Miele CS 1223-1 Manuel utilisateur

Operating and installation instructions

Induction wok

CS 1223-1

To avoid the risk of accidents or

damage to the appliance, it is

essential to read these instructions

before it is installed and used for the

first time. M.-Nr. 09 551 700

en-GB

Guide to the appliance .............................................4

Warning and Safety instructions .....................................6

Caring for the environment.........................................15

Before using for the first time.......................................16

Induction........................................................17

The induction principle .............................................17

Pans ............................................................18

Operation .......................................................19

Switching on and off ...............................................19

Residual heat indicator .............................................19

Settings .........................................................20

Auto heat-up .....................................................20

Booster function...................................................21

Safety features ...................................................22

System lock ......................................................22

Safety switch-off...................................................23

Overheating protection .............................................24

Cleaning and care ................................................25

Problem solving guide ............................................27

Optional accessories..............................................29

Safety instructions for installation...................................30

Contents

Appliance and building-in dimensions ...............................35

Preparing the worktop.............................................36

Installation of several appliances....................................37

Fixing the spring clamps and spacer bars ............................39

Installing the appliance(s)..........................................41

General installation tips ...........................................42

Electrical connection..............................................43

After sales service, data plate, guarantee .............................45

Contents

aWok basin

normal: 2400 W

with Booster: 3200 W

bWok

cControl

dIndicators

eDisplay

Indicators

fIn-operation indicator

gBooster indicator

hResidual heat indicator

Guide to the appliance

Display

ßNo wok on cooking zone, or wok unsuitable

AAuto heat-up

FFault message (See "Problem solving guide")

C/0Safety switch-off (See "Safety features")

IBooster in operation

HOverheating protection (See "Safety features")

LLock (see "Safety features")

Accessories supplied

Wok (CSWP 1400)

Wok rest

Guide to the appliance

This appliance is built in accordance with current safety

requirements. Inappropriate use can, however, lead to personal

injury and damage to property.

To avoid the risk of accidents and damage to the appliance,

please read these instructions carefully before installation and

before using it for the first time. They contain important notes on

installation, safety, use and maintenance.

Miele cannot be held liable for damage caused by

non-compliance with these Warning and Safety instructions.

Keep these instructions in a safe place and ensure that new users

are familiar with the content. Pass them on to any future owner.

Warning and Safety instructions

Correct application

~The wok is not designed for commercial use. It is intended for use

in domestic households and similar working and residential

environments.

~The appliance is not intended for outdoor use.

~It is intended for domestic use only to cook food and keep it

warm. Any other use is not supported by the manufacturer and

could be dangerous.

~The appliance can only be used by people with reduced

physical, sensory or mental capabilities, or lack of experience and

knowledge, if they are supervised whilst using it, or have been

shown how to use it in a safe way and understand the hazards

involved.

Warning and Safety instructions

Safety with children

~Children under 8 years of age must be kept away from the wok

unless they are constantly supervised.

~Children 8 years and older may only use the wok if they have

been shown how to use it in a safe way and recognise and

understand the consequences of incorrect operation.

~Children must not be allowed to clean the wok unsupervised.

~This appliance is not a toy! To avoid the risk of injury, do not allow

children to play with it or use the controls.

~The wok gets hot when in use and remains hot for quite a while

after being switched off. Keep children well away from the appliance

until it has cooled down and there is no danger of burning.

~Danger of suffocation. Packaging, e.g. plastic wrappings, must

be kept out of the reach of babies and children. Whilst playing,

children could become entangled in packaging, or pull it over their

head and suffocate.

~Danger of burning.

Do not store anything which might arouse a child's interest in

storage areas above or behind the appliance. Otherwise they could

be tempted into climbing onto the appliance

~Danger of burning or scalding.

Place pots and pans on the cooking zone in such a way that

children cannot pull them down and burn themselves.

~Activate the system lock to ensure that children cannot switch on

the appliance inadvertently.

Warning and Safety instructions

Technical safety

~Installation, maintenance and repairs may only be carried out by

a Miele authorised service technician.

~A damaged appliance could be dangerous. Before installation,

check the appliance for visible signs of damage. Do not use a

damaged appliance.

~The electrical safety of this appliance can only be guaranteed if

connected to a correctly installed on-site earthing system which

complies with local and national safety regulations. It is most

important that this basic safety requirement is observed and

regularly tested, and where there is any doubt, the household wiring

system should be inspected by a qualified electrician.

~To avoid the risk of damage to the appliance, make sure that the

connection data (frequency and voltage) on the data plate

corresponds to the household supply, before connecting the

appliance to the mains supply.

Consult a qualified electrician if in any doubt.

~Do not connect the appliance to the mains electrical supply by a

multi-socket adapter or extension lead. These are a fire hazard and

do not guarantee the required safety of the appliance.

~For safety reasons, this appliance may only be used when it has

been built in.

~The wok must not be used in a non-stationary location (e.g. on a

ship).

Warning and Safety instructions

~Never open the casing of the appliance.

Tampering with electrical connections or components and

mechanical parts is highly dangerous to the user and can cause

operational faults.

~While the appliance is under guarantee, repairs should only be

undertaken by a Miele authorised service technician. Otherwise the

guarantee is invalidated.

~The manufacturer can only guarantee the safety of the appliance

when original Miele replacement parts are used. Faulty components

must only be replaced by genuine Miele original spare parts.

~The wok is not intended for use with an external timer switch or a

remote control system.

~If the plug is removed from the connection cable or if the

appliance is supplied without a plug, the appliance must connected

to the electrical supply by a suitably qualified electrician. If the

connection cable is faulty, it must be replaced with a special

connection cable. See "Electrical connection".

~The appliance must be disconnected from the mains electricity

supply during installation, maintenance and repair work. Ensure that

power is not supplied to the appliance until after it has been

installed or until any maintenance or repair work has been carried

out.

~Danger of electric shock.

Do not use the wok if it is faulty, or if the ceramic surface is cracked,

chipped or damaged in any way. Switch it off immediately, and

disconnect it from the mains electricity supply.

Warning and Safety instructions
