Mitsubishi Electric Apricot MS660 Guide de l'utilisateur

QUICK

START

GUIDE

Includes a

COMPACT

MS660

Owner’s Handbook

NATIONAL

ACCREDITATION

OF CERTIFICATION

BODIES

Up and running in a few minutes

COMPACT

QUICK

START

GUIDE

BRUNO-QS.PM5 29/11/96, 09:451

When you have fully

connected your system

press thePower button to

turn the computer on.

When the system unit

is powered the power

indicator on the left of

the front panel will light

up. If nothing happens,

check your connections and

supply switch.

Refer to the “Troubleshooting” chapter in the Owner’s Handbook if you

encounter any problems.

Power Up

Remember that the monitor has its own power switch; see the monitor’s

User’s Guide for details.

The Standby button can be used to both place the system into an energy

saving mode or restore it to

normal operation. Next

to this button is an

LED which lights

up during either of

the Energy Saving

modes. Further

details are provided

on the last page of this

guide.

The system will now perform a self-test routine and then display the message,

‘Starting Windows 95’. This will take several minutes the first time you

switch on, during which time the computer will reboot several times

and you will be requested to register your copy of Windows 95.

COMPACT

BRUNO-QS.PM5 29/11/96, 09:462

Pressing the red button while this window is displayed provides access to

the remote control’s help file. To hide the remote status window, press the

MENU button on the remote control again.

The Remote Control

The optional infra-red remote

control offers a friendly user-

interface to the inexperienced user.

The remote control operates on two

AA batteries, which are provided.

You need to insert the batteries into the remote

control unit in order to use it. Use the diagram

opposite to insert the batteries.

The remote control has an integral two-button

mouse to control the major functions of the

multimedia applications.

Pressing the MENU button on the

remote control displays the

remote status window.

The remote status

window (shown below)

provides you with

information on the

current status of the

remote-controlled

program.

For example, here is the remote status window for the CD player:

BRUNO-QS.PM5 29/11/96, 09:463

VOL

REVEAL

ENLARGE HOLD

T TEXT START

123

456

789

STANDBY: puts the PC into, or restores it from

energy saving mode. Further details on the energy

saving capabilities of your computer are provided

on the last page of this section.

If your computer has a TV card fitted, pressing

the TV button on the remote control for the

first time will activate the TV Wizard. This will

guide you through tuning into your local

transmitter.

MESSAGE: launches the Message Centre

application for accessing the various message types.

The Message LED on the front panel of the

computer will be lit when you have received any

new messages.

TTEXT: launches the TV application in full-screen

Teletext mode.

START: Displays the main menu to start a program,

find a file, or get help.

The coloured buttons can be used:

lIn Teletext mode where they are used to drive

the Fasttext capabilities of the application.

lTo control Apricot Easy Manager applications.

lOutside Apricot Easy Manager, the coloured buttons act as shortcuts

for common Windows actions. That is:

OK and CANCEL to accept/decline changes.

EXIT to close any application.

TASK changes focus between Windows applications. That is, it has

the same functionality as the Windows ALT-TAB command, which

switches between the windows you have opened.

Refer to the on-line tutorial, which can be found in the Apricot

Remote Control help file, for futher details.

BRUNO-QS.PM5 29/11/96, 09:474

3Playing Games

To play any of the games provided, you

need to insert the appropriate CD into

the CD-ROM drive. Press the button

on the front of the drive and place the

CD label-up on the platter.

Push the button again, or gently push

the front of the platter to draw it

back into the drive.

Using your remote control, press the

MENU button to display the status

window. Then, press the corresponding

coloured button labelled ‘Games’ to load the

Entertainment Centre screen as shown below:

COMPACT

You can select any of the games by clicking the labelled coloured button

with your mouse, or by pressing the appropriate coloured button on the

remote control. Some games will require the system to run in DOS-only

mode. Where this is the case Windows 95 will shut down and reboot in

DOS mode for the duration of the game. Remember to exit the game properly

and restore Windows 95 before you switch the system off.

The pictures of the software shown above are for example purposes only,

actual software may vary.

BRUNO-QS.PM5 29/11/96, 09:495

4Please remember...

This computer system is shipped with the latest Energy Star power-saving features

already activated, allowing you to be more environmentally friendly in your

work. It is intended to help reduce global power consumption, and ultimately

waste and pollution. This computer system is designed, when left unattended,

to enter a ‘Low Power’ mode followed by ‘Standby’ mode shortly afterwards.

LOW POWER MODE

In this state the screen will be blank but your software will still be running,

although it will run much slower.

You can Restore the system by moving the mouse, pressing any keyboard key, or

by pressing the purple STANDBY button on either the front panel, or the

remote control.The computer will quickly restore to the state in which you left

it. The monitor may take a few seconds to warm up again.

STANDBY MODE

In this state the monitor will be in a controlled ‘off’ state. The system and

software will assume a frozen state. You will not lose any unsaved data, unless

your mains electricity supply fails. The system fans will slow down or stop

altogether.

You can Restore the system by pressing the purple STANDBY button on the

front panel of the system or the one on the remote control. The computer will

quickly restore to the state in which you left it. The monitor may take a few

seconds to warm up again.

NOTE

Pressing either of the STANDBY buttons when the system is in normal use will

put the system directly into standby mode.

You can change any of the above settings. How to

access the Apricot power Manager is shown in the

chapter ‘The multimedia applications’. Refer also to

the application’s help file.

BRUNO-QS.PM5 29/11/96, 09:506

OWNER’S HANDBOOK

APRICOT MS660

Intel, ‘Pentium®’ and ‘Pentium®with MMXTM technology’ are registered

trademarks of Intel Corporation.

Microsoft, MS-DOS, Windows®and Windows®95 are registered trademarks of

Microsoft Corporation in the US and other countries.

Other trademarks mentioned within this document and not listed above are the

properties of their respective owners.

Information contained in this document is subject to change without notice and

does not represent a commitment on the part of Apricot Computers Limited.

Any software described in this manual is furnished under a license agreement.

The software may be used or copied only in accordance with the terms of this

agreement. It is against the law to copy any disk supplied for any purpose

other than the purchaser’s personal use.

No part of this manual may be reproduced or transmitted in any form or by any

means electronic or mechanical including photocopying and recording, for any

purpose, without the express written permission of the publishers.

Published by:

Apricot Computers Limited

3500 Parkside

Birmingham Business Park

Birmingham, England

B37 7YS

http://www.apricot.co.uk

Printed in the United Kingdom

CONTENTS 1

CONTENTS

Safety and regulatory notices

General i

Standards ii

Power connection guidance iii

Power cable wiring UK ONLY iv

1 Introducing your computer

Your multimedia computer 1/1

Energy-efficient features 1/2

Pictorial guides 1/3

Removing panels 1/6

The internal layout 1/8

2 Using your computer

Using the 3.5 diskette drive 2/1

Using the CD-ROM drive 2/3

Using the (optional) PD drive 2/7

Cleaning your drives 2/9

The sound connections 2/10

The speaker sound system 2/12

Customising your display settings 2/13

The hard disk drives 2/14

Software backup 2/14

Using help 2/15

3 First use of Internet and ‘Branding’

Setting up your FREE Internet/Fax 3/1

‘Branding’ your computer 3/3

4 The multimedia applications

Media Manager application 4/1

Message Centre application 4/3

Entertainment application 4/4

Power Manager application 4/5

Internet Connection application 4/6

TV/Teletext application 4/7
