Spectroquant®Multy

Operating manual

Table of contents

1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.1 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.2 Inserting the rechargeable batteries/lithium powerpack. . . . . . . . .8

1.2.1 Lithium powerpack – Important information . . . . . . . . . . . . . .9

1.2.2 Charging the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

1.2.3 Using non-rechargeable batteries . . . . . . . . . . . . . . . . . . . . . .10

1.2.4 Using the protective caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

1.3 Overview of the key functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

1.4 Starting the colorimeter the first time . . . . . . . . . . . . . . . . . . . . . .12

1.5 Overview of the mode menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

1.6 Setting the language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

1.7 Deleting data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

1.8 Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1.9 Time and date display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1.10 Automatic switch-off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

2 Operating mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

2.1 Selecting the method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

2.2 Measuring with test kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

2.3 Differentiation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

2.4 Altering the citation form. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

2.5 Measuring absorbances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

2.6 User countdown (timer function). . . . . . . . . . . . . . . . . . . . . . . . . . .24

2.7 Saving measurement results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

2.8 Retrieving saved measurement results. . . . . . . . . . . . . . . . . . . . . . .26

2.8.1 Retrieving all saved measurement results. . . . . . . . . . . . . . . .26

2.8.2 Retrieving saved measurement results

from a defined date range . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

2.8.3 Retrieving saved measurement results

from a defined code-No. range . . . . . . . . . . . . . . . . . . . . . . . .28

2.8.4 Retrieving saved measurement results

from a defined method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

2.9 Deleting saved measurement results . . . . . . . . . . . . . . . . . . . . 31

3 Other functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

3.1 User-specific method list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

3.1.1 Processing the user-specific method list. . . . . . . . . . . . . . . . .32

3.1.2 User-specific method list: Activate all methods. . . . . . . . . . .34

3.1.3 User-specific method list: Deactivate all methods. . . . . . . . .34

3.2 Profi mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

3.3 Acoustic signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

3.3.1 Activating/deactivating the key beep . . . . . . . . . . . . . . . . . . .36

3.3.2 Activating/deactivating the signal beep . . . . . . . . . . . . . . . . .36

3.3.3 Activating/deactivating the countdown function

(observance of reaction times) . . . . . . . . . . . . . . . . . . . . . . . . .37

3.4 Setting the display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

3.5 System info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

4 Trouble-shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

4.1 User messages on the display / Error messages . . . . . . . . . . . . . . .39

4.2 Other potential sources of error. . . . . . . . . . . . . . . . . . . . . . . . . . . .42

4.3 Avoiding errors in photometric measurements . . . . . . . . . . . . . . .43

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Declaration of CE-Confirmity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

5 Contents of CD-ROM see enclosed CD

5.1 Overview of preprogrammed methods and analytical procedures

5.2 Standard solutions

5.2.1 Use of Spectroquant® CombiCheck and ready-to-use

standard solutions

5.2.2 Preparation of standard solutions

5.3 Printing measurement results

5.3.1 Setting the print parameters

5.3.2 Printing all measurement results

5.3.3 Printing measurement results from a defined date range

5.3.4 Printing measurement results from a defined code-No. range

5.3.5 Printing measurement results from a defined method

5.4 Transferring data to a PC

5.5 Software update via the internet

5.6 User methods

5.6.1 User concentration method

5.6.2 User polynomials

5.6.3 Deleting a user method

5.6.4 Printing data for a user method

5.6.5 Initializing the user-method system

5.7 User-specific calibration

5.7.1 Saving the user-specific calibration

5.7.2 Deleting the user-specific calibration

5.8 Calculating the Langelier saturation index

5.9 Technical specifications

Getting started

1.1 Package contents

The standard contents of the Spectroquant® Multy Colorimeter

package comprise the following items:

1 colorimeter in a plastic carrying case

1 beaker (plastic) 100 ml (a)

1 set of rechargeable batteries (7 nickel-cadmium batteries; type AA) (b)

1 adapter for 16-mm ø round cells (c)

3 round cells with lids, ø 16 mm (d)

1 screwdriver

(e)

1 cable for connection with a PC or printer (f)

1 mains adapter, 100 - 240 V, 50 - 60 Hz

with 4 wall-socket adapters (EU, UK, USA, AUS) (g)

2 protective caps for connection terminals on the back (h)

1 lid for adapter (i)

1 lithium battery (CR 2032; 3V)

3 round cells with lids, ø 24 mm (k)

1 operating-instructions

manual

1 certificate of compliance

1.2 Inserting the rechargeable

batteries/lithium powerpack

Before operating the system for the first time, the rechargeable

batteries and the lithium powerpack included in the package

must be installed.

The batteries enclosed in the package are not charged.

ABattery pack: 7 nickel-cadmium batteries (type AA, 750 mAh)

BBattery: lithium battery (type CR 2032, 3V)

CFuse: 1 A, delayed-action, 20 mm

1. Ensure that the Spectroquant® Multy Colorimeter is switched off.

2. Remove, where applicable, the cell from the measurement

compartment.

3. Place the unit on its front on a clean, flat surface.

4. Remove the two screws (E) on the battery-compartment cover

(F) on the bottom of the unit.

5. Remove the batteries cover (F).

6. Remove any old batteries (A) and/or the lithium powerpack (B).

7. Insert 7 new rechargeable batteries and/or the lithium

powerpack

Make sure that the batteries are inserted correctly!

8. Attach the battery-compartment cover.

9. Replace the screws and tighten with moderate pressure.

Mains

connector

DSerial interface

(printer, PC)

Protective cap

EScrews

ABattery pack CFuse BBattery Back of unit

FBattery-compartment cover

Dispose of used batteries and/or

the lithium powerpack in accordance

with the local regulations.

1.2.1 Lithium powerpack –

Important information

The lithium powerpack (B) serves to save all important data

(saved measurement results, settings) for approx. ½ year when

the unit is not being supplied with power by the battery pack

or the mains supply.

As long as the colorimeter is being supplied with mains or

battery power, it does not draw any power from the lithium

powerpack. Since lithium powerpacks have a very long life,

it will in all probability not be necessary to exchange the

one supplied. All the same, to ensure proper functioning it is

recommended to replace the lithium powerpack every five years.

Note

When neither the mains adapter nor the battery pack are

supplying power, removal of the lithium powerpack will result

in a complete loss of data (saved measurement results and

settings). For this reason we strongly recommend that the unit

is connected to the mains power supply while replacing the

lithium powerpack.

1.2.2 Charging the battery pack

The rechargeable batteries (A) remain in place in the photo-

meter for recharging. Once the mains power supply is established,

the batteries start to be charged.

Charge the rechargeable batteries in the instrument for 5 days

(working with power from mains is possible). Now use the

instrument without mains until the first battery warning comes

up. Charge again, 4 days this time. Repeat usage to battery

warning and charging four times.

Approximately 10 charging/discharging cycles are required until

the batteries reach their full capacity.

The unit can be operated with mains power supply with or

without the batteries in place. For this you must attach the

country-specific wall-socket adapter to the mains adapter.

1.2.3 Using non-rechargeable batteries

In principle it is also possible to operate the unit using conven-

tional batteries – in this case, however, they must never be

used in combination with the mains adapter. The charging

process would start automatically as soon as the colorimeter is

connected to the mains power supply. Conventional batteries

are destroyed by the charging current, resulting in severe dam-

age to the unit. This also involves the risk of fire and explosion.

1.2.4 Using the protective caps

To protect the connection terminals on the unit from damage

(e.g. corrosion) due to environmental influences such as e.g.

dust or water splashes, the supplied protective caps should be

attached over the connection points (D) when these are not

being used.

1.3 Overview of the key functions

Switching the unit on and off

Function key: Function explained at the corresponding place in the text

Back to method selection / to parent menu

Confirmation of selections (visible on the display as the “ ” symbol)

Menu for settings and other functions

Moves cursor (visible on the display as the “>>” symbol) up or down

Save a displayed result

Zero-calibration function

Run a measurement

Display of date and time / user countdown

O

tseTedoM

Store

Zero

654

321

987

Spectroquant® Multy

Enter

Esc

Time

1.5 Overview of the mode menu

Mode No. Mode function Brief description Section

10 Language Setting the language 1.6

11 Key-beep Activating the acoustic key-acknowledgment tone 3.3.1

12 Clock Setting the date and time 1.8

13 Countdown Activating/deactivating the countdown for reaction times 3.3.3

14 Signal-beep Activating/deactivating the acoustic signal at the end of a measurement 3.3.2

20 Print Printing all saved measurement results 5.3.2

21 Print, date Printing measurement results from a defined date range 5.3.3

22 Print, code No. Printing measurement results from a defined code-No. range 5.3.4

1.4 Starting the colorimeter

the first time

Switch on the colorimeter by pressing the [On/Off] button.

The unit runs an electronic self-check test.

The display then shows:

Pressing the [Enter] key takes the colorimeter to method

selection.

Any data already saved in the unit must be deleted (mode 34,

see chapter 1.7, "Delete data"), the user-method system must

be initialized (mode 69, see section 5.6.5, "Initializing the

user-method system (concentration and polynomials)"), and

the date and time should be reset. (See below for details.)

The Spectroquant® Multy is supplied with English preset as the

standard language setting. Before making the first measurement

you should therefore reset the unit to the language of your

choice. To do this go from the method list and change to the

mode menu by pressing the [Mode] key.

The display shows:

After a short time the selection list appears:

Please initialize

the storagesystem

with MODE 34

MODE Menu

cancel: ESC

>> 10:Language

11:Key-beep

12:Clock

... ...

Table des matières

Autres manuels Millipore Équipement de laboratoire

Millipore

Millipore Elix 35 Manuel utilisateur

Millipore

Millipore Milliflex Oasis Manuel utilisateur

Millipore

Millipore Direct Detect Manuel utilisateur

Millipore

Millipore Steritest Symbio Manuel utilisateur

Millipore

Millipore Samplicity Manuel utilisateur

Millipore

Millipore SNAP i.d Manuel utilisateur

Millipore

Millipore PR00SIA1 Manuel d'utilisation et d'entretien

Millipore

Millipore Amicon Ultra-2 Manuel utilisateur

Millipore

Millipore Millicell ERS-2 Manuel utilisateur

Millipore

Millipore Viresolve Pro VPMCPDKNB9 Manuel utilisateur

Millipore

Millipore M Air T Manuel utilisateur

Millipore

Millipore Helicon S10 Manuel utilisateur

Millipore

Millipore milli-q Manuel utilisateur

Millipore

Millipore MERCK EZ-Pak Manuel utilisateur

Millipore

Millipore ReadyStream Manuel utilisateur

Millipore

Millipore XX11 000 00 Manuel utilisateur

Millipore

Millipore Labscale Manuel utilisateur

Millipore

Millipore XX4004700 Manuel utilisateur

Millipore

Millipore Amicon Ultra-4 Series Manuel utilisateur

Millipore

Millipore Milli-Q Advantage A10 Manuel utilisateur

Millipore

Millipore APC ErgoTouch Pro 2 Manuel utilisateur

Millipore

Millipore 8003 Manuel utilisateur

Millipore

Millipore Amicon 6028 Manuel utilisateur

Millipore

Millipore Millicell MDCI10000 Manuel utilisateur

Manuels Équipement de laboratoire populaires d'autres marques

Qiagen

Qiagen DML 3000 Manuel utilisateur

Queensgate

Queensgate NANOSCAN OP400 Manuel de programmation

Conviron

Conviron GEN1000-GE Manuel utilisateur

Parr Instrument

Parr Instrument 4560 Mode d’emploi

IKA

IKA IC control Manuel utilisateur

Integra

Integra DOSE IT Manuel utilisateur

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manuel utilisateur

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manuel utilisateur

NI PXI-5422 Manuel

Collomix

Collomix Aqix Manuel utilisateur

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manuel utilisateur

Ocean Insight

Ocean Insight FLAME-NIR+ Manuel utilisateur

Parker

Parker ALIGN-MG-NA Manuel utilisateur

BD 644787 Manuel utilisateur

DENTAURUM

DENTAURUM Compact Megaplus Manuel utilisateur

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manuel utilisateur

VWR

VWR SAS Super IAQ Manuel utilisateur

illumina

illumina MiSeqDx Manuel utilisateur
