4
SAFETY INSTRUCTIONS
Use the finger protector to press in the food which is to
be sliced.
Only plug in the appliance when you want to use it.
Otherwise, remove the plug from the mains socket.
Never leave the appliance unattended during operation.
Never immerse the appliance in water or any other liquid.
Do not use the appliance if the cable or device is
damaged in any way.
Only use accessories provided by the manufacturer.
Ensure that the mains power socket is easily accessible.
Connect the mains cable always to a mains socket 240V
~ 50Hz which is easily accessible. The power socket
must be freely accessible so that you can unplug the
appliance quickly, if necessary.
Do not use the unit with an extension cable. There is a
risk of tripping.
Never undertake your own repairs
In case the power supply cord or the unit is damaged,
disconnect the AC mains plug immediately.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Under no circumstances should you attempt to open
and/or repair this unit on your own. Refer all servicing to
telefix at 1300 366 144
5
SETTING UP
Unpacking
Remove all packing materials. Remove the adhesive strip
from the finger protector.
WARNING!
Do not let children play with the plastic wrapping.
There is a risk of suffocation.
Check package contents
When unpacking, ensure that the following parts are
included:
Multi-slicer
Attachable finger protector
Operating instructions
Proper use
This appliance is intended for cutting firm foodstuffs (especially bread, cheese
and meat) into slices. The appliance is intended only for use indoors and for
private use. Never use the appliance for any other purpose.
The appliance is not intended for commercial purposes.
2
CONTENTS
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Check package contents . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
After use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3
SAFETY INSTRUCTIONS
Keep electrical equipment out of reach of children
The appliance is not intended for use by young children
or infirm persons without supervision.
Young children should be supervised to ensure that they
do not play with the appliance.
Use the equipment with extreme caution when children
are present.
Keep plastic packaging out of the reach of children.
There is a risk of suffocation.
Setting up the multi-slicer safely
Please ensure that the mains voltage corresponds with
the voltage specified on the rating plate before
connecting the equipment to the power supply.
Place the appliance on a sturdy, even levelled surface.
Do not place the appliance near the edge of the working
surface.
Always ensure that the area where the appliance is set up
is kept dry!
Never set up the appliance near hot surfaces.
Ensure that the power cable cannot get caught up during
use, does not trail over the appliance or hang over the
edge of the working surface.
Using the multi-slicer safely
The multi-slicer's blade is very sharp.
Never touch the cutting edge of the blade.
Only use the appliance with the food carriage down in the
operating position.
About these instructions
Read these instructions carefully before use. Note the warnings on
the appliance and in the operating instructions.
Always keep the operating instructions close to hand. If you sell the
appliance or give it away, please ensure that you also pass on these
instructions.
8
Safety Precaution
Do not use the appliance to cut frozen foods or bones
Do not use the appliance on products that may cause the blade to slow down due to food texture
(i.e. some cheese types)
This appliance is not intended for use by young children or infirm persons without
supervision. Young children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
10
TECHNICAL DATA
Power supply: 240V ~ 50Hz
Power output:150W
Blade:190mm diameter
Short-term operation:10 minutes continously with full load
6
OPERATION
Before initial use
The switch for adjusting the cutting depth is in the upwards
position.
Position 0. The rear wall is at the same height as the blade.
The finger protector is lying on the food carriage.
Wipe the moving parts with a dry cloth to remove any
packing remnants.
Usage
Prepare the food so that it lays well on the food-holder. If
the piece of food to be sliced is very large, cut it into
manageable pieces.
Do not use the appliance to cut frozen foods or
bones.
Set the cutting depth:
Turn towards +: thicker slices;
Turn towards –: thinner slices.
Place the food onto the food-holder.
Slide the food towards the rear wall using the finger
protector. If the piece of food is broader than the food-
holder you can hold it without using the finger protector.
However, make sure you keep your hand clear of the
blade!
Turn on the appliance (operating switch to position I)
The
blade starts to rotate.
Cut slices off the food by sliding the food carriage past
the blade and then pulling it back again.
Do not use the appliance for more than 10 minutes
continously with full load.
If the appliance overheats turn it off immediately and
allow it to cool down for at least 30 minutes.
After use
Switch the appliance off immediately after use. Never
leave it running when not in use.
Let the appliance cool down for a few minutes before you
use it again.
FOOD SLICER / MULTI SLICER
UNIVERSAL Blade Assembly Instruction
Dear Customer
Please note the correct assembly of the universal blade to the device:
As stated in the instruction manual on page 7, the universal blade can be taken out for cleaning purpose.
This should be done any time you feel necessary to keep up a proper hygiene. (Kindly be reminded to
be extremely careful and cautious when disassembling the device and taking out the blade as the edge
of the blade is extremely sharp and any improper handling can result in injuries.)
When reassembling the universal blade to the device please be aware of the following:
The blade holder of the device and the blade are equipped with a middle ring made of plastic.
The plastic ring fixed to the device comes with a FEED HOLE and the plastic ring fixed to the universal
blade comes with a GUIDE PIN (please refer to the line drawing below).
When reassembling the universal blade to the device, please ensure that the GUIDE PIN is properly
aligned with the FEED HOLE as indicated by the arrows (markings) on the plastic parts. (Any different
assembly would cause the blade to be not centred that will cause an out-of-centre run of the universal
blade and will cause damages.)
With assembling the 2 parts at the position of GUIDE PIN and FEED HOLE a smooth run of
the universal blade will be assured.
9 7
CLEANING
The parts of the appliance that come into immediate
contact with foodstuffs (blade, food-holder, finger
protector, floor plate, rear wall behind the blade) should be
cleaned after every use. Clean these parts immediately after
use, so that no deposits build up on them.
Before cleaning always pull the plug out.
Remove the cutting blade by using a suitable object, e. g.
a coin, to turn the fastening screw towards the right.
To clean the appliance use a soft cloth or sponge, warm
water and soap suds, if necessary, to remove fat
deposits.
If you use soap suds, always rinse them off using clean
water.
Dry all parts of the appliance thoroughly.
After cleaning, replace the blade so that the plastic
guides on the rear side slot into the corresponding slots.
When the blade has clicked into place replace the screw
and tighten it by turning it towards the left.
Clean the housing using only a damp cloth.
Never use scouring creams or powders, pan cleaners
etc. Do not use sharp or pointed objects to remove
food remains. These could damage the appliance!
Do not use the appliance again until is completely dry!
WARNING!
Never
immerse the
appliance in water or
other liquids! Do not
clean the appliance
or the removable
parts in the
dishwasher.
WARNING!
The blade is
very sharp!
MESMS-008-150
Instruction manual
