Meyer Sound UPL-1 Manuel utilisateur

radial horn housed in a vented

cabinet. An active crossover,

optimized pole-zero response

correction filters, loud-

speaker element protection

circuitry and dual power

amplifiers are built directly

into the enclosure.

Both UPL-1 drivers are of

a proprietary design and are

individually factory-tested for

maximum linearity. The high-

frequency horn driver is of an

entirely new configuration,

employing a titanium dome

The Meyer Sound UPL-1 is a

self-contained, high-definition

powered loudspeaker that is

suitable for a wide variety of

high-quality sound reinforce-

ment applications. It is

optimized to approximate a

true point-source radiator

within its coverage area, and

features a frequency response

of ±2 dB from 50Hz to 18 kHz.

The UPL-1 comprises a 10-

inch cone low-frequency driver

and 1-inch high-frequency

driver with 90°by 40°modified

FEATURES

and fabric suspension in a

patented, low distortion design

(U.S. patent number

4,152,552). It is coupled to

a modified radial horn that

provides excellent directivity

control with wide horizontal

high-frequency coverage.

The UPL-1’s power am-

plifiers utilize complementary

power MOSFET output stages

in a class AB configuration.

Input sensitivity is switchable

to either +4 dBu or -10 dBV.

High Definition Reinforcement Loudspeaker

UPL-1

Self-powered

Two way bi-amplified

Electronically corrected

Individually

factory-aligned

Patented horn driver

Modified Radial horn

PATENTED

Meyer

Sound

Superior

engineering

for the art

and science

of sound.

Acoustical

(each loudspeaker)

Coverage

Crossover

Transducers

Audio Input

Amplifiers

AC-Power

Physical

Notes

14.00"

20.75"

14.00"

16.42"

15.54"

8.00"

13.20"

8.50"

9.20"

8.88"

2.0"

PHYSICALDIMENSIONS CONTINUOUSOUTPUT

UPL-1SPECIFICATIONS

Frequency Response1

Phase Response

Maximum SPL

Dynamic Range

(-6 dB points)

Low Frequency

High Frequency

Type

Connector

Nominal Input Level

Type

Burst Capability (Low Frequency)

Burst Capability (High Frequency)

THD, IM, TIM

Dimensions

Weight

Finish

Protective Grill

Rigging

±2 dB from 50 Hz to 18 kHz2

-3 dB at 32 Hz and 20 kHz

124 dB peak @ 1 meter

>100 dB

90°H; 40°V

Optimized pole-zero filter combinations to complement transducer

response and to achieve acoustical transparency and flat phase3

10” diameter MS-15 cone (2)

1” titanium dome horn driver (1” voice coil)4

10kΩimpedance, electronically balanced

XLR (A-3) female

+4 dBu or -10 dBv, switchable

Complementary power MOSFET output stages

200 watts

100 watts

<.02 %

3-pin IEC 320 male inlet. Voltage selector switch for 100/120/220/

240 VAC, 50 or 60 Hz (accepts voltages from

90 to 260 VAC), 175 W maximum.

14" W x 20 3⁄4" H x 14" D (+ 2 1⁄2" additional depth for

amplifier chassis and 2" for grill with foam)

70 lbs (32 kg)

Black textured

Perforated metal screen, grey foam covering

3/8"-16 nut plates, top and bottom

1. Subject to room loading. Specified for 8 feet actual

distance between UPL-1 cabinet and a single boundary

surface, measured with one-third octave frequency

resolution in fixed ISO bands.

2. Specified with grill removed. Response tolerance ±3 dB

with grill screen and foam in place.

3. U.S. patent #5,185,801 (additional patent pending).

4. U.S. patent #4,152,552.

* Unless otherwise specified, all acoustical measurements

are performed at 1 meter from front baffle on highfrequency

horn axis. Acoustical decibels are specified re 20 µPa.

ALL UNITS IN INCHES

Meyer Sound Laboratories, Inc.

2832 San Pablo Avenue

Berkeley, CA 94702

tel: 510.486.1166

fax: 510.486.8356

e-mail: [email protected]

http: www.meyersound.com

®®

LISTED

3K59

COMMERCIAL

AUDIO SYSTEM

Meyer Sound Laboratories

has devoted itself to

designing, manufacturing,

and refining components

that deliver superb sonic

reproduction. Every part of

every component is

designed and built to

exacting specifications

and undergoes rigorous,

comprehensive testing

in the laboratories.

Research remains an

integral, driving force

behind all production.

Meyer strives for sound

quality that is predictable

and neutral over an

extended lifetime and

across an extended range.

Made by Meyer Sound, Berkeley, CA, USA

European Office:

Meyer Sound Europe

Dalston House

39-49 Hastings Street

Luton Bedfordshire

England, LU1 5BE

16k

500

250

125

100 110 120

Frequency (Hz)

UPL-1 - 04.553.002.01B
