Modway MOD-6192 Manuel utilisateur

JCBB SCREW M8 x 16MM

M5 ALLEN KEY

JCBC SCREW M6 x 50MM

SPRING WASHER 1/4''

ADJUSTABLE GLIDE C167

Hardware for Headboard

Hardware for Bed Frame and Legs

Component :

1- HEADBOARD

2- HEADBOARD SUPPORT

3- SIDERAIL (L & R)

4- FOOTBOARD

Customer Service 908-368-1025 www.modway.com Page 1/3

x11

Thank you for purchasing the MODWAY BED !

Before you start,here is some helpful advice:

1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step

instructions.

2.Owing to the size and weight of the bed, we recommed that it is assembled by two adults,on a carpeted or

padded area, in the room that it is intended for.Approx assembly time:30 minutes.

3.Please do not use any tools other than those provided or recommended in these instructions.

4.Please do not throw away any of the packaging or the instruction until you have checked all the components

and hardware and the furniture is fully assembled.Please ensure that the packaging is disposed of in a safe

environmentally friendly way.

5.Assemble all components loosely until advised to tighten.Depending on use, it may be necessary to tighten

the components from time to time,so please save the tools that has been provided.

6.Please keep all fitting out of reach of children.

MOD-6192

5- SLAT

6- SLAT WITH HOLE

7- CENTER SLAT

8- CENTER SLAT SUPPORT

M4 ALLEN KEY (BALL SHAPE )LONG

PAN HEAD SCREW M4 x 25MM

x28

HJCBC SCREW M6 x 40MM x4

IFLAT WASHER 1/4" x8

JPROTECTION PAD x4

Place

STEP 1 :

STEP 2 :

Hardware & Tool required

Page 2/3

Customer Service 908-368-1025 www.modway.com

STEP 1.1

Hardware & Tool required

A x 8 B x 1

Place SIDERAIL (L & R)(3) and FOOTBOARD(4) on a carpeted or padded area as shown.Attach FOOTBOARD(4) into

SIDERAIL (L & R)(3)by inserting JCBB SCREW M8 x 16MM(A).Tighten with M5 ALLEN KEY(B).

STEP 1.2

A x 3 B x 3 B x 3 F

Flip the assembled CENTER SLAT(7) over. Place the SLAT WITH HOLE(6) on the CENTER SLAT (7) and place the

CENTER SLAT SUPPORT(8) attach them by inserting JCBC SCREW M6 x 50MM(C),and Spring Washer1

4''.

Tighten with M4 Allen Key(Ball Shape)Long(D).Then, attach ADJUSTABLE GLIDE C167(E) into CENTER SLAT SUPPORT(8).

MOD-6192

J x 4

Place

Hardware & Tool required

STEP 3 :

Page 3/3

Customer Service 908-368-1025 www.modway.com

28x

G x 28

Screw the slat(5) by inserting PAN HEAD SCREW M4 x 25MM (G) or padded area as shown. Tighten with SCREW DRIVER.

Assembly is complete,the bed is ready to be enjoyed now!

Remark: Do not sit or lie down on the

platform without the mattress

MOD-6192
