Mini Gadgets OmniRadar Manuel utilisateur
1 Version 1.4
OmniEye Radar Detector with
Hidden Camera
SKU: OmniRadar
2 Version 1.4
THANK YOU FOR PURCHASING THE OMNIRADAR HIDDEN
CAMERA
Please read this manual before operating the camera
and keep it handy.
Your purchase should include:
1 x OmniRadar
1 x AC Wall Charger
1 x Manual
1 x A/V Cable
1 x 3.5mm to USB Cable
1 x Remote
1 x 16GB MicroSD Card
1 x MicroSD Card Reader
3 Version 1.4
GET FAMILIAR WITH YOUR OMNIRADAR HIDDEN
CAMERA
4 Version 1.4
5 Version 1.4
6 Version 1.4
7 Version 1.4
IMPORTANT WARRANY INFORMATION: If the
warranty sticker on your device has been removed or
tampered with, your lifetime warranty will be voided.
You may be charged fees or denied a return should this
happen.
HOW TO CHARGE THE CAMERA
Note: If you are not located in the US, or if you intend
to use this product anywhere other than the US, you
will need to purchase a converter in order to use the AC
wall plug in and avoid damaging the product. Because
different countries use different voltages in their
electrical wiring, you will need a converter that adapts
to the current in your particular country.
The OmniRadar operates by battery only:
1. Connect the 3.5mm cable to the included AC
Wall Adapter.
2. Connect the other end of the cable to the
device’s DC port.
8 Version 1.4
3. Plug the AC Wall Adapter into a functional wall
outlet. Please allow the device to charge 6-8
hours.
OPERATING THE CAMERA
HOW TO TURN ON THE CAMERA
1. Once your device has finished charging, unplug
it from its cables.
2. Press the Power Button on the included
remote. The Indicator Light on the top of the
device (near the mount) will blink green once,
then blink red 3 more times and turn off (if
motion is detected immediately). The device is
now in motion detection mode.
NOTE: If the light doesn’t come on, try many different
angles when pressing the power button. Do not hold
down the power button. Press and release the button
only.
9 Version 1.4
3. To put the device into standby mode, press the
“Motion Detection Button”one time. The green
light will come on, and the device will be in
standby mode.
HOW TO RECORD VIDEO
1. When the camera is in Standby Mode, press the
“Continuous Recording Button” (see page 6).
The Indicator LED will flash two times.
2. Once the Indicator LED turns off, the camera is
now recording video.
HOW TO STOP RECORDING VIDEO
1. While the camera is recording video, press the
“Continuous Recording Button” once more. The
Indicator LED will turn on.
2. The camera has saved the video file, stopped
recording, and is back in Standby Mode.
HOW TO TAKE PICTURES
10 Version 1.4
1. When the camera is in Standby Mode, press the
“Photo Button” (see page 6). The green light
will turn red while the photo is being taken.
2. Once the photo is taken, the light will turn back
to green, and the device is back in standby
mode.
HOW TO SET UP MOTION DETECTION MODE
1. When the camera is in Standby Mode, press the
“Motion Detection Button” (see page 6).
2. If motion is detected, the red light will flash 2
times and turn off.
3. If there is no motion after 1 minute, the device
will return to detection standby mode until
motion is detected again. While waiting, the
green light will be on.
NOTE: If you activate motion detection and there is no
motion currently in front of the camera, there will be
no indication you have entered into motion detection
mode. The green light will simply remain on. If you
wish to confirm that you have entered into motion
