Milesight Technology MS-C9674-PB Manuel utilisateur
Fisheye Network Camera
User Manual
V1.07
Thank you for purchasing our product. If there is any questions or requests, please do not hesitate
to contact your dealer.
This manual is applicable to the Milesight H.265 Fisheye Network Camera, series are shown as
follows, except where otherwise indicated.
This Manual explains how to use and manage Milesight Fisheye Network Camera on your network.
Previous experience of networking will be of use when using the products. Please read this manual
carefully before operation and retain it for future reference.
This manual may contain several technically incorrect places or printing errors, and the content is
subject to change without notice. The updates will be added into the new version of this manual.
We will readily improve or update the products or procedures described in the manual.
Copyright Statement
This manual may not be reproduced in any form or by any means to create any derivative such as
translation, transformation, or adaptation without the prior written permission of Milesight
Technology Co., Ltd (Hereinafter referred to as Milesight).
Milesight reserves the right to change this manual and the specifications without prior notice. The
latest specifications and user documentation for all Milesight products are available on our official
website www.milesight.com
Industry Canada ICES-003 Compliance:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
Milesight H.265 Fisheye Network Camera
Type Megapixel
5MP
12MP
Fisheye Network Camera
MS-C5374-PB
MS-C9674-PB
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss. The precaution measures are divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may be caused if any of these warnings is neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings: Please follow these safeguards to
prevent injury or death.
Cautions: Please follow these safeguards to
prevent potential injury or material damage.
Warnings
This installation must be conducted by a qualified service person and should strictly
comply with the electrical safety regulations of the local region;
To avoid risk of fire and electric shock, do keep the product away from rain and moisture
before installed;
Do not touch components such as heat sinks, power regulators, and processors, which
may be hot;
Source with DC 12V;
Please make sure the plug is firmly inserted into the power socket;
When the product is installed on a wall or ceiling, the device should be firmly fixed;
If the product does not work properly, please contact your dealer. Never attempt to
disassemble the camera by yourself.
Cautions
Make sure that the power supply voltage is correct before using the camera;
Do not store or install the device in extremely hot or cold temperatures, as well as dusty
or damp locations, and do not expose it to high electromagnetic radiation;
Only use components and parts recommended by manufacturer;
Do not drop the camera or subject it to physical shock;
To prevent heat accumulation, do not block air circulation around the camera;
Laser beams may damage image sensors. The surface of image sensors should not be
exposed to where a laser beam equipment is used;
Use a blower to remove dust from the lens cover;
Use a soft, dry cloth to clean the surface of the camera. Stubborn stains can be removed
using a soft cloth dampened with a small quantity of detergent solution, then wipe dry;
Do not use volatile solvents such as alcohol, benzene or thinners as they may damage the
surface finishes;
Save the package to ensure availability of shipping containers for future transportation.
EU Conformity Statement
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury(Hg). For proper recycling, return the battery to your supplier or to a designated
collection point. For more information see: www.recyclethis.info.
Table of Contents
Chapter I Product Description.............................................................................................................. 1
1.1 Product Overview.................................................................................................................... 1
1.2 Key Features............................................................................................................................ 1
1.3 Hardware Overview.................................................................................................................2
1.4 How to Connect to Alarm Interface.........................................................................................3
1.5 How to Connect the Water-proof Connector..........................................................................3
1.6 System Requirements.............................................................................................................. 4
Chapter II Network Connection............................................................................................................5
2.1 Setting the Camera over the LAN............................................................................................ 5
2.1.1 Connect the Camera to the PC Directly.........................................................................5
2.1.2 Connect via a Switch or a Router...................................................................................5
2.2 Dynamic IP Connection............................................................................................................5
Chapter III Accessing the Network Camera.......................................................................................... 7
3.1 Assigning An IP Address...........................................................................................................7
3.1.1 Assigning An IP Address Using Smart Tools...................................................................7
3.1.2 Assign An IP Address via Browser................................................................................10
3.2 Accessing from the Web Browser..........................................................................................13
3.3 Accessing from Milesight VMS (Video Management Software)........................................... 15
Chapter IV System Operation Guide...................................................................................................17
4.1 Live Video.............................................................................................................................. 17
4.1.1 Operations on Live View Page..................................................................................... 18
4.1.2 Set / Call a preset / Patrol............................................................................................22
4.2 Playback................................................................................................................................. 24
4.3 Local Settings......................................................................................................................... 26
4.4 Basic Settings......................................................................................................................... 26
4.4.1 Video............................................................................................................................26
4.4.2 Image........................................................................................................................... 28
4.4.3 Audio............................................................................................................................36
4.4.4 Network....................................................................................................................... 38
4.4.5 Date&Time...................................................................................................................47
4.5 Advanced Settings................................................................................................................. 48
4.5.1 Alarm........................................................................................................................... 48
4.5.2 Storage.........................................................................................................................55
4.5.3 Security........................................................................................................................ 59
4.5.4 SIP................................................................................................................................ 62
4.5.5 Smart Event................................................................................................................. 65
4.5.6 Fisheye.........................................................................................................................72
4.5.7 Logs..............................................................................................................................74
4.6 System....................................................................................................................................75
4.7 Maintenance..........................................................................................................................76
4.7.1 System Maintenance................................................................................................... 76
4.7.2 Auto Reboot.................................................................................................................77
Chapter V Services..............................................................................................................................78
1
Chapter I Product Description
1.1 Product Overview
Milesight provides a consistent range of cost-effective and reliable Fisheye Network Camera to
fully meet your requirements. Based on embedded Linux operating system, Milesight Fisheye
Network Camera could be easily accessed and managed either locally or remotely with great
reliability. With built-in high-performance DSP video processing modules, the cameras pride on
low power consumption and high stability. They support state-of-the-art H.265/ H.264/ MJPEG
video compression algorithm and industry-leading HD dual-stream technology to achieve the
highest level of video image quality under the limited network resources. It is fully functional,
supporting for flexible and comprehensive alarm linkage mechanism, and features with
advanced technology, bringing panoramic viewing experience. It has the effect of more than 4
regular network cameras. The ultra high resolution and latest design guarantee the detailed
images and enjoy-able user-experience.
In practical applications, Milesight Fisheye Network Camera could either work independently in
the LAN, or be networked to form a powerful safety monitoring system. It is widely used in fields
such as finance, education, industrial production, civil defense, health care for security’s sake.
1.2 Key Features
70% ~80% bandwidth saved by 10-level adjustable H.265+
Up to 25fps@4000×3000
7 display modes to meet various needs
Built-in Microphone and Audio out
Equipped with Alarm In and Alarm Out
IK09-rated vandal-proof metal cover, and high vandal resistant enclosure
IP67-rated weather-proof housing
Streamlined design, exquisite appearance
Easy to blend in with the installation environment
255 Preset Points and 8 Patrols
Based on Linux OS with high reliability
Support ONVIF Profile S & G
Support activation and set-up of the security questions for cameras(V4x.7.0.69 or above)
ICR filter with auto switch, true day/night
UPnP protocol for the easy management of cameras
Support Milesight DDNS
Motion Detection, Privacy Masking, Network Fault Detection and ROI
FTP upload, SMTP upload, SD card record and SIP function
G.711/AAC audio compression capability
Three-privilege levels of users for flexible management
Micro SD/SDHC/SDXC card local storage support, expand the edge storage
2
1.3 Hardware Overview
1. 5MP Fisheye Network Camera
2. 12MP Fisheye Network Camera
1
3
Note:
1) DC 12V and PoE are available for power supply.
2) Built-in SD card slot can be seen after rotating open the cover, removing the 3 screws and
open the front panel.
1.4 How to Connect to Alarm Interface
External interface of camera is as the following, you can refer to the picture to install the external
alarm device:
PIN1: Alarm Output NC/NO 24V DC 1A
PIN2: Alarm Output NC/NO 24V DC 1A
PIN3: Alarm Input NC/NO ≤12V
PIN4: Alarm Input NC/NO ≤12V
1.5 How to Connect the Water-proof Connector
Step1: Get the network cable through the screw nut, rubber ring and the screw bolt.
Step2: Insert the rubber ring into the screw bolt.
Step3: Connect the screw nut to the screw bolt.
Step4: Place the O-Ring on the network port connector.
Step5: Connect the RJ45 to the network port connector, and tighten the screw bolt and the
connector.
1
4
1.6 System Requirements
Operating System: Windows XP/Vista/7/8/10/Server 2000/Server 2008
CPU: 1.66GHz or higher
RAM: 1G or higher
Graphic memory: 128MB or more
Internet protocol: TCP/IP (IPv4/IPv6)
Web Browsers: Internet Explorer 8.0 and above version, Mozilla
Firefox, Google Chrome and Safari.
4
Chapter II Network Connection
2.1 Setting the Camera over the LAN
Connecting the camera to a switch or a router is the most common connection method. The
camera must be assigned an IP address that is compatible with its LAN.
2.1.1 Connect the Camera to the PC Directly
In this method, only when the computer connected to a camera, it will be able to view the camera.
The camera must be assigned a compatible IP address to the computer. Details are shown as the
following figure.
Figure 2-1-1 Connect the camera to the PC directly
2.1.2 Connect via a Switch or a Router
Set network camera over the LAN via the switch or router as figure 2-1-2:
Figure 2-1-2 Connect via a switch or a Router
2.2 Dynamic IP Connection
Connecting the network camera via a router
Step1: Connect the network camera to a router;
Step2: On the camera, assign a LAN IP address, a Subnet mask and a Gateway;
Step3: On the router, set port forwarding. E.g. 80, 8000 and 554 ports. The steps for port
forwarding vary depending on different routers. Please look up the router's user manual for
assistance with port forwarding;
Step4: Apply a domain name from a domain name provider;
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Milesight Technology Caméra de sécurité
Milesight Technology
Milesight Technology MS-C2942-B Manuel utilisateur
Milesight Technology
Milesight Technology MS-C2181-PA Manuel utilisateur
Milesight Technology
Milesight Technology MS-C2981-PB Manuel utilisateur
Milesight Technology
Milesight Technology MS-C5374-PB Manuel utilisateur
Milesight Technology
Milesight Technology UI-2A81-PCV Manuel utilisateur
