Midea NT20-22E Manuel utilisateur

NT20-22E

USER MANUAL

Warning notices: Before using this product, please read this manual carefully and keep it for future reference.

The design and specifications are subject to change without prior notice for product improvement.

Consult with your dealer or manufacturer for details.

The diagram above is just for reference. Please take the appearance of the actual product as the standard.

This product is only suitable for well insulated spaces or occasional use.

COMPACT FAN HEATER

THANK YOU LETTER

Thank you for choosing Midea! Before using your new Midea product, please read

this manual thoroughly to ensure that you know how to operate the features and

functions that your new appliance offers in a safe way.

CONTENTS

1 2

1 1

1 3

1 0

1 4

THANK YOU LETTER

SAFETY INSTRUCTIONS

SPECIFICATIONS

PRODUCT OVERVIEW

OPERATION INSTRUCTIONS

CLEANING AND MAINTENANCE

TROUBLESHOOTING

TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT

DISPOSAL AND RECYCLING

DATA PROTECTION NOTICE

Danger

This symbol indicates that there are dangers to the life and health of

persons due to extremely ﬂammable gas.

Warning of electrical voltage

This symbol indicates that there is a danger to life and health of

persons due to voltage.

Warning

The signal word indicates a hazard with a medium level of risk which, if

not avoided, may result in death or serious injury.

Caution

The signal word indicates a hazard with a low degree of risk which, if

not avoided, may result in minor or moderate injury.

Attention

The signal word indicates important information (e.g. damage to

property), but not danger.

Observe instructions

This symbol indicates that a service technician should only operate and

maintain this appliance in accordance with the operating instructions.

The following safety guidelines are intended to prevent unforeseen risks or damage from

unsafe or incorrect operation of the appliance. Please check the packaging and appliance

on arrival to make sure everything is intact to ensure safe operation. If you ﬁnd any

damage, please contact the retailer or dealer. Please note modiﬁcations or alterations to

the appliance are not allowed for your safety concern. Unintended use may cause

hazards and loss of warranty claims.

Read these operating instructions carefully and attentively before using/commissioning the

unit and keep them intheimmediate vicinity of theinstallation site or unit for later use!

Intended Use

Explanation of Symbols

SAFETY INSTRUCTIONS

Caution

●

Read Rules for Safe Operation and Instructions carefully.

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall

not be made by children without supervision.

The heater must not be located immediately below a

socket-outlet.

Children of less than 3 years should be kept away unless

continuously supervised.

Children aged from 3 years and less than 8 years shall

only switch on/off the appliance provided that it has

been placed or installed in its intended normal operating

position and they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children aged from

3 years and less than 8 years shall not plug in, regulate

and clean the appliance or perform user maintenance.

CAUTION — Some parts of this product can become very

hot and cause burns. Particular attention has to be given

where children and vulnerable people are present.

Do not use this heater if it has been dropped;

Use this heater on a horizontal and stable surface, or fix it

to the wall, as applicable.

●

Warning: In order to avoid overheating, do not

cover the heater.

If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

Do not use this heater in the immediate surroundings of

a bath, a shower or a swimming pool.

The appliance is not to be used by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction.

Children being supervised not to play with the

appliance.

WARNING: To reduce the risk of fire, keep textiles,

curtains, or any other flammable material a minimum

distance of 1 m from the air outlet.

Do not use if there are visible signs of damage to the

reater.

Do not use outdoors.

WARNING: Do not use this heater in smallrooms when

they are occupied by persons not capable of leaving

the room ontheir own, unless constant supervision is

provided.

Warning

SPECIFICATIONS

NT20-22EProduct Model

Voltage

Frequency

Power

220-240V~

50Hz

2000W

Symbol Value Unit Item Unit

Item

Heat output for NT20-22E

Auxiliary electricity consumption Fan assisted heat output

Nominal heat

output Pnom 2 kW No

Type of heat input, for electric local

space heaters only (select one)

Manual heat charge control with

integrated thermostat

Minimum heat

output (indicative) Pmin 1 kW

Pmax 2 kW

Manual heat charge control with

room and/or outdoor

temperature feedback

Electronic heat charge control

with room and/or outdoor

temperature feedback

Maximum

continuous heat

output

elmax 0 kW Type of heat output/room temperature

control (select one)

elmin 0 kW

elSB 0 W

Yes

Single stage heat output and no

room temperature control

Two or more manual stages, no

room temperature control

With mechanic thermostat

room temperature control

With electronic room

temperature control

Electronic room temperature

control plus day timer

Electronic room temperature

control plus week timer

Maximum

continuous heat

output

At minimum heat

output

At nominal heat

output

Other control options (multiple

selections possible)

Room temperature control, with

presence detection

Room temperature control, with

open window detection

With distance control option

With adaptive start control

With working time limitation

With black bulb sensor

PRODUCT OVERVIEW

Part Name

NOTE

All the pictures in this manual are for explanation purpose only. Any discrepancy between

the real object and the illustration in the drawing shall be subject to the real subject.

Temperature

control knob

Safty grill

Power selection

knob

OPERATION INSTRUCTIONS

Check Before Turning On The Machine

1. Check if the power wire is under good condition.

2. The product adopts 220-240V AC power supply, before use, please confirm if the

rated current of the power socket meets the local requirements with safe grounding

device, otherwise, please replace it with the qualified socket.

Put The Machine On The Flat Place

Uneven place may possibly cause the turnover switch at abnormal position, then the

heater can't work after turning on, therefore, please put the heater on the flat place, at

least the surface below the base of the heater must be flat.

Temperature Control Knob

Insert the plug into the power socket, then turn the Temperature Control knob clock-

wise, when hearing the “poop” sound (it means the temperature controller is on), adjust

the Temperature Control knob to the desired temperature level.

Power Selection Knob

Turn the Power selection knob to select between 4 functions: Fan only, Low 900W

(LOW), MIDDLE 1300W(MIDDLE), High 2000W(HIGH).

Turn Off The Heater

A. Turn the Power selection knob to OFF position.

B. Turn the Temperature Control knob anticlockwise to the initial position.

C. Remove the power plug, store the heater after the entire machine has become cool.

Safety Protection

1. Overheat protection: When the temperature in the heater is too high due to

abnormality in the use environment or improper use, the thermostat device can

automatically cut off the power and the heater stops working. After the whole heater

is cooling, the heater can return to the normal use after removing the abnormality.

2. Inversion protection: When the whole heater is inverted, the safety system will

automatically cut off the power, and return to the work state before inversion after the

body is placed upright.

Safety Control

• Your heater is fitted with a safety device "Double Protector" that (1) switches off the

heater by thermal cut-off in the event of overheating or malfunction, It will reset while

the temperature reduce to a normal level. (2) Shuts off the heater by thermal fuse in

the event of overheating or malfunction and not operates by some other accidental

reason.

• If overheating or malfunctions continue, return the heater to an Approved Service

Agent for examination.

• The most common cause of overheating is deposits of dust or fluff entering the heater,

Ensure these deposits are removed regularly by unplugging the unit and vacuum

cleaning air vents and front grille.

• This heater cannot achieve accurate temperature control of the enviroment, and thus

cannot be used as insulation device for storage environment, items, animals and plants.
