HARDWARE MANUAL

αSIMPLE APPLICATION CONTROLLER

Simple Application Controller

ENG

Foreword

• This manual contains text, diagrams and explanations which will guide the reader in the correct installation,

safe use and operation of the αSeries and should be read and understood before attempting to install or

use the unit.

• If in doubt at any stage during the installation of the αSeries always consult a professional electrical engi-

neer who is qualified and trained to the local and national standards. If in doubt about the operation or use

of the αSeries please consult the nearest Mitsubishi Electric distributor.

• This manual is subject to change without notice.

Simple Application Controller

ENG

αα

αSimple Application Controller

Hardware Manual Manual number : JY992D74201

Manual revision : H

Date : OCT 1999

Simple Application Controller

ENG

Guidelines for the safety of the user and protection of equipment

This manual is written to be used by trained and competent personnel for installation of this equipment as defined by

the European directives for machinery, low voltage and EMC. A technician or engineer trained in the local and

national electrical standards should perform all tasks associated with the electrical wiring of the αSeries controllers.

Throughout this manual symbols are used to highlight information relating to the user’s personal safety and protec-

tion of the equipment. When any of these symbols are encountered, the associated note must be read and under-

stood.

Symbols are:

1) The identified danger will cause physical and property damage.

2) The identified danger could cause physical and property damage.

• Under no circumstances will MITSUBISHI ELECTRIC be liable or responsible for any consequential damage that may arise as a

result of installation or use of this equipment.

• All example and diagrams shown in this manual are intended to aid understanding and do not guarantee operation. MITSUBISHI

ELECTRIC will accept no responsibility for actual use of this product based on these examples.

• Due to the great variety of possible applications for this equipment, the user must assess the suitability of this product for specific

applications.

• If the controller breaks for any reason, please have safety procedures in place to stop any connected equipment in a safe manner.

• Do not replace electrical parts or try to repair an αSeries product in any way.

• Please dispose of the αSeries product in accordance with local and national standards.

Simple Application Controller

iii

Table of Contents

Guideline...................................................................................................................................ii

1. Introduction............................................................................................................ 1

2. Hardware Specification.........................................................................................3

2.1 Available Models.......................................................................................................... 3

2.2 Power Supply Specification ......................................................................................... 4

2.3 Input Specification........................................................................................................ 6

2.4 Output Specification..................................................................................................... 8

2.5 General Specification................................................................................................... 9

3. Installation............................................................................................................ 11

3.1 DIN RAIL Mounting.................................................................................................... 11

3.2 Termination at Screw Terminals................................................................................ 11

3.3 Installation Mounting Notes........................................................................................ 12

ENG

Simple Application Controller

4. Wiring ................................................................................................................... 15

4.1 Installation Wiring Notes ............................................................................................ 15

4.2 Wire Size and Specifications ..................................................................................... 15

4.3 Power Supply............................................................................................................. 16

4.4 Recommended Power Input Wiring Diagram............................................................. 16

4.5 AC Input Wiring.......................................................................................................... 17

4.5.1 AC Input Wiring Diagram..................................................................................... 17

4.6 Wiring Diagrams for the Sink/Source Terminals........................................................ 18

4.6.1 Source (“+” Common) Input Wiring Diagram....................................................... 18

4.6.2 Sink ("-" Common) Input Wiring Diagram............................................................ 18

4.7 Output Relay and Transistor Wiring........................................................................... 19

4.7.1 Relay Output Wiring Diagram (AC and/or DC).................................................... 19

4.7.2 Transistor Output (Source or “+” Common Only) Wiring Diagram ...................... 20

5. α

αα

αSeries Terminal Layout.................................................................................... 21

6. How to Use α

αα

αSeries Controllers - Getting Started...........................................23

6.1 Connecting Two Blocks ............................................................................................. 23

6.2 Accessing Blocks ...................................................................................................... 24

6.3 Setting Function Block Parameters............................................................................ 25

6.4 Exiting, Running, and Stopping the Program............................................................. 25

ENG

Simple Application Controller

Introduction 1

ENG

1. Introduction

The simple, friendly αSeries has been designed for use around your home, office, factory.... anywhere that

requires a flexible supervisory control function. Every module allows you to read signals and set outputs

according to particular conditions or time settings defined by you, the user. Plus the built-in programmable

display allows you to check the status of your system anytime.

Special features of the αSeries system are:

• Direct (on-device) programming capability

• High current output capability

•Smallsize

• Easy access programming port

• EEPROM cassette program storage capability

• Built-in Real Time Clock as standard

• Windows based programming package, AL-PCS/WIN-E

• Plus a full range of support documentation and Training packages

The αSeries is designed to be used in the following automatic applications: lighting, air conditioning,

irrigation, doors, gates, simple security systems, greenhouses, air fans, etc. The Real Time Clock can be

used as a power saving device to automatically turn the equipment On/Off at scheduled times.

Debug programs carefully before installing in automated equipment. The αSeries is not designed to be used

in life critical or fail safe applications.

Contact your dealer for more information.

Simple Application Controller

Introduction 1

ENG

Simple Application Controller

Hardware Specification 2

ENG

2. Hardware Specification

2.1 Available Models

* Without Special Connection Modules.

Table 2.1:Model Table

Model Power Supply Input Output Dimensions Weight

Type Number Type Number mm (inches) kg (lbs)

AL-6MR-A 100 - 240V

AC~ 100 - 240V

AC~ 4 RELAY 2 71.2 x 90 x 55

(2.80 x 3.54 x

2.17)

0.20

(0.44)

AL-10MR-A 6 RELAY 4

AL-10MR-D 24V DC 24V DC

Sink/Source 6 RELAY 4

AL-10MT-D 6 TRANSISTOR 4

AL-20MR-A 100 - 240V

AC~ 100 - 240V

AC~ 12 RELAY 8 124.6 x 90 x 55

(4.91 x 3.54 x

2.17)

0.32

(0.70)*

AL-20MR-D 24V DC 24V DC

Sink/Source 12 RELAY 8

AL-20MT-D 12 TRANSISTOR 8

Simple Application Controller

Hardware Specification 2

ENG

2.2 Power Supply Specification

Table 2.2: Power Supply Specifications

Description Code Specification

Power Supply AL -***-A 100 - 240V AC~, +10% -15%, 50 - 60 Hz

AL-***-D 24V DC, +20% -15%

Maximum Momentary Power

Failure AL-***-A 10ms

AL-***-D 5ms

In-rush Current 240V AC~ (120V AC~) < 1.5 Amp (0.7 Amp)

24 V DC < 7.0 Amp

Maximum Power Consumption

(without Special Connection

Modules)

AL-6MR-A, 264V AC~ 3.0 W

AL-10MR-A, 264V AC~ 4.0 W

AL-10MR-D, 28.8V DC 3.0 W

AL-10MT-D, 28.8V DC 2.0 W

AL-20MR-A, 264V AC~ 8.0 W

AL-20MR-D, 28.8V DC 7.0 W

AL-20MT-D, 28.8V DC 5.0 W
