xTablet T1400 User Guide

Getting Started

Contents

Chapter 1: Getting Started 1

Unpacking 1

Description Of Parts 2

First-time Operation 5

Hot Swapping Batteries 6

Connecting to Power Supply 6

Turning On / Off 8

Chapter 2: Useful Information 10

CTRL-Alt-Delete Operation 10

Boot Menu 10

How to Enter BIOS 10

Battery Status LED's 11

HotTab Operation 11

Camera 13

HotTab Devices 15

HotTab Setting Menu 16

Auto Screen Rotate- Windows 10 Enable - Disable 18

Auto Screen Rotate- Windows 8.1 Enable - Disable 19

Auto Screen Rotate- Windows 7 Enable - Disable 20

Tech Tip - Windows 8.1 Password required on wake 24

Tech Tip - Windows 10 Password required on wake 25

High Resolution Screen Scaling 26

High Resolution Screen Scaling Win 10 27

High Resolution Screen Scaling Win 8.1 & WIn7 28

Changing screen resolution in Win 10 29

Changing screen resolution in Win 8.1 & Win 7 31

Setting up the Barcode Scanner 33

Setting up the RFID Reader 38

How to use the LTE Skylight Connection Mgr Software 44

How to install LTE SIM 48

Mechanical Drawings 54

Accessories 56

Chapter 3: Troubleshooting 57

Troubleshooting (Basic) 57

Chapter 4: Safety Informaiton 60

Precaution on Battery Pack 60

Please read these instructions carefully before using this product, and save this manual for future use.

Read Me First Getting Started Troubleshooting Appendix Useful Information

General Product Safety 61

Handling and Maintenance 62

General Guideline 62

Cleaning Guideline 62

Touchscreen Guideline 62

Regulatory Safety Statements 63

Contact information 64

xTablet T1400 Users Guide

Getting Started

Chapter 1: Getting Started

Congratulations on purchasing the xTablet T1400. The rugged design allows you to use it in

harsh outdoor environments.

This chapter tells you step by step how to get the computer up and running. You will find

instructions for the following procedures:

 Unpacking

 Description of Parts

 First Time Operations

 Turning On/Off

Unpacking

Check and identify the supplied accessories:

 xTablet T1400 with Screen Protector  Standard, Long-Life, or Extra Long Life

Battery

 Power Adapter



Power Cord

 Capacitive Stylus and Tether

 Briefcase Handle

xTablet T1400 Users Guide

xTablet T1400 User Guide

Getting Started

Description of Parts

Front:

Right:

Item Description

1Front Camera 2 Megapixel Webcam

2LED Indicators: Show the current status

of the xTablet T1400

Green -

WiFi/BT/3G/GPS ON

No light - WiFi/

BT/3G/GPS are OFF

HDD Green - Hard drive

Activity

No light - Hard drive

Idling

Battery

Orange – Charging in

progress

Green – Battery in use

Blinking Red – Battery

removed while tablet

Solid Red - Low

Battery (<10%)

Not lit – Battery is fully

charged when AC

adapter is plugged in

Power

Blue – Tablet is ON

No light – Tablet is

OFF

3Touch Screen Display and multi-touch

act as one of the inputs

4Fn1 Button Programmable function

key configured by

HotTab Utility. Default:

Web Browser

5Menu Button HotTab Quick Access

6Power Button Turns on/off tablet

No Item Description

7 I/O Cover Protects I/O ports

8 Micro HDMI HDMI output to

external HDMI display

9 LAN/RS232 Adapter port for a

LAN or RS232

connection with cable

10 USB 3.0 High speed USB port

connects to USB

devices, such as a

USB flash drive,

mouse, keyboard,

printer, etc.

11 Mic In/Line

Out

Headset or

headphone can be

connected

12 Power Jack DC-IN power input

jack

13 Micro SD

Card Reader

Memory card reader

port for Micro SD

Card

Side I/O:

xTablet T1400 Users Guide

Getting Started

Front Buttons:

Front LED Indicators:

Docking Contacts:

Expansion Port:

Rear Buttons

Battery Lock:

xTablet T1400 Users Guide

xTablet T1400 User Guide

Getting Started

No Item Description

14 Kensington

Lock detail

Kensington Lock access.

15 Optional

Barcode

Barcode Imager for

reading 1D/2D barcodes.

16 Optional RFID RFID reader for reading of

13.56MHz RFID tags.

17 Rear Camera 5MP autofocus camera.

Captures images and

videos.

18 Camera Flash LED flash to for the

camera.

19 Expansion

Contacts

Connectivity to custom

modules (USB2.0 and

RS232 signals).

20 Fn2 Button Programmable function

key configured by HotTab

Utility. Default: camera

21 Volume

Buttons

Volume Control.

(+) increase volume,

(-) decrease volume.

22 Battery Lock Lock the battery in place

once battery is inserted.

Not spring-loaded.

23 Battery Latch Spring-loaded slider that

latches the battery in.

24 Stylus Holder Stylus holder with tether

slot.

25 LTE Module &

SIM card slot

Service window to insert

Micro SIM card. Also

provide access to LTE

Module.

26 Speakers Audio and audible alerts.

No Item Description

27 Docking

Contacts

Docking contacts for

office and vehicle

docks to provide

power and external

GPS antenna

Bottom:

Rear:

xTablet T1400 Users Guide

Getting Started

First-time Operation

Inserting Battery Pack

To insert the included standard battery pack into the xTablet

T1400:

1. Disconnect any cords connected to the xTablet T1400.

2. Turn the xTablet T1400 over, back facing up.

3. Rotate the D-Rings so they are out of the way for the

battery to be removed.

4. Locate the Battery Lock and push it to the “Unlocked”

position.

5. Insert the battery on the connector-pins side first, and then

lower the battery into the battery compartment until you

hear the latch click.

6. Make sure the edges of the battery are flat against the

housing once fully inserted. Then move the D-rings back

into place

Removing the Battery Pack

1. Disconnect any cords connected to the computer.

2. Turn the xTablet T1400 over, back facing up.

3. Rotate the D-Rings so they are out of the way for the battery to be removed.

4. Locate the Battery Lock and push it to the “Unlocked” position.

5. Locate the Battery Latch that is spring-loaded. Pull back and hold.

6. Lift the battery out using the opening on side of battery compartment. Note if the hand

strap is attached you will need to rotate the D-rings out to remove the pack easily.

xTablet T1400 Users Guide

xTablet T1400 User Guide

Getting Started

Hot Swapping Batteries

The xTablet T1400 supports hot-swapping of batteries, meaning the tablet doesn’t need to be

powered off in order to replace the main battery. The xTablet T1400 has a backup battery inside

the tablet’s main battery compartment that is charged by the main battery. The backup battery

cannot be removed except in service, and needs to have adequate power for hot swapping of

main battery to be done without issue. When the backup battery is fully charged, it can sustain up

to 5 minutes of runtime, so battery swapping needs to complete in under 5 minutes.

Perform the following to hot swap the batteries:

1. While the tablet is powered on, go to HotTab utility to check on the power level of the

Backup battery.

2. If the Backup battery level is at “Low”, please charge the tablet with AC Power until the

Backup battery level is at “Medium” or “High”, and do not remove the main battery.

a. If you need to swap in this situation then shut down the tablet and then swap with a

fully charged battery which will then begin charging your backup battery.

Note: If you have used the xTablet T1400 for several hours and then put it to sleep for

several days, the main battery will be slowly depleted and may lose power all together.

If that happens, your unsaved work will be lost and date/time will need to be set when

power is restored.

3. If the Backup battery level is at “Medium” or “High”, continue to remove the main battery.

4. Insert a new fully charged removable battery into the battery compartment following the

instructions on page 9 of this manual.

5. Go to HotTab utility to check if Main battery level can be correctly read. If not, check if the

new battery is inserted properly.

6. If the Main battery level can be read, resume use the xTablet T1400.
