Modway MOD-5458 Manuel utilisateur

Customer Service 908-368-1025︱ Page 1 of 3

MOD-5458 TWIN BED

Hardware:

Component:

A Bolt M6x20mm x20

B Flat Washer x4

C Rubber Insert x16

D Allen Wrench x1

1 Headboard x1 2 Footboard x1

3 Side Rail x2 4 Double Slat x4

5 Single Slat x8 6 Low Post x2

Thank you for purchasing the TWIN BED！

Before you start, here is some helpful advice:

1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step

instructions.

2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or

padded area, in the room that it is intended for. Approx assembly time: 45 minutes.

3.Please do not use any tools other than those provided or recommended in these instructions.

4.Please do not throw away any of the packaging or the instruction until you have checked all the components and

hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe

environmentally friendly way.

5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the

components from time to time, so please save the tools that has been provided.

6.Please keep all fitting out of reach of children.

Customer Service 908-368-1025︱ Page 2 of 3

MOD-5458 TWIN BED

Ax4 Bx4 Dx1

Ax16 Cx16 Dx1

STEP 1:

Insert Low Post (6) into Headboard (1) as shown.

Attach by using Flat Washer (B) and Bolt (A) from the holes on the back of Low Post (6) and Headboard (1).

Use Allen Wrench (D) to tighten Bolts (A) clockwise until secure at this step.

Hardware & Tool required

STEP 2:

Take out all Double Slats (4), Single Slats(5) and Side Rails(3) and place them as shown.

Insert one end of Single Slats (5) into Rubber Insert (C), then insert them into the corresponding holes on one piece of

Side Rail (3) as shown.

Attach Double Slats (4) to the same Side Rail (3) by using Bolts (A). Do not fully tighten Bolts (A) with Allen Wrench (D) yet.

Repeat above for the other Side Rail (3).

Use Allen Wrench (D) to tighten all Bolts (A) clockwise until secure.

Hardware & Tool required

4 5 4 4 4

5 5 5 5 5

5 5

A A D

Back with holes

A B

A B 1

Customer Service 908-368-1025︱ Page 3 of 3

MOD-5458 TWIN BED

STEP 3:

Assembly is complete. Your bed is ready to be enjoyed now!

Place the Headboard (1) close to the assembled Side Rail (3).

Insert the hooks on the Side Rail (3) into the hook holder on the assembled Headboard (1&6) as shown.

Repeat the same steps for the Footboard (2).

Hooks on side rails

Hook Holder on

Headboard/Footboard

6 3
