Microscan Vision MINI Manuel utilisateur

Vision MINI Smart Camera Guide

83-016300-02 Rev B

Microscan Systems, Inc.

Tel: 425.226.5700 / 800.251.7711

Fax: 425.226.8250

ISO 9001 Certified

Issued by TüV USA

allowing customers to operate and/or service Microscan manufactured equipment and is not to be released,

reproduced, or used for any other purpose without written permission of Microscan.

Throughout this manual, trademarked names might be used. We state herein that we are using the names to the

benefit of the trademark owner, with no intention of infringement.

Disclaimer

The information and specifications described in this manual are subject to change without notice.

Latest Manual Version

For the latest version of this manual, see the Download Center on our web site at:

www.microscan.com.

Technical Support

For technical support, e-mail: help[email protected].

Warranty and Terms of Sale

For Standard Warranty information, see: www.microscan.com/warranty.

Microscan Systems, Inc.

Renton Headquarters

425.226.5700 / 800.251.7711

Nashua Office

603.598.8400

Microscan Europe

011 31 172 423360

Microscan Asia Pacific

65 6846 1214

Vision MINI Smart Camera Guide iii

Contents

PREFACE Welcome! v

Purpose of This Manual v

Manual Conventions v

CHAPTER 1 Introduction 1-1

Product Summary 1-2

Features and Benefits 1-2

Applications 1-3

Package Contents 1-3

Vision MINI Smart Camera Models 1-4

Part Number Structure 1-4

CHAPTER 2 System Components 2-1

Hardware Components 2-1

Important Label Information 2-5

Mounting and Wiring the Vision MINI Smart Camera 2-5

Status Indicators 2-10

AutoVISION Button 2-11

CHAPTER 3 Optics and Lighting 3-1

Optics 3-2

Illumination 3-3

APPENDIX A Connector Pinouts A-1

Vision MINI Smart Camera Connectors A-2

Contents

ivVision MINI Smart Camera Guide

APPENDIX B Cable Specifications B-1

61-000208-01 USB Type A to USB Type B Plug Cable B-2

61-000105-01 Host Cable, MS-Connect 210 to Host, Stripped to 9-Pin

Socket

B-3

61-000196-02 Vision MINI USB / I/O Cable (Attached) B-4

61-300026-03 Communication Cable, DB25 Plug to DB9 Socket B-6

97-000002-02 Power Supply, 90-254 VAC, +5VDC B-7

97-100004-15 Power Supply, 90-254 VAC, 24VDC, USA/Euro Plug B-8

99-000017-01 Photo Sensor, Visible, NPN, Dark On B-9

99-000017-02 Photo Sensor, Visible, NPN, Light On, MS-Connect 210

Configuration B-10

99-000019-01 Photo Sensor, Visible, NPN, Light On, USB Configuration B-11

APPENDIX C General Specifications C-1

Dimensions C-3

Field of View and Working Distance C-4

Vision MINI Smart Camera Guide v

Preface

PREFACE Welcome!

Purpose of This Manual

This manual contains detailed information about the Vision MINI Smart

Camera.

Manual Conventions

The following typographical conventions are used throughout this manual.

• Items emphasizing important information are bolded.

• Menu selections, menu items and entries in screen images are

indicated as: Run (triggered), Modify..., etc.

Preface

viVision MINI Smart Camera Guide

Vision MINI Smart Camera Guide 1-1

Introduction

CHAPTER 1 Introduction

FIGURE 1–1. Vision MINI Smart Camera

Chapter 1Introduction

1-2 Vision MINI Smart Camera Guide

Product Summary

The Vision MINI Smart Camera is designed for reliable vision performance

in embedded identification and inspection applications. As the world’s

smallest fully-integrated vision system, the Vision MINI’s compact size

and wide angle optics provide the best performance available for

machine vision tasks at close range.

The Vision MINI allows OEM design engineers to implement inspection,

color matching, symbol decoding, OCR, and more, in a single compact

solution. The camera’s small form factor allows flexible positioning in tight

spaces. The lightweight and durable magnesium alloy case weighs less

than 2 ounces.

Pressing the AutoVISION button at the back of the Vision MINI enables

real time dynamic autofocus. When an object is centered in the field of

view and the AutoVISION button is pressed, the camera automatically

adjusts focal distance and sets internal parameters to optimize image

captures.

AutoVISION software, designed for use with the Vision MINI, provides an

intuitive interface, step-by-step configuration, and a library of presets that

allow easy setup and deployment. For more complex vision applications,

the system can be upgraded from AutoVISION to Visionscape.

Features and Benefits

• World’s smallest fully functional vision system

• Virtual Ethernet over USB

• OEM-ready for easy integration

• Integrated lighting and autofocus lens

• Flexible programming options for custom applications

• AutoVISION button for automatic targeting, calibration, and triggering

• Simplified configuration with AutoVISION software

Applications

Introduction

Vision MINI Smart Camera Guide 1-3

Applications

• Part presence/absence

• Color detection and matching

• Medical device inspection

• Fiducial location

• Part location/orientation detection

• Packaging

• Robotics

• Auto ID (Data Matrix and other 2D symbologies, 1D, OCR)

Package Contents

Before you install AutoVISION software and connect your Vision MINI

Smart Camera, please take a moment to confirm that the following items

are available:

• Vision MINI Smart Camera — Your package contains one of the

available models listed in Table 1–1.

• USB Type A to USB Type B Cable

• AutoVISION Software Installation USB Drive

Chapter 1Introduction

1-4 Vision MINI Smart Camera Guide

Vision MINI Smart Camera Models

Table 1–1 lists and describes the Vision MINI Smart Camera models,

including acquisition modes and resolutions.

Part Number Structure

TABLE 1–1. Vision MINI Smart Camera Models

Part Number Vision MINI Smart Camera Model

GMV-6300-2100G Vision MINI Smart Camera, USB, SD, WVGA, Built-In Light, AutoVISION

GMV-6300-2102G Vision MINI Smart Camera, USB, SD, WVGA, Built-In Light, AutoVISION + Visionscape

GMV-6300-2110G Vision MINI Smart Camera, USB, SD, SXGA, Built-In Light, AutoVISION

GMV-6300-2112G Vision MINI Smart Camera, USB, SD, SXGA, Built-In Light, AutoVISION + Visionscape

GMV-6300-2172G Vision MINI Smart Camera, USB, SD, Color QXGA, Visionscape

GMV-6300-2200G Vision MINI Smart Camera, USB, HD, WVGA, Built-In Light, AutoVISION

GMV-6300-2202G Vision MINI Smart Camera, USB, HD, WVGA, Built-In Light, AutoVISION + Visionscape

GMV-6300-2210G Vision MINI Smart Camera, USB, HD, SXGA, Built-In Light, AutoVISION

GMV-6300-2212G Vision MINI Smart Camera, USB, HD, SXGA, Built-In Light, AutoVISION + Visionscape

GMV-6300-2272G Vision MINI Smart Camera, USB, HD, Color QXGA, Visionscape

GMV 6300

General

Machine

Vision

MINI

Comm Lens Sensor Options RoHS Custom

2 = USB 1 = Standard

Density

0 = WVGA 0 =

AutoVISION

G = RoHS

compliant

0 to 99

1 = SXGA

2 = High

Density

7 = Color

QXGA

2 =

AutoVISION +

Visionscape
