Moen 6500 Guide de configuration

 Order by Part Number

Icon™

Single-Handle Lavatory

MODELS FINISH

6500 Chrome

6500BB Brushed Bronze

6500BN Brushed Nickel

Vessel Extension Kit - Not included with faucet

Plug Button

133484 Chrome

133484BB Brushed Bronze

133484BN Brushed Nickel Grid Strainer

125752 Chrome

125752BN Brushed Nickel

Handle

146192 Chrome

146192BB Brushed Bronze

146192BN Brushed Nickel

Plug Button

152859 Chrome

152859BB Brushed Bronze

152859CSL Brushed Nickel

Waste Nut

& Seal

Illustrated Parts

TO ORDER PARTS CALL: 1-800-BUY-MOEN

www.moen.com

Vessel Extension Kit

A1717 Chrome

A1717BB Brushed Bronze

A1717BN Brushed Nickel

Rev. 12/10

Pop-Up Plug & Seat

10709 Chrome

10709BB Brushed Bronze

10709BN Brushed Nickel

Hardware Kit

146190

Lift Rod Kit

133481 Chrome

133481BB Brushed Bronze

133481BN Brushed Nickel

Deck Plate

133483 Chrome

133483BB Brushed Bronze

133483BN Brushed Nickel

Single Mount Escutcheon

133482 Chrome

133482BB Brushed Bronze

133482BN Brushed Nickel

Aerator (1.5 gpm) & Tool

316711

Aerator (2.2 gpm) & Tool

128878

Cartridge, Cartridge Nut

and Set Screw

1255

Cartridge Nut

Note: Must change nut with cartridge

144266

Set Screw

155023

Plug

Button Kit

137403

HANDLE PLUG BUTTON

PRIOR TO 1/2011

There is more than 1 version of this model.

Page down to identify the version you have.

 Order by Part Number Icon™

Single-Handle Lavatory

MODELS FINISH

6500 Chrome

6500BB Brushed Bronze

6500BN Brushed Nickel

Lever Mechanism Kit

101957

Deck Plate

133483 Chrome

133483BB Brushed Bronze

133483BN Brushed Nickel

Retainer Clip

SK1711

Aerator (1.5 gpm) & Tool

316711

Aerator (2.2 gpm) & Tool

128878

Hardware Kit

118245

Vessel Extension Kit - Not included with faucet

Single Mount Escutcheon

133482 Chrome

133482BB Brushed Bronze

133482BN Brushed Nickel

Plug Button

133484 Chrome

133484BB Brushed Bronze

133484BN Brushed Nickel

Replacement Cartridge

1225

Hardware Kit

96804

Handle Assembly

133485 Chrome

133485BB Brushed Bronze

133485BN Brushed Nickel

Plug Button Kit

137403

Lift Rod Kit

133481 Chrome

133481BB Brushed Bronze

133481BN Brushed Nickel

Waste Nut

& Seal

Grid Strainer

Illustrated Parts

TO ORDER PARTS CALL: 1-800-BUY-MOEN

www.moen.com

Ring Shield

102567 Chrome

102567BB Brushed Bronze

102567BN Brushed Nickel

Dome

133487 Chrome

133487BB Brushed Bronze

133487BN Brushed Nickel

Vessel Extension Kit

A1717 Chrome

A1717BB Brushed Bronze

A1717BN Brushed Nickel

Rev. 10/10

Pop-Up Plug & Seat

10709 Chrome

10709BN Brushed Nickel

10709BB Brushed Bronze
