Mio GPS Car Kit Manuel utilisateur

Welcome

Thank you for using GPS Car Kit. This Quick Start Guide

guides you through a successful setup.

WARNING: Always press the release button whenever

adjusting the retaining arm.

For more information on the GPS Car Kit, go to

www.mio.com

Status LED

Volume

Control

Adjustment

Block. Back

Support

Adjustment

Switch on back.

Retaining Arm

Release

Button

Audio Aux

Output

Power

(USB)

Speake

Multifunction switch on back

Installation

Please do not place your iPhone® or iPod touch® into

the GPS Car Kit until instructed to do so.

Assembling

Assemble the GPS Car Kit as shown. Do not tighten the

retaining ring.

Press the unlock button and raise the retaining arm all

the way to the top.

Inserting your iPhone into the GPS Car Kit

Slide your iPhone or iPod touch into the connector on

the bottom of the GPS Car Kit and then gently push

your iPhone or iPod touch towards the GPS Car Kit.

Press the release button and push down on the

retaining arm to lock your iPhone or iPod touch in

place.

Checking for an uneven gap

The gap between the iPhone or iPod touch and the GPS

Car Kit should be even. If it is uneven, you can slide the

adjustment switch on the back to push out the

adjustment block until the gap at the top is the same as

the gap at the bottom.

Retaining Ring

Cradle Holde

(Please note that if it is still uneven, you will need to

remove your device. Then pull out the adjustment

block, rotate it 180º and place it back in the GPS Car

Kit. This will increase the thickness of the adjustment

block.)

Mounting the GPS Car Kit in your vehicle

Before mounting the GPS Car Kit you should remove

your iPhone or iPod touch by lifting the front tab on the

retaining arm and rotating your iPhone slightly forward.

When mounting the GPS Car Kit in your vehicle please

keep these important guidelines in mind...

Check local vehicle laws regarding mounting

devices on windshields.

Make sure not to mount the GPS Car Kit where it

could be dislodged should your airbags deploy.

Likewise, make sure that the power cable would

not be dislodged should the airbags deploy.

Clean the area where the GPS Car Kit will be placed.

Dry the area thoroughly before continuing.

Press the GPS Car Kit base firmly against the windshield

or dash surface.

Push the suction cup arm down, locking the GPS Car Kit

to the surface.

Applying power

Connect the USB end of the power cable to the GPS

Car Kit. Connect the other end of the cable to a vehicle

power receptacle.

Reinstall your iPhone into the GPS Car Kit and adjust

for proper viewing.

When making viewing adjustments, always hold the

assembly by the GPS Car Kit and not your iPhone.

Make any final adjustments for proper viewing and

tighten the retaining ring.

Bluetooth®pairing

When the GPS Car Kit is first powered on, Bluetooth is

automatically set to discovery mode and ready to pair

with a new device.

1. Connect the GPS Car Kit to power.

2. In the iPhone Settings Menu, turn on BlueTooth.

3. Under Devices, select “Mio GPS Car Kit.”

4. When prompted to pair with the GPS Car Kit, press

Yes.

5. GPS Car Kit will connect with your iPhone.

6. Pairing is now complete.

Once paired, the GPS Car Kit will automatically connect

with the iPhone when it is in range.

Declaration of Conformity

For regulatory identification purposes, GPS Car

Kit is assigned a model number of N269.

Hereby, Mio Technology declares that this N269 is in compliance

with the essential requirements and other relevant provisions of

Directive 1999/5/EC.

Visit Mio website (mio.com) for the full text of the declaration

for your device.

All brand and product names are trademarks or registered

trademarks of their respective companies.
