Microsemi 9001GO-ET
1-Port, 802.3at Outdoor PoE Midspan
User Installation Guide
Deutsch
Copyright 2016 Microsemi Page 2
PD-9001GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Notice
It is Microsemi’s policy to improve its products as new technology,
components, software, and firmware become available. Microsemi,
therefore, reserves the right to change specifications without prior
notice.
Technical Support
If you encounter problems when installing or using this product, please
consult the Microsemi website at: http://www.Microsemi.com.
USA/Canada: +1-949-380-6245
POEsupport@microsemi.com
Copyright 2016 Microsemi Page 3
PD-9001GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Product Overview
Microsemi PD-9001GO-ET is a 1-Port 802.3at Gigabit PoE Outdoor
Midspan that offers a cost effective, IEEE 802.3atTM compliant
solution, guaranteeing 30 Watts of power and ensures safe and
reliable operation in outdoor environments for standard PoE data
terminal. The PD-9001GO-ET supports 10/100/1000Mbps data rates
and is powered via wide-range AC input (100-240VAC).
The PD-9001GO-ET is IP67 rated and has extended temperature
range so it can be installed in an outdoor environment. In a typical
installation the PD-9001GO-ET will provide power to outdoor
devices such as WLAN AP, WLAN Mesh, or to an IP Camera, etc.
PD-9001GO-ET EMC Compliance:
CE:
oEN55024, EN61000-4-5 Class 5 (6KV on AC Lines)
oEN55022 class B
FCC Part 15 class B
VCCI
PD-9001GO-ET Safety Compliance:
UL60950-1
UL60950-22
GS Compliance
PD-9001GO-ET Lightning Protection:
Designed to meet GR-1089-CORE lightning protection
requirements
Designed to meet ITU K.21 lightning protection- Enhanced level
Other Standards and Approvals:
IEEE 802.3at & IEEE 802.3af (PoE) standards
RoHS Compliant
WEEE Compliant
REACH Compliant
Copyright 2016 Microsemi Page 4
PD-9001GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Dust & Water protection
oIEC60529, level IP67
oNEMA 250, level 4x
Note
Do not use cross-over cable between the PoE Midspan output
port and load device.
WARNING
Take extra care when connecting the AC power inlet terminals, so
that 'N', 'L' and 'Ground' are connected to the proper polarity.
Ensure the AC power is within the allowed range.
Mounting Instructions Installation
Note: Before mounting the PoE Midspan to a fixed location:
To insure weather-proof connection in order to meet IEC60529
level IP67. PoE Midspan AC power plug needs to be connected to
a weather-proof AC power source box.
There is no “On-Off” switch; simply plug the PoE Midspan into an
AC main power source.
PoE Midspan AC power lines should be connected to the socket-
outlet that shall be installed near the equipment and be easily
accessible.
Copyright 2016 Microsemi Page 5
PD-9001GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Product View
Figure 1
Installing the unit
Warning
Earth ground screw must be connected to Earth ground in all
types of installations.
Step1: Connect the chassis bolt to earth ground.
CONNECT TO
EARTH GROUND
USE A TORQUE OF 10Lb-in (1.1Nm) - 15Lb-in(1.7Nm)
FOR TIGHTENING THE NUT
Figure 2
Copyright 2016 Microsemi Page 6
PD-9001GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Step 2: There are two options for the installation of PD-9001GO-ET:
A. Wall installation –PoE Midspan unit can be mounted on a
wall/bench (all kind of flat surfaces: wood, brick, concrete
etc.) using the mounting holes.
B. Pole installation - using optional mount kit (sold separately).
Step 2A: Wall installation
Fasten the PD-9001GO-ET using three screws, see figure 3 (Screw
holes are marked 1, 2, 3 & 4):
184.8
117.8
Figure 3
Copyright 2016 Microsemi Page 7
PD-9001GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Step 2B: Pole installation using optional mount kit (sold separately)
1.
2.
Warning: Mounting bracket must be connected to earth ground!
Copyright 2016 Microsemi Page 8
PD-9001GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Step 3A: Pole of 1” (25.4mm) < ø < 3” (76.2mm)
Copyright 2016 Microsemi Page 9
PD-9001GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Step 3B: Pole of- 3” (76.2mm) < ø < 8” (203.2mm)
1. Insert Screwdriver, press and rotate counter-clockwise to unlock
2. Pull cap away from unit
Copyright 2016 Microsemi Page 10
PD-9001GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
N L
PE
Clamping
NUT Seal BodyClamp spring Body Female
Housing
Click
Lead Rails
Step 4: AC Cable installation instruction:
Tools: Wire stripper, Solid Wrench No.30 or Monkey Wrench wide than 3cm.
Note: Please use certified outdoor cable with thickness diameter of 6-10mm with
18AWG Max gauge and 300V insulation rating.
1. Connector Parts:
2. Insert the cable through the parts, crimp and screw the wire leads
using 0.8 N*m torque
3. Push Housing into Body according to lead rails
4. Insert Seal and Clamp spring into body, then tighten the nut using
4N•m torque
5.
Figure 4
