OWNER’S MANUAL

TOWER FAN

MODEL:FZ10-8HC

Please read the instruction manual carefully before use and safekeeping.

TOWER FAN

Read Rules for Safe Operation and Instructions Carefully.

CAUTION

WARNING

1. Never insert fingers, pencils, or any other object through the grille when fan is

running.

2. Disconnect fan when moving from one location to another.

3. Be sure fan is on a stable surface when operating to avoid overturning.

4. DO NOT use fan in window, rain may create electrical hazard.

5. Indoor use only.

RULES FOR SAFE OPERATION

1. If the supply cord is damaged, it must be replaced by manufacturer

or its service agent or a similarly qualified person in order to avoid

a hazard.

2. To protect against the risk of electrical shock, do not immerse the

unit, cord or plug in water or other liquid.

3. This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety. Young children should be

supervised to ensure that they do not play with the appliance.

4. When the appliance is not in use and before cleaning, unplug the

appliance from the outlet.

5. Keep electrical appliances out of reach from Children or infirm

persons. Do not let them use the appliances without supervision.

6. When the fan was assembled, the rotor blade guard shall not be

taken off anymore

- Prior cleaning unplug the fan

- The rotor guard shall not be dissembled/opened to clean the

rotor blades.

- Wipe the fan enclosure and rotor blade guard with a slightly

damp cloth.

PART FIGURE

Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between

the real object and the illustration in the drawing shall be subject to the real subject.

1. Body

2. Front base

3. Rear base

4. Plastic nut

5. Power cord

1. Take the chassis, fan body from the packing box and combine two parts of the

chassis with two screws.(See Fig.1)

2. Pass the power cord through the flute, then Insert the fan body in the chassis.

(See Fig.3)

3. Fix the fan body on the chassis with plastic nut. (See Fig.2)

ASSEMBLY INSTRUCTIONS

The outlet trough

Fig.1

Fig.2 Fig.3

a. Control parts description:

1. Timer 2. Body oscillating switch 3. Speed switch

b. Instructions:

1. Plug the power cord into a wall outlet.

2. The air flow can be set to oscillate to left or right by

pushing the button of body oscillating switch (2).

If you want to stop oscillation, push it again.

3. Automatic 120-minute timer. Turn the knob of the

timer (1) to the desired time you want, the fan will

stop when the time is over. The longest time set is

120 minutes. If the timer is not required and

constant fan operation is required, then set Timer

to “ON” position.

4. Speed is controlled by selecting the speed switch (3) on the top of the body.

There are 4 positions: OFF ; 1--Low ; 2--Medium ; 3--High

OPERATION INSTRUCTION

4080

120

The fan requires little maintenance. Do not try to fix it by yourself. Refer it to

qualified service personnel if service is needed.

1. Before cleaning and assembling, fan must be unplugged.

2. To ensure adequate air circulation to the motor, keep vents at the rear of the

motor free of dust. Do not disassemble the fan to remove dust.

3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.

4. Do not use any abrasive detergent or solvents to avoid scratching the surface.

Do not use any of the following as a cleaner: gasoline, thinner, bending.

5. Do not allow water or any other liquid into the motor housing or interior parts.

MAINTENANCE INSTRUCTION

CLEANING

1. Be sure to unplug from the electrical supply source before cleaning.

2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.

Thoroughly remove soap film with dry cloth.

GD Midea Environment Appliances Manufacturing CO.,LTD.

Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong, China
