Mitel 480 Manuel utilisateur

1

2

2

1

Adjusng the Viewing Angle of the Phone

(Oponal)

The IP Phone stand supports two lt angles for the phone on desk.

The stand is shipped in the low posion. Use these instrucons to change the lt angle.

Remove the Stand:

1. Grasp the phone base in one hand and the stand in the other.

2. Pull the stand o the base unl it unsnaps.

Replace the Stand:

1. Rotate the stand 180 degrees. Seat the stand rmly in the hooks.

2. Push the stand into the base unl it snaps into place.

Connecng to Power over Ethernet

Required Items:

l Ethernet cable for IP Phone (included)

l Network wall port that supports power or Power over Ethernet (PoE)

Note: This conguraon describes a Power over Ethernet connecon. Refer to Connecng to Power

and the Network on page 2 if your network wall port or data switch does not support Power over

Ethernet.

IP Phone 480/480g/485g

Quick Install Guide

Connecng a Headset (Oponal)

The IP Phone supports use of an oponal Headset, as shown. Aer connecng the headset,

select the Headset buon on the front panel of the IP Phone.

Remove Replace

Copyright © 2017 Mitel Networks Corporaon. All Rights Reserved. The Mitel word and logo are trademarks of Mitel Networks Corporaon.

Any reference to third-party trademarks is for reference only and Mitel makes no representaon of ownership of these marks.

Part Number: 800-1540-10

41

Connect Power over Ethernet:

1. Connect one end of the Ethernet cable to the Ethernet port on the IP Phone.

2. Connect the other end of the Ethernet cable to a network wall port that supports Power over

Ethernet. Aer a few seconds, the IP Phone powers on and runs through a series of system tests.

Note: IP Phone 480 supports 10/100 Ethernet network speed. IP Phones 480g/485g support 10/100/1000 network speed.

Low angle High angle

1

2

4

5

12 3

AB

3

2

1

C

Connecng to Power and the Network

Required Items for connecng to Power and the Network:

l PoE (Power over Ethernet) Adapter. One Ethernet cable and AC power cable included.

l Ethernet cable for connecng IP Phone to PoE Adapter (included with phone)

Note: This conguraon requires a PoE adapter and two Ethernet cables.

Refer to Connecng to Power over Ethernet on page 1 if your network wall port

supports Power over Ethernet.

Connecng to a Computer (Oponal)

The IP Phone supports connecng to a PC or laptop.

Required Items for connecng the IP Phone to a computer:

l Computer

l Ethernet cable for connecng IP Phone to computer (not included)

3

2

Connect to Power and the Network:

1. Connect one end of ETHERNET CABLE A to the Ethernet port on the IP Phone.

2. Connect the other end of ETHERNET CABLE A to the DATA AND POWER OUT port on the PoE

adapter.

3. Connect one end of ETHERNET CABLE B to the DATA IN port on the PoE adapter.

4. Connect the other end of ETHERNET CABLE B to a network wall port.

5. Connect power from the PoE adapter to an appropriate power source. Aer a few

seconds, the IP Phone powers on and runs through a series of system tests.

Connect to a Computer:

1. Follow instrucons Connecng to Power over Ethernet on page 1 or Connecng to Power and

the Network on page 2.

2. Connect one end of ETHERNET CABLE C to the PC port on the IP Phone.

3. Connect the other end of ETHERNET CABLE C to the Ethernet port on a PC or laptop.
