Mictrack B2316 Manuel utilisateur
B2316 User Manual V1.0
http://www.mictrack.com
B2316 Cat M1 & NB-IoT GPS Bracelet
User Manual V1.0
Preface
Congratulations on choosing the Mictrack B2316 CAT M1 & NB-IoT GPS Bracelet. This
manual shows how to easily program and setup the tracker for best results. Make sure to read
this manual carefully before using this product, so as to avoid delays or confusion with it’s
operation. Please note that specifications and instructions are subject to change without notice
to facilitate product improvement. Updates and changes will be integrated into the latest
release. The manufacturer assumes no responsibility for any errors or omissions in outdated
documents.
B2316 User Manual V1.0
http://www.mictrack.com
Contents
1. Overview ......................................................................................................................... 1
2. Features .........................................................................................................................1
3. Applications ....................................................................................................................1
4. Specifications .................................................................................................................2
5. B2316 interface ..............................................................................................................3
6. In the box ....................................................................................................................... 3
7. First Use .........................................................................................................................3
7.1 SIM Card ............................................................................................................. 3
7.2 Charge the device ...............................................................................................3
7.3 Power ON/OFF ................................................................................................... 3
8. LED Indications ..............................................................................................................4
9. Setup and Configuration ................................................................................................4
10. OTA ..............................................................................................................................4
11. Tracking platform ......................................................................................................... 4
B2316 User Manual V1.0
http://www.mictrack.com
1
1. Overview
B2316 is a GPS bracelet that uses the latest low-power Cat M1 & NB-IoT technology,
fusion positioning technology and multiple sensor technologies, and built-in a eSIM card.
Including temperature monitoring, SOS alarm, body temperature, heart rate, step, indoor
and outdoor positioning, Geo-fence, historical track query etc.
The data will be automatically reported to the server and mobile APP periodically.
The B2316 GPS bracelet is small, lightweight, and deeply waterproof, and is suitable for
all-weather wear. It can be used for monitoring in schools, prisons, nursing homes, factories,
and hospitals.
2. Features
CAT M1 & NB-IoT & Network
Real-timing tracking
GPS+WiFi+LBS Positioning
History record check
Geo-Fence alarm
SOS alarm
Body temperature report
Heart rate report
Blood pressure report
Low battery alarm
Power saving mode
Long standby up to 72 hours
P67 Waterproof
PC & Mobile App tracking
Open API/Protocol
OTA
3. Applications
COVID-19 Back to work
Isolating people
Entry from the airport
Enterprise
Crowd place
Hospital
School
Kids
B2316 User Manual V1.0
http://www.mictrack.com
2
4. Specifications
Item
Specifications
Dimension
43(L)*23(W)*13(H)mm
Weight
30g
Charging mode
Magnetic USB charging Cable DC 5V
Backup battery
3.7 V 160mAh
Power consumption
30uA standby current
Working time
80 hours every 5mins upload interval
130 hours every 30mins upload interval
360 hours every 60mins upload interval
Working temperature
-20°C to 65°C
Cellular Bands
Cat M1 (LTE-M, eMTC)
B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26
/B27/B28/B66/B85
NB-IoT (Cat NB2)
B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28
/B66/B71/B85
Bluetooth
Low Power Bluetooth BLE (OTA)
Positioning
GPS, WiFi, LBS
Tracking Sensitivity
-162 dBm
Sensor
Accelerometer, Temperature sensor, Heart rate sensor, blood
pressure sensor
Screen
0.49 inch OLED
LED
GREEN
B2316 User Manual V1.0
http://www.mictrack.com
3
Button
SOS
SIM Card
6*5mm eSIM (MFF2)
Waterproof
IP67
5. B2316 interface
6. In the box
1* B2316 GPS Tracker
1* Magnetic USB charging cable
1* Quick Start Guide
7. First Use
7.1 SIM Card
The devices built in eSIM Card, no need to install additional SIM card
7.2 Charge the device
Please charge the device before using it for the first time.
The green light is flashing means under charging, if the green light is on it means
fully charged.
7.3 Power ON/OFF
Connect the charging cable will auto power ON, if the battery is low, it will power
OFF.
B2316 User Manual V1.0
http://www.mictrack.com
4
8. LED Indications
9. Setup and Configuration
At first time to use please setup the device via Bluetooth App, please check this post:
https://help.mictrack.com/articles/how-to-setup-b2316-via-bluetooth-app/
Once setup correct and the device will communication with your server.
10. OTA
You can upgrade the firmware via Bluetooth App, please check this post:
https://help.mictrack.com/articles/how-to-upgrade-b2316-firmware/
11. Tracking platform
Web: http://aiday.com.cn
Input your Account and password to login
Status
Description
Green Blinking
Charging
Solid Green
full charged
