HDMI EXTENDER



HDMI EXTENDER (By CAT-5e/6 cable)

Dear customer

Thank you for purchasing this product. For optimum performance and safety,

please read these instructions carefully before connecting, operating or adjusting

this product. Please keep this manual for future reference.

1.0 INTRODUCTION

The HDMI Extender by CAT-5e/6 uses two pieces of UTP cable to extend the

HDTV display up to 30 meters for 1080p It not only breaks the limitation of the

HDMI cable transmission lengthbut also CAT-5e/6 has more flexibility and

convenience in cable construction.

It is equipped with HDMI (high definition multimedia interface) connectors and is

capable of supporting DVI (digital visual interface) equipment when used with an

HDMI to DVI Adapter, providing greater flexibility and options when integrating

several home theater components.

It offers solutions for residential consumers: HDTV retail and show site, HDTV,

STB, DVD and Projector factories, noise, space and security concerns, data

center control, information distribution, conference room presentation, school and

corporate training environments.

1.1 BENEFITS

1) The length of HDMI cable is fixed and unchangeable after it is produced.

Because the HDMI connector can only be soldered or terminated by the

professional workers in factory, the users can not reduce or increase by

themselves. However CAT-5e/6 cables are available everywhere and be

processed easily by the user or installer.

2) Because the header of the long HDMI cable is big, using it must in hidden

method. What's more, it is not easy to bend the HDMI cable and to pull it

through the in-wall tube or tray. However, CAT-5e/6 cable has no such

problems.

3) Using this Extender together with UTP cable the transmission distance can be

up to 60 meters for 1080p. For the general HDMI cables, they must be

customized when the length is over 10 meters.

1.2 FEATURES

This HDMI Extender has many features that enable it to perform in a superior

manner. Among those features you will find:

HDMI EXTENDER



One pair as a full functional module, no need of setting.

CAT-5e/6 cable can substitute HDMI cable to achieve long distance

transmission.

Follows the standard of IEEE-568B.

Transmission distance can be up to 30 meters for 1080p while using UTP

cable.

Supports HDMI1.2a.

Supports highest video resolution 1080p.

Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.

Supports 8bit per channel (24bit all channel) deep color.

HDCP pass-through.

Supports uncompressed audio such as LPCM

Supports compressed audio such as DTS Digital, Dolby Digitalincluding

DTS-HD and Dolby True HD.

2.0 SPECIFICATIONS

Signal Inputs/Output

Input Video Signal 5 Volts p-p (TTL)

Maximum Single Link Range 1920x1080p

Output Video HDMI1.2a

HDMI Input/Output Connector Type A 19 pin

Operating Frequency

Vertical Frequency Range 50/60Hz

Video Amplifier Bandwidth 1.65Gbps/165MHz

Resolutions(HDTV)

Interlaced(50&60Hz) 480i,576i,1080i

Progressive(50&60Hz) 480p,576p,720p,1080p

Mechanical 1.8” W x 1” H x 3.2” D

Size(H-W-D) 45mmW x 25mmH x 81mmD

Weight(Net) 0.246KGs

Warranty

Limited Warranty 1 Year Parts and Labor

Environmental

Operating Temperature 0 to +70

Operating Humidity 10% to 85 % RH (no condensation)

Storage Temperature -10to +80

Storage Humidity 5% to 90 % RH (no condensation)

Power Requirement

External Power Supply 5V DC@2A(optional)

Power consumption (Max) 5W

Regulatory Approvals

Converter Unit FCC,CE,UL

Power Supply UL,CE,FCC

Accessories Adapter

HDMI EXTENDER



AC Power Adapter US standard, UK standard and so on

User Manual

3.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the shipping carton:

1) Main unit NO. 1 Sender

2) Main unit NO. 2 Receiver

3) 5VDC Power Supply.

4) User’s Manual

4.0 PANEL DESCRIPTIONS

Sender

Receiver

HDMI EXTENDER



1) HDMI input.

2) CAT-5e output2.

3) CAT-5e output1.

4) HDMI output

5) CAT-5e input1

6) CAT-5e input2

7) Power Input

5.0 CONNECTION AND OPERATION

1) Connect the HDMI input sources such asHD-DVDPS3STB etc.

2) Connect two CAT-5E cables to both the output of the sender and input of the

receiver.

3) Connect the HDMI output( such as : HD-LCDHD-DLP)into receiver.

4) Insert the DC side of 5v power supply if the 5v of the source is not enough.

Attention: Insert / Extract cable gently.

HDMI EXTENDER



5.1 CONNECTION DIAGRAM

DC 5V

CAT-5e/6 cable

Sender Receiver

CAT-5e/6 cable

HDMI signal source

such as STB

Display Such as

LCD TV

P/N0003
