Mi 360° Home Security Camera 2K Pro
User Manual
Read this manual carefully before use, and retain it for future
reference.
The nameplate of this camera is located on its bottom.
Product Overview
Package Contents: Mi 360° Home Security Camera 2K Pro, power adapter,
charging cable, wall mounting kit, user manual
Front View Rear View
Reset Button
Micro-USB
Power Port
Loudspeaker
MicroSD Card
Slot (Visible
when lens is
facing upward)
Indicator
Lens
Microphone
Microphone
Reset
The Mi 360° Home Security Camera 2K Pro can be placed on horizontal
surfaces, such as desks, dining tables, and coffee tables. It can also be
mounted on a wall.
1. First use a pencil to mark the positions for the base mounting holes on the
wall, then drill two holes at the marked positions. The diameter of each hole is
approximately 6 mm, and the depth is approximately 30 mm.
Mounting the camera on a wall:
2. Insert a plastic wall plug into each drilled hole.
Installation
3. Place the side of the base with arrows facing
forward, and then align the holes. Insert the screws
and then tighten them into the wall plugs with a
Phillips head screwdriver.
4. Align the grooves on the bottom of the camera
with the raised part on the base, and then turn it
clockwise until it locks into place.
Notes:
1. The wall must be able to support at least three times the total weight
of the camera.
2. To prevent possible injury, the camera must be securely fixed to the
ceiling or wall according to the installation instructions.
How to Use
MicroSD
Installing a MicroSD card
Make sure the camera is turned off. Push the lens upward to reveal the
MicroSD card slot. Insert the microSD card into the card slot with its
contact points facing downward.
Note: Disconnect the camera from the power before installing or removing
a MicroSD card. Please use a genuine MicroSD card (up to 32GB)
manufactured by a qualified supplier. It is recommended to use a card with
a reading/writing speed of no less than U1/Class 10.
Indicator
Blue: Connected successfully/Working properly
Blinking blue: Network error
Quickly blinking orange: To be connected
Slowly blinking orange: Updating
Note: When the camera is working, do not turn the lens of the camera nor
force it to rotate. If the positioning of the lens is inaccurate, please calibrate
it in the Mi Home/Xiaomi Home app.
Turning on the camera
Plug the charging cable into Micro-USB port on the back, the camera
automatically turns on, and the indicator quickly blinks orange.
Reset
Connect with Mi Home/Xiaomi Home App
Restoring factory settings
In case the network the camera is connected to, or the Mi account the
camera is paired with has to be changed, use a pin to press and hold the
reset button for about five seconds to restore factory settings. Then
reconnect the network and the app with the camera.
Note: Restoring factory settings will not delete the content on the MicroSD
card.
This product works with Mi Home/Xiaomi Home app *. Control your device,
and interact it and other smart home devices with Mi Home/Xiaomi Home
app.
Scan the QR code to download and install the app.
You will be directed to the connection setup page if the
app is installed already. Or search "Mi Home/Xiaomi
Home" in the app store to download and install it.
Open Mi Home/Xiaomi Home app, tap "+" on the
upper right, and then follow prompts to add your device.
* The app is referred to as Xiaomi Home app in Europe
(except for Russia). The name of the app displayed on
your device should be taken as the default.
Note: The version of the app might have been updated, please follow the
instructions based on the current app version.
Make sure the camera turns on and the network connection is stable during
connecting. The indicator is quickly blinking orange when waiting for a
connection, and turns into blue once the camera is successfully connected.
In the app, you can view the real-time surveillance, adjust the sharpness of the
image, adjust the horizontal and vertical angles, capture and record, and make
calls.
Real-time Surveillance
The camera can automatically switch to night vision mode at night according
to the change in ambient light. The camera is equipped with built-in infrared
night vision lights reaching a night vision distance of up to 9 meters, which
enables it to clearly capture videos in the dark.
Infrared Night Vision
Playback
The playback feature of the camera is only available when a compatible
MicroSD card is installed.
Once a MicroSD card is installed and the camera is plugged in, it will
automatically start recording video. Tap the playback button in the app,
then drag the timeline to select the time period you want to playback. The
maximum supported playback speed is 16x.
Home Surveillance Assistant
When the home surveillance assistant is enabled, the camera will record
videos if it detects human movement and changes in real-time within its
surveilled area. Then you will get the app push notification.
You can enable or disable the function of automatic surveillance in the app.
You can set 24-hour, daytime, nighttime, custom period surveillance, alert
sensitivity and alert time intervals, etc.
In the app, you can select the device sharing option in the settings menu to
share the camera with others. The users, you share the camera with, need to
download the Mi Home/Xiaomi Home app and log in with their Mi account to
view contents.
Video Sharing
When recording is not required, tap " " in the app to enable the physical
lens blocking function. The camera will automatically adjust the lens so that
it is covered by the casing of the camera itself to protect the user's privacy.
Physical Lens Blocking
Note: Illustrations of product, accessories, and user interface in the user
manual are for reference purposes only. Actual product and functions may
vary due to product enhancements.
Normal Blocked
