Midea MRU17B2AWW Manuel utilisateur
Upright Freezer
SINGLE DOOR SERIES
Warning notices: Before using this product,please read this manual carefully and keep it forfuture reference.
The design and specifications aresubject tochange without prior notice for product improvement.
Consult with your dealer ormanufacturer for details.
The diagram aboveis just for reference.Please taketheappearance of the actual product as the standard.
USER MANUAL
MRU17B2AWW
LANGUAGES
EN English
FR French
ES Spanish
01
EN
THANK YOU LETTER
Thank you for choosing Midea! Before using yournewMidea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance oers in a safe way.
CONTENTS
THANK YOU LETTER------------------------------------------- 01
SPECIFICATIONS------------------------------------------------ 02
PRODUCT OVERVIEW----------------------------------------- 03
PRODUCT INSTALLATION----------------------------------- 04
OPERATION INSTRUCTIONS-------------------------------- 08
CLEANING AND MAINTENANCE--------------------------- 11
TROUBLESHOOTING------------------------------------------- 13
WARRANTY--------------------------------------------------------15
02
EN
SPECIFICATIONS
Product model MRU17B2AWW
Total Storage Volume 17 cu.ft.
Rated Voltage 115V~/60Hz
Rated Current 1.8 A
Overall Dimension (H x W x D) 32.7 in x 29.3 in x 65 in
03
EN
PRODUCT OVERVIEW
Names of components
7
1Air flow outlet
4Wire Basket
2Wire Shelf
5Leveling feet
3Air flow inlet
6Door lock
7Door bin
ATTENTION
The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor.
04
EN
PRODUCTINSTALLATION
Install Instruction
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be
recessed or built-in.
• The refrigerator should be placed in a well-ventilated indoor place; the ground
shall be flat and sturdy.
• Keep away from heat and avoid direct sunlight. Do not place the refrigerator in
moist or watery places to prevent rust or reduction of insulating eect.
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
Required space for
air circulation
>100mm
>100mm
>100mm
>100mm
>100mm
>100mm
Top View
Providing a proper power supply
• Check your local power source. This refrigerator requires a 115 V, 60 Hz power
supply.
• Use a receptacle that accepts the grounding prong. The power cord is
equipped with a 3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility of electric shock
hazard from this refrigerator.
CAUTION
The freezer should always be plugged into its own individual electrical outlet which
has a voltage rating that matches the rating plate.
Never unplug your freezer by pulling on the power cord. Always grip the plug firmly
and pull straight out from the outlet.
Start to use
• The freezer shall stay for half an hour before connecting power when it is firstly
started.
• The freezer shall run 2 to 3 hours before loading fresh or frozen foods; the freezer
shall run for more than 4 hours in summer in advance considering that the ambient
temperature is high.
05
EN
Space requirement diagram (when the door is open and when the door is closed)
B
AC
D
E
135 °
Width Overall
Height Depth Width doors
open 135°
Depth doors
open 135°
A B C D E
711 1570 750 1230 1242
Notice: All dimensions in mm
06
EN
Leveling feet
To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to compensate for the uneven floor.
The front should be slightly higher than the rear to aid in door closing.
Leveling screws can be turned easily by tipping the cabinet slightly.
Turn the leveling screws counterclockwise to raise the unit, clockwise to
lower it.
Moving the appliance
1. Remove all food from inside the appliance.
2. Pull the power plug out, insert and fix it into the power plug hook at the rear or
on top of the appliance.
3.
while moving the appliance.
4. Move the appliance with more than two people carefully. When transporting
the appliance over a long distance, keep the appliance upright.
5. After installing the appliance, connect the power plug into a socket out to
switch on the appliance.
Changing the light
• Any replacement or maintenance of the LED lamps is intended to be made by
the manufacturer, its service agent or similar qualified person.
Connecting the appliance
After installing the appliance, connect the power plug into a socket outlet.
ATTENTION
• After connecting the power supply cord (or plug) to the outlet, wait 2 or 3 hours before
you put food into the appliance. If you add food before the appliance has cooled
completely, your food may spoil.
Precautions before operation:
• Before making changes the refrigerator must be disconnected from power.
• Precautions should be taken to prevent any personal injury.
