CHIMNEY SEC-

TIONS AND ELBOWS.

 Fireplaces may use MHSC model SK8, or Mod-

el S (three wall) chimney systems. The WR/WC Series

"A" Fireplace will accept the SK8 chimney system as is;

but a TWABR adapter collar is required when using the

Model S (triple wall) chimney system. The installation

procedure described in this manual applies  to the

SK8 system. Either chimney system may be used, but

 be mixed.

FP555

 Insulating between platform and fireplace.

FP555

11/10/97

Hard Flat

Surface

Insulation

Platform

WR / WC Series Woodburning Fireplace

20014528



To mark the centerline of the flue, put the fireplace

in final position and measure out from the wall: 9¹⁄₄"

(235mm). Mark a spot on the ceiling directly above the

fireplace. Draw a line parallel to the back wall through

this mark. (Fig. 11)

Using a plumb bob positioned directly over center point

of fireplace flue collar, mark the ceiling to establish the

chimney center point. (Fig. 11)



In order to clear an obstruction, it may be necessary to

offset chimney from vertical. This is accomplished by

using MHSC elbows. Use the 30° Offset Elbow table on

Page 6 to determine proper offset and parts required.

Each offset requires two (2) elbows. The second elbow

is equipped with support straps. It is very important to

install the second elbow in each offset as close to the

ceiling or support as possible so that the elbow straps

can be secured to framing members to help support the

weight of the chimney.

Determine offset distance of your chimney arrangement

from centerline of fireplace to centerline of chimney

where it is to pass through ceiling.

Locate center point of the chimney on ceiling as though

a straight up chimney arrangement is to be used. Mea-

sure your offset dimension from straight up chimney

center point on ceiling.





The size of the hole in ceiling will vary with the angle at

which the chimney passes through ceiling.

Drive a nail up through ceiling at marked chimney cen-

ter point. Go to floor above and see where hole will be

cut. Check to see where existing ceiling joists and other

possible obstructions are located...i.e. wiring, plumbing

etc... If necessary, reposition chimney and/or fireplace

to avoid obstructions.



Cover fireplace collar opening and cut proper sized

chimney hole in chimney. The SK8 pipe allows you to

run pipe through a typical 16” on center joist without

cutting joists.



Frame the ceiling chimney hole as shown in Figure

12. It is good practice to use framing lumber that is the

same size as the ceiling joists; this is a requirement at

attic level.

FP556

 Locate centerline of chimney with plumb line.

FP556

BR/BC

LOCATE CENTER LINE

11/10/97

956M"

(235mm)

Chimney Centerline

Actual Centerpoint

Plumb Line

Plumb Bob

Imaginary Cen-

terpoint

 Typical frame for ceiling chimney hole.

FP551

BR/BC

9/29/97

AB AB

A "SK" Series framing = 1456O" X 1456O" (368 x 368mm)

B"S" Series framing = 1756O" X 1756O" (445 x 445mm)

Existing

Ceiling Joist

Ceiling

New

Framing Members

Chimney Hole

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Monessen Hearth Cheminée intérieure

Monessen Hearth

Monessen Hearth BDV300N/PV7 Manuel utilisateur

Monessen Hearth

Monessen Hearth Direct Vent Gas Fireplace BDV300 Manuel utilisateur

Monessen Hearth

Monessen Hearth 724BV4536 Manuel utilisateur

Monessen Hearth

Monessen Hearth Direct Vent Insert System REVEAL (ILDV) Instructions d'installation

Monessen Hearth

Monessen Hearth GCUF Series Manuel utilisateur

Monessen Hearth

Monessen Hearth MAGNUM MCUF36E-F Manuel utilisateur

Monessen Hearth

Monessen Hearth Unvented Vent-Free Fireboxes BUF400 Manuel utilisateur

Monessen Hearth

Monessen Hearth DFX DBX24C Manuel utilisateur

Monessen Hearth

Monessen Hearth B Vent 724BV4536C Instructions d'installation

Monessen Hearth

Monessen Hearth Direct Vent CDVR33 Instructions d'installation

Monessen Hearth

Monessen Hearth Natural Vent Gas Fireplace BBV400 Manuel utilisateur

Monessen Hearth

Monessen Hearth AVFL42NTSC-SR Manuel

Monessen Hearth

Monessen Hearth Indoor Gas Fireplace GRUF36CF Manuel utilisateur

Monessen Hearth

Monessen Hearth VCF Series Manuel

Monessen Hearth

Monessen Hearth DFX24 Manuel utilisateur

Monessen Hearth

Monessen Hearth DB24NTG Guide de démarrage rapide

Monessen Hearth

Monessen Hearth Indoor Gas Fireplace IDV490C Manuel utilisateur

Monessen Hearth

Monessen Hearth AVFLST Series Manuel

Monessen Hearth

Monessen Hearth 6000DV Manuel utilisateur

Monessen Hearth

Monessen Hearth Lo-Rider Vent Free Firebox LCUF32-R Instructions d'installation

Monessen Hearth

Monessen Hearth BLDV7 SERIES BLDV500N/PV7;N/PSC7 Manuel utilisateur

Monessen Hearth

Monessen Hearth HBDV300N Manuel

Monessen Hearth

Monessen Hearth LO-Rider Designer Vent Free Fireboxes LLCF36 Manuel utilisateur

Monessen Hearth

Monessen Hearth Unvented Vent-Free Fireboxes BUF400 Instructions d'installation

Manuels Cheminée intérieure populaires d'autres marques

Brigantia

Brigantia 35-DVRS31N-2 Manuel du propriétaire

Nordpeis

Nordpeis Bergen Manuel utilisateur

Superior

Superior BCT2536TMN Manuel utilisateur

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuel utilisateur

Renaissance

Renaissance RUMFORD 1000 Manuel utilisateur

Lacunza

Lacunza IV-800 Manuel utilisateur

Baxi

Baxi 940 Instructions d'utilisation

Dru

Dru Maestro 60/2 Tall RCH Manuel utilisateur

Diamond Fireglass

Diamond Fireglass SS-O22 Manuel utilisateur

HearthStone

HearthStone Windsor Bay 8830 Manuel de programmation

Napoleon

Napoleon ASCENT B42 Manuel utilisateur

Enviro

Enviro E33GI Manuel utilisateur

Smeg

Smeg L30 FABE Instructions de montage

KEDDY

KEDDY K700 Manuel utilisateur

Godin

Godin 3451 Manuel utilisateur

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuel utilisateur

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuel utilisateur

Desa

Desa CCFPDFT Manuel d'utilisation
