Mobile Edge MEABH2 Manuel utilisateur

CONTENT

Introduction / 2

1. Package Contents / 3

1.1. Product Features / 3

1.2. Product Specifications / 3

1.3. Description of Parts / 4

1.4. Charging the Battery / 4

1.5. Switching the Bluetooth Headset ON/OFF / 4

1.6. Handsfree Operations / 5 ~ 6

Troubleshooting / 7

Warranty / 7

Introduction

The Comfort Fit Bluetooth Headset is an

advanced wireless headset for Handsfree

operations. The device can be connected to

any Bluetooth phone that supports Headset or

Handsfree profile. The comfortable and soft

contoured ear piece secures the headset

along the ear wall. The Comfort Fit Bluetooth

Headset is convenient to wear and remains

comfortable even when used for extended

periods of time. With its light and elegantly

designed architecture, you can drive or walk

the streets with confidence enjoying

Handsfree. This instruction manual will get

you started!

1. Package Contents

Comfort Fit Bluetooth Headset

Charger Cradle

AC/DC Charger Adapter

Rubber Gel Ear Piece (2 sizes)

Phone clip and Lanyard

User’s Manual

1.1. Product Features

Bluetooth V1.2, 2.0 compliant

Supports Headset & Handsfree profiles

Unique contoured rubber gel ear piece

keeps headset secure in ear

High performance built-in speaker and

microphone

Red and blue LED indications for

Bluetooth operations, battery and charging

Up to 5 hours of talk time and 150 hours of

standby time

Simple to charge with the AC charger

cradle

Multifunction button (see 1.6)

1.2. Product Specifications

Weight – .33 oz.

Bluetooth V2.0

Range – 35 feet

Profiles Supported – HSP, HFP

Charger – Cradle with AC Adapter

Charge Time – 2 hours

Dimensions – 1.6” x .74” x .35”

Ear Buds – two (2) sizes

1.3. Description of Parts

1.4. Charging the Battery

Before using the headset, charge the

battery for at least 2 hours.

To charge, first connect the charger cradle

with AC/DC charger adapter and then plug

the cord into power supply. Then place the

headset onto cradle and push down until

the headset gets locked with red LED on.

While charging, the headset LED will turn

red. When fully charged, the LED will turn

blue.

1.5.Switching theBluetoothHeadset ON/OFF

To power the headset on, click and hold

the MFB until Headset LED lights up blue

and flashes blue.

To switch power off, click and hold MFB

until Headset LED lights up red and then

shuts down.

MFB

(Multi-Function

Button)

VOL UP (+)

VOL DOWN (-) LED

(2-color)

1.6. Handsfree Operations

Function

Action / Tone Indicator

Pairing

Mode

Powered OFF, click and hold MFB continuously until LED alternates red and blue.

Pairing mode lasts for approx. 3 minutes. After this period the headset returns to

standby mode.

From a Bluetooth phone, search for device and establish the connection. If

prompted for pin key, enter ‘0000.’ The LED will turn OFF once connected.

Answer Call

Short click MFB to answer call. Ringer will sound from both phone and headset.

Make Call To make a call, first dial from phone and short click MFB to switch call to headset.

Note: For some phones, call may automatically be transferred to headset.

Redial

To redial, double click MFB in idle state.

Note: When MFB is double clicked, some phones display the last number dialed

or received. Double click MFB again to redial. Some phones allow direct redialing

by double clicking MFB just once.

Voice Dial

Make sure your phone supports voice dialing and that it is activated. Ensure voice

tags have been recorded. To voice dial, press and hold MFB in idle Handsfree

mode. Follow the instructions message from your phone to complete voice

dialing.

Function

Action / Tone Indicator

Volume

Control

Click (+) or (-) to adjust volume during Handsfree mode. The tone will increase or

decrease while being adjusted.

End Call

To end a call first, press the MFB during ‘Talk Mode.’ If the other party ends the

call first, the headset automatically returns to Handsfree standby mode.

Reject Call To reject incoming call, press and hold MFB.

Call Transfer

During ‘Talk’ mode, if you want to transfer call from headset to phone or vice

versa, press the MFB.

Call Waiting

To answer second call while in ‘Talk’ mode, press the MFB twice. To switch from

second call to first call, click the MFB twice. Note: This function can only be used if

user has subscribed for this service.

Microphone

Mute

For privacy reasons, if you don’t want your voice to be transmitted to the other

party, you can mute the microphone by pressing and holding the (+) and (-)

buttons together during talk mode. To cancel mute function, press and hold (+)

and (-) buttons.

Reconnect To reconnect headset with phone, press the MFB twice.

Troubleshooting

I hear electronic static noises –

For best sound quality always wear the headset on the same

side as your mobile phone.

I can not hear anything – Increase the volume of the headset, ensure the headset is paired with

the mobile phone.

I have problems pairing even though my phone indicates it is connected –

You may have

deleted your headset pairing connection on your phone. Follow the pairing instructions in your

phone’s user manual.

Will the Comfort Fit Bluetooth Headset work with other Bluetooth devices? – The Mobile Edge

Comfort Fit Bluetooth Headset is designed to work with Bluetooth mobile phones. It will work

with other Bluetooth devices that are compliant with Bluetooth version 1.1, 1.2 and support

Headset/Handsfree profile.

Warranty

Mobile Edge is pleased to provide the original purchaser of this accessory product a warranty for

defects in material or workmanship under normal use and service for one year from the date of

purchase. If you need to make a warranty claim, please provide the original receipt, on-line

registration, or other acceptable documentation. This limited warranty does not cover any damage

due to accident, misuse, abuse or negligence. Please contact Mobile Edge Customer Service at

info@mobileedge.com or 714-399-1400 for warranty service.
