Mindray DPM 4 Manuel utilisateur

Quick Reference Guide

Central Station

Note: The DPM4 Quick Reference Guide is not

intended as a replacement to the Operating

Instructions. Prior to operating equipment, the user

must be familiar with the Operating Instructions

Manual contents. This document is a guideline only to

be used as an aid to comprehensive Inservice Training.

P/N: 046-001981-00 Rev A

Overview ................................................1

Removing Cleaning Plug from SpO2Module..............1

Enabling the SpO2module ...............................1

Installing the SpO2patient cable and sensor..............2

Displaying the SpO2waveform ...........................2

Printing Real Time SpO2Waveform .......................3

Patient Alarms ...........................................3

Viewing and Printing Trends..............................5

Viewing and Printing Events .............................5

Disabling the SpO2Module ..............................6

Cleaning the SpO2Module ...............................7

Frequently Asked Questions..............................7

Admit a Patient without Patient Information..............2

Admit a Patient and Enter Patient Information ............2

Discharge a Patient ......................................2

Set a NIBP Interval .......................................3

Set Alarm Limits .........................................3

Silence Active Alarm(s) ...................................4

Pause All Alarms .........................................4

Set Screen Configuration

(Standard, Trends, OxyCRG, or Large Fonts) ...............4

Change Waveform Configuration .........................4

Change Waveform Order .................................5

Initiate Standby..........................................5

Resume Monitoring from Standby........................5

Record Real Time Recording Strip ........................5

Record Trend Table.......................................6

Record NIBP Measurements ..............................6

Record Alarm Events .....................................6

Table of Contents

P/N: 046-001981-00 Rev A 1

Admit a Patient without Patient Information

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectPatient Setup

 •SelectQuick Admit

 •SelectYes to confirm clearing prior data and

 •SelectPatient type (size)

 •SelectOK to confirm and return to normal screen

Admit a Patient and Enter Patient Information

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectPatient Setup

 •SelectAdmit

 •SelectYes to confirm clearing prior data and

 •Scrollandselecttoenterpatientinformation

 •SelectOK to confirm and return to normal screen

Discharge a Patient

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectPatient Setup

 •SelectDischarge Patient (Clear Patient Data)

 •SelectYes to confirm clearing prior data and return

to normal screen

Note: Clear Patient Data is present if patient

information is omitted.

Quick Reference Guide

Central Station

P/N: 046-001981-00 Rev A 2

Set a NIBP Interval

Using Control knob on control panel

 •ScrollandselectNIBPtile

 •ScrollandselectInterval

 •Scrolltoselecttime

 •ScrollandselectExit to return to normal screen

Set Alarm Limits

Using Control knob on control panel (Option 1)

 •ScrollandselectParametertile

 •ScrollandselectAlm HI/Alm LO

 •Scrolltoadjustalarmlimit

 •ScrollandselectExit to return to normal screen

Using Control knob on control panel (Option 2)

 •ScrollandselectMenu

 •ScrollandselectSystem Setup

 •ScrollandselectAlarm Setup

 •SelectAlm Sel

 •Selectparameter’sAlm Setup

 •ScrollandselectAlm HI/Alm LO

 •Scrolltoadjustalarmlimit

 •ScrollandselectExit to return to normal screen

Quick Reference Guide

Central Station

P/N: 046-001981-00 Rev A 3

Silence Active Alarm(s)

Press and hold Silence button >2 seconds. If new alarms

occur, system silence will be terminated

Pause All Alarms

Press Silence button. All alarms are paused for a

preconfigured time (1, 2, or 3 minutes). All visual and

audio alarm notification is suspended. Alarm notification

will resume if Silence is pressed a second time or once the

preconfigured time has elapsed.

Set Screen Configuration

(Standard, Trends, OxyCRG, or Large Fonts)

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectSystem Setup

 •ScrollandselectFace Select

 •Scrolltoselectscreen

 •ScrollandselectExit to return to normal screen

Change Waveform Configuration

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectSystem Setup

 •ScrollandselectTrace Setup

 •Scrollandselectwaveform(s)tobedisplayed(A√in

the waveform box indicates waveform is selected)

Quick Reference Guide

Central Station

P/N: 046-001981-00 Rev A 4

Change Waveform Order

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectSystem Setup

 •ScrollandselectTrace Setup

 •ScrollandselectWave Sequence

 •Scrolltoselectchanneltochange

 •Selectparameter

 •ScrollandselecttoExit to return to normal screen

Initiate Standby

Using Control knob on control panel

 •ScrollandselectStandby

 •ScrollandselectYes to confirm

Resume Monitoring from Standby

Press any key on front panel and Scroll and select Yes

to confirm

Record Real Time Recording Strip

 •SelectRecordkeyoncontrolpanel

 •SelectRecordkeytostop(ifcontinuousmodeis

enabled)

Quick Reference Guide

Central Station

P/N: 046-001981-00 Rev A 5

Record Trend Table

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectTrend Table

 •ScrollandselectResolution

 •Scrolltoadjusttimeinterval

 •ScrollandselectREC to record

 •ScrollandselectExit to return to normal screen

Record NIBP Measurements

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectNIBP Recall

 •ScrollandselectREC to record

 •ScrollandselectExit to return to normal screen

Record Alarm Events

Using Control knob on control panel

 •ScrollandselectMenu

 •ScrollandselectAlarm Recall

 •ScrolltoadjustStart/End time

 •ScrollandselectAlarm Recall Event to select

sorting criteria

 •ScrollandselectAlarm Recall to view alarm event

or UP-Down to view other alarm events

 •ScrollandselectREC to record

 •ScrollandselectExit to return to normal screen

Quick Reference Guide

Central Station

P/N: 046-001981-00 Rev A 6
