MiniFinder Pico Lite Manuel utilisateur
MiniFinder®Pico Lite
User Manual
English
© 2020 MiniFidner® All rights reserved
Updated: 2019/12/11
User Manual
www.mininder.com 1of 16
minifinder pico lite
Thank you for purchasing a MiniFinder®product. We believe you made the right choice. MiniFinder®
Pico Lite is full of smart features that help you monitor, protect and locate your loved ones remotely.
Before you start using your Pico Lite, please read this manual in its entirety.
Thank you!
CONTENTS OF THE PACKAGE
1. MiniFinder Pico Lite
2. Micro USB Charging Cable
3. Power Adapter
2
23
4
3
4. Charging Station
1
1
PRODUCT OVERVIEW
2. GPS LED Light
3. Lanyard Attachment
1. GSM LED Light
4. Charging Contact Pins
3
4
1
2
User Manual
www.mininder.com 2of 16
minifinder pico lite
SIM CARD INSTALLATION
Device needs to be equipped with a SIM-card bofore it can operate.
Note! Only authorized MiniFinder retailer may install the SIM card. SIM card with activated PIN code
will not work with MiniFinder devices.
PRODUCT MANAGEMENT
A. Please charge your device for 4 hours before rst-time use.
B. During charging, the blue LED light (or the red light on the charging station) will be solid on.
C. The blue LED light (or the red lamp on the charging station) is off when the device is fully charged.
The device is charged through the supplied charging station. Connect the charging station to a
power source via the supplied USB cable and power adapter. Place the MiniFinder Pico Lite in the
charging station to charge. See picture below:
GSM LED Light
GPS LED Light
GSM LED Light
GPS LED Light Lanyard Attachment
Charging Station
Lanyard Attachment
User Manual
www.mininder.com 3of 16
minifinder pico lite
EXPLANATION OF LED LIGHTS
DOWNLOAD MINIFINDER GO APP
To set up and track your MiniFinder®Pico Lite, you need to download MiniFinder GO Tracking System APP.
Download the app by searching the “MiniFinder GO GPS Tracking” in Apple App Store
or Google Play store. Install the app to log in with your created or assigned login details.
If you read the documentation on your mobile phone, please click on the link below to download
the APP.
Apple iPhone: https://apple.co/2P3oYxN Android: http://bit.ly/2IengsS
Steady light =
No or faulty SIM card
Single blink =
Connected to GSM network
3 sec
Double blink =
Connected to GPRS network
3 sec
Slow blink =
Searching for GSM network
1 sec
GREEN LED:
BLUE LED:
3 sec Single blink =
Connected to satellite
1 sec Slow blink =
Searching for GPS signal
Steady blink =
Charging
No light =
Sleep mode or fully charged
User Manual
www.mininder.com 4of 16
minifinder pico lite
APP Overview
After logging in the MiniFinder GO APP, you will see the view as shown below.
This consists of 10 different parts:
1. Menu (Device list)
2. Alarm notication
3. Show map
4. Create / Edit GeoFence
5. Applications settings
6. Application info & Help
7. View the position of my mobile phone
8. Zoom in / out
9. View street information of a selected GPS device
10. GPS device location indication on the map
Menu/Device List
Click the menu icon to open the menu. The menu consists of one or more devices (GPSs) depending
on how many licenses you have in the system.
1. Unit name
2. Time for the last position
3. Status icons:
Battery, GPS signal, GSM signal and motion
4. Action menu (history, settings, ...)
User Manual
www.mininder.com 5of 16
minifinder pico lite
Device Status
A GPS unit can have three different colors indicating status. Green (Online), Orange (Passive),
Red (Passive) and White (Ofine).
A) Green: The device is online and sending position right now.
B) Orange: The device is passive and has sent last position more than 10 minutes ago.
C) Red: The device is passive and has sent last position more than 1 hour ago.
D) White: The device is ofine.
Action Menu
At the far right of the row of units is an Action Menu (three vertical points). In the Action Menu you
can see history (History), call (Call) and settings (Setup).
Regardless of the device’s status, you can always press the device row to display the latest
position on the map.
Lite
User Manual
www.mininder.com 6of 16
minifinder pico lite
Alarm Notication
MiniFinder GO APP supports various types of alarms: Geofence alarm, Fall alarm, SOS / Panic alarm,
Low battery alarm and speeding alarm. All alarms send an alarm notication to the phone’s or tablet’s
screen. Audio alert, vibration and ashing alarm can be activated when opening the APP.
Images below show examples of alarm notications:
- An example of notications on a phone´s screen. - A ashing bell at the top right corner of the app.
- Click on the ashing alarm bell to see active alarms.
Click on active alarms to conrm and move them to the alarm history.
History
See positioning history on the map based on date and time.
- Start by clicking the Action Menu (1), then click “History” (2).
- Select a time period and then click “View History” to display the device’s positioning history.
- To clear the history information, click “Clear Hisotry”.
Lite
User Manual
www.mininder.com 7of 16
minifinder pico lite
Fall Alarm
An accidental fall can cause devastating consequences. When an accidental fall occurs, the MiniFinder®
remote sensor sends an alarm to the APP in the form of an alarm notication on the mobile device’s
screen and an alarm bell in the APP.
To enable the Fall Alarm, click the Action Menu (1) and then select “Setup” (2).
Activate “Fall Alarm” as shown above and click ”Apply” to save the settings.
Power Saving Mode
Rename Device
Edit device name through Device Setting.
Click the Action Menu (1) and then click on the “Setup” (2). Edit device name (3) with your preference.
Then click “Apply”(4) to save the changes.
Pico Lite
Lite
Lite
User Manual
www.mininder.com 8of 16
minifinder pico lite
Low Battery Alarm
If a device’s battery level falls below 20%, you are alerted with an alarm notication and the
battery icon in the menu starts ashing to indicate low battery level.
- To activate Low Battery Alarm, click Action Menu, and select the “Setup”.
- Turn on “Low Battery Alarm” and then click “Apply” to save the settings.
Power Saving Mode
Power Saving Mode is an effective way to optimize battery life. GPS and GSM modules will only be
activated in case of an alarm or event occurs, otherwise, stay deactivated.
Enable deep sleep mode by clicking on the Action Menu and then selecting “Setup”. Turn on “Power
Saving Mode” and then click “Apply” to save the settings.
Power Saving Mode
User Manual
www.mininder.com 9of 16
minifinder pico lite
Speeding Alarm
Click Action Menu (1) of the device that you want to set Speeding Alarm to, and then click “Setup” (2).
Activate ”Speeding Alarm” (1). Drag the circle to a desired speed (2). Finally, click “Apply” (3) to
set the alarm for speeding.
Position Update Interval
The device can be tracked by different time interval depending on different requirements. Longer time
interval consumes less battery usage.
To change the update interval, click on the Action Menu and select “Setup”. Then click “Position Update
Interval”, select a desired interval and click “Apply” to save the settings.
