Mitsubishi AJ65SBT2B-64RD3 Manuel utilisateur

User’s Manual

(Hardware)

AJ65SBT2B-64RD3

Thank you for purchasing the Mitsubishi programmable controller .

RTD Input Module

Prior to use, please read this and relevant manuals thorougly to fully

understand the product.

MODEL AJ65S-64RD3-U-HW

MODEL

CODE 13JY77

IB(NA)-0800420-A(0805)MEE

A-1

SAFETY PRECAUTIONS

(Be sure to read these instructions before use.)

Before using this product, please read this manual and the relevant manuals

introduced in this manual carefully and pay full attention to safety to handle the

product correctly.

The instructions given in this manual are concerned with this product. For the

safety instructions of the programmable controller system, please read the CPU

module user’s manual.

In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".

Note that the CAUTION level may lead to a serious consequence according

to the circumstances.

Always follow the instructions of both levels because they are important to

personal safety.

Please save this manual to make it accessible when required and always forward

it to the end user.

DANGER

Indicates that incorrect handling may cause

hazardous conditions, resulting in death or severe

injury.

Indicates that incorrect handling may cause

hazardous conditions, resulting in minor or moderate

injury or property damage.

CAUTION

A-2

[Design Precautions]

[Installation Precautions]

DANGER

In the case of a data link error, the master module data is backed up.

Using the communication status information, create an interlock circuit on the

sequence program for the system to operate safely.

CAUTION

Do not install the control or communication cable(s) together with the main

circuit or power cables.

Keep a distance of 100mm or more between them.

Failure to do so may cause malfunctions due to noise.

CAUTION

Use the module in an environment that meets the general specifications

given in this manual.

Operating it in any other environment may cause an electric shock, fire,

malfunction, product damage or deterioration.

For protection of the switches, do not remove the cushioning material before

installation.

Securely fix the module with the DIN rail or fixing screws. Fixing screws must

be tighten within the specified torque range.

A loose screw may cause a drop of the module or malfunction.

Overtightening may damage the screw, resulting in a drop or malfunction of

the module.

Do not directly touch any conductive part of the module.

Doing so may result in a malfunction or failure of the module.

A-3

[Wiring Precautions]

CAUTION

Be sure to shut off all phases of the external power supply used by the

system before installation or wiring.

Failure to do so may cause a damage to the product and/or malfunctions.

Always ground the FG terminal to the protective ground conductor.

Failure to do so may result in malfunctions.

Be sure to tighten any unused terminal screws within a tightening torque

range.

Failure to do so may cause a short circuit due to contact with a solderless

terminal.

Use applicable solderless terminals and tighten them with the specified

torque.

If any solderless spade terminal is used, it may be disconnected when the

terminal screw comes loose, resulting in failure.

Check the rated voltage and terminal layout and then wire the module

correctly.

Connecting a power supply of a different voltage rating or incorrect wiring

may cause a fire or failure.

Tighten terminal screws within the specified torque range.

A loose terminal screw may cause a short circuit or malfunction.

Overtightening can cause a short circuit or malfunction due to damage of the

screws or module.

Take care to prevent foreign matter such as dust or wire chips from entering

the module.

Failure to do so may cause a fire, failure or malfunctions.

Place the connection wires and cables in a duct or clamp them.

If not, dangling cables may swing or inadvertently be pulled, resulting in

damage to the module and/or cables or malfunctions due to poor cable

connection.

A-4

[Wiring Precautions]

[Starting and Maintenance Precautions]

[Disposal Precautions]

CAUTION

Do not install the control cable(s) together with the communication cable(s).

Doing so may cause malfunctions due to noise.

When disconnecting the cables from the module, do not hold and pull the

cable part.

Disconnect the cables after loosening the screws in the portions connected

to the module.

Pulling the cable that is still connected to the module may damage the

module and/or cable and cause malfunctions due to poor cable connection.

CAUTION

Do not touch the terminals while the power is on.

Doing so may cause malfunction.

Be sure to shut off all phases of the external power supply used by the

system before cleaning or retightening the terminal screws.

Not doing so can cause the module to fail or malfunction.

Undertightening can cause a drop, short circuit or malfunction.

Overtightening can cause a drop, short circuit or malfunction due to damage

of the screws or module.

Never disassemble or modify the module.

This may cause breakdowns, malfunction, injury and/or fire.

Do not drop or apply any strong impact to the module.

Doing so may damage the module.

Be sure to shut off all phases of the external power supply used by the

system before mounting or dismounting the module to or from the panel.

Not doing so can cause the module to fail or malfunction.

Do not install/remove the terminal block more than 50 times after the first use

of the product. (IEC 61131-2 compliant)

Before handling the module, always touch grounded metal, etc. to discharge

static electricity from the human body.

Failure to do so can cause the module to fail or malfunction.

CAUTION

When disposing of this product, treat it as industrial waste.

A-5

Revisions

* The manual number is given on the bottom right of the cover.

Print Date *Manual Number Revision

May, 2008 IB(NA)-0800420-A First edition

This manual confers no industrial property rights or any rights of any other kind, nor does it

confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any

problems involving industrial property rights which may occur as a result of using the contents

noted in this manual.

A-6

CONTENTS

1. OVERVIEW..................................................................................................... 1

2. SPECIFICATIONS .......................................................................................... 2

2.1 General Specifications..............................................................................2

2.2 Performance Specifications...................................................................... 3

3. PART NAMES AND SETTINGS ..................................................................... 6

3.1 Part Names............................................................................................... 6

4. LOADING AND INSTALLATION..................................................................... 9

4.1 Handling Precautions ............................................................................... 9

5. DATA LINK CABLE WIRING ........................................................................ 11

5.1 Wiring Precautions ................................................................................. 11

5.2 CC-Link Dedicated Cable Connection Method.......................................11

5.3 Connection of Terminating Resistor ....................................................... 11

6. WIRING......................................................................................................... 12

6.1 Wiring Precautions ................................................................................. 12

6.2 Wiring with RTD...................................................................................... 12

7. EXTERNAL DIMENSIONS ........................................................................... 13

A-7

About Manuals

The following manuals are also related to this product.

If necessary, place an order.

COMPLIANCE WITH THE EMC AND LOW VOLTAGE DIRECTIVES

(1) For programmable controller system

To configure a system meeting the requirements of the EMC and

Low Voltage Directives when incorporating the Mitsubishi

programmable controller (EMC and Low Voltage Directives

compliant) into other machinery or equipment, refer to the "EMC

AND LOW VOLTAGE DIRECTIVES" chapter of the User's Manual

for the CPU module used.

The CE mark, indicating compliance with the EMC and Low Voltage

Directives, is printed on the rating plate of the programmable

controller.

(2) For the product

For the compliance of this product with the EMC and Low Voltage

Directives, refer to the "CC-Link module" section in the "EMC AND

LOW VOLTAGE DIRECTIVES" chapter of the User's Manual for

the CPU module used.

Related Manuals

Manual name Manual Number

(Model code)

RTD Input Module Type AJ65SBT2B-64RD3 User's Manual SH-080770ENG

(13JZ21)

1. OVERVIEW

This user's manual explains the specifications, names of the

components and wiring for the type AJ65SBT2B-64RD3 RTD Input

Module (hereafter AJ65SBT2B-64RD3) which are used as a remote

device station of a CC-Link system.

2. SPECIFICATIONS

2.1 General Specifications

The general specifications for the AJ65SBT2B-64RD3 are shown in the

following table.

*1 It indicates the device is to be connected to which power distribution part,

within the area from the public electricity network to machinery in the

premise. Category II applies to devices to which power is supplied from fixed

installations.

The surge voltage withstand for devices rated up to 300V is 2500V.

*2 This is an index showing the degree of the conductive pollution that can

occur in the environment where the device is used.

In Pollution degree 2, only nonconductive pollution occurs. Occasionally,

however, temporary conductivity caused by condensation can be expected.

*3 Do not operate or store the programmable controller in the environment

where the pressure applied is equal to greater than the atmospheric pressure

at the altitude of 0m. Doing so may cause a malfunction. Please consult our

branch office when the programmable controller is to be operated under

pressure.

Table 2.1 General specifications

Item Specification

Operating ambient

temperature 0 to 55

Storage ambient

temperature -20 to 75

Operating ambient humidity 10 to 90%RH, condensation not allowed

Storage ambient humidity 10 to 90%RH, condensation not allowed

Vibration resistance

Compliant

with JIS B

3502,

IEC 61131-2

For intermittent vibration No. of

sweeps

Frequency Acceleration Amplitude

10 to 57Hz - 0.075mm 10 times

each in X,

Y and Z

directions

(for 80

minutes)

57 to 150Hz 9.8m/s2-

For continuous vibration

Frequency Acceleration Amplitude

10 to 57Hz - 0.035mm

57 to 150Hz 4.9m/s2-

Shock resistance Compliant with JIS B 3502, IEC 61131-2 (147m/s2, 3 times each

in X, Y and Z directions)

Operating atmosphere No corrosive gases

Operating altitude *3 2000m or lower

Installation location Inside control panel

Overvoltage category *1 II or lower

Pollution degree *2 2 or lower

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Mitsubishi Contrôleurs

Mitsubishi

Mitsubishi QD75P1N Manuel utilisateur

Mitsubishi

Mitsubishi Q00JCPU Manuel utilisateur

Mitsubishi

Mitsubishi FX3U Series Manuel utilisateur

Mitsubishi

Mitsubishi FX2NC DSS Series Manuel utilisateur

Mitsubishi

Mitsubishi FX2N-64CL-M Manuel utilisateur

Mitsubishi

Mitsubishi FX2NC-485ADP Manuel utilisateur

Mitsubishi

Mitsubishi FX3U-20SSC-H Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC System Q Manuel du propriétaire

Mitsubishi

Mitsubishi MELSEC-F FX3U-4AD-TC-ADP Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC-F FX3U-4AD-TC-ADP Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC Q Series Manuel utilisateur

Mitsubishi

Mitsubishi q64rd Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC-A Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC Q Series Manuel du propriétaire

Mitsubishi

Mitsubishi FX3U-4AD-PNK-ADP Manuel utilisateur

Mitsubishi

Mitsubishi FX0N-16NT Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC-QnA Series Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC-L Series Manuel du propriétaire

Mitsubishi

Mitsubishi FX2N-20GM Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC-Q EQ-V680D1 Manuel utilisateur

Mitsubishi

Mitsubishi CR750-Q Series Manuel utilisateur

Mitsubishi

Mitsubishi QD70P4 Manuel utilisateur

Mitsubishi

Mitsubishi FX2N series Manuel utilisateur

Mitsubishi

Mitsubishi MELSEC Q Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
