Minicraft Models USAF F-15A Manuel utilisateur

1 2

14693

Cement Do Not Cement Symmetrical L/ROptional

Your MINICRAFT F15A includes optional parts for a 'stationary' or 'ground' version with extended landing gear, or 'in-flight' versions. Optional armament of Sparrow

missiles are provided, as well as optional drop tanks. Please review the assembly steps to become familiar with the parts before beginning assembly.

PARTS LAYOUT DIAGRAM

3IN-FLIGHT VERSION

STATIONARY VERSION

BOTH VERSIONS

(Stationary version ONLY)

Add noseweight

Exhausts BURNT METAL

Cockpit interior DARK GRAY

15 (Shown in place)

Canopy

Missiles WHITE

Drop tank LIGHT GRAY

Struts/hubs/wheel well and door interiors WHITE

Tires FLAT BLACK-GRAY

Note alignment angle

NOTE

Missile and drop tank installation

is same for in-flight

or stationary versions.

NOTE

Missiles 10 shown in place

on starboard (right) side

Cut

6 5

987

(4x)

18 18

17 16

Canopy

USAF F-15A, Prototype, USAF St. Louis, MO, 1982

14693

PAINTS

A White (ModelMaster 1745, Acryl 4696)

B Blue FS15052 (ModelMaster 2727, Acryl 4661)

C Jet Exhaust (ModelMaster 1796, Acryl 4676)

D FS36320 Dark Ghost Gray (ModelMaster 1741, Acryl 4761)

E FS36375 Light Ghost Gray (ModelMaster 1728, Acryl 4762)

USAF F-15A, Bitburg AB, Germany, 1977

14693

Your Minicraft model includes high-quality waterslide decals. These decals adhere best

to a glossy surface; and it is recommended that you apply a clear gloss coat over your

painted model.

Use a sharp scissors or knife to cut individual decals from the carrier sheet. Do not cut

into the clear film surrounding the individual decals.

* It is recommended that you apply one decal at a time.

* Place the decal section in warm water, when first inserted in the water your decal will

curl, after approximately ten seconds the decal will uncurl. Remove from water and lay

on a paper towel. After approximately 10 - 20 seconds the decal will slide freely from the

backing paper. Use a small brush to help slide the decal from the backing paper and into

position on the model. Carefully blot excess water from the decal, using care not to move

the decal or tear it.

* If you choose to use a setting solution, apply a thin coat over the decal following the

manufacturer’s instruction.

* Allow the decal to dry overnight. Wash any adhesive residue off the model with a small

amount of clean water and dry thoroughly.

* Apply clear gloss, matte or flat coat to seal decals following the instructions from the

manufacturer.

Visit our Website-

www.minicraftmodels.com

Minicraft Models (US) LLC

1501 Commerce Drive

Elgin, IL 60123

Phone: 847-429-9676

Printed in China
