LIFEBEING SENSOR MSA012 R Version: A0
Shenzhen Merrytek Technology Co.,Ltd
Add: No.17th Building, Dianda Guyuan Industrial Park, Mashantou, Matian, Guangming District, Shenzhen, China, 518106
Tel: +86 (0)755-2305 7253 Fax: +86 (0)755-2786 3012 Website: www.merrytek.com
All technical information is subject to the physical performance, Merrick reserves the right to final interpretation
page 3of 11
-25℃…+50℃/Humidity:85% (Non condensing)
Storage
Temperature/humidity
-35℃…+80℃/Humidity:85% (Non condensing)
EN300440; EN301489-1; EN55015; EN61547; EN62479
"L N ground" port diameter: 0.75-1.5mm2; 1-10V dim port diameter:
0.75-1.0mm2
5 years warranty@Ta 230V full load
3. Function
Instructions of signal detection: the sensor detects human walking, minor motion(such as body movement, turn up
head and others minor movements) and breathing to realize the detection of human existence in non-sleep state.
Big motion signal active Minor motion& Breathing signal maintain
*Big motion signal: Big motion for sensor triggering
* Minor motion signal:very small movement even only body motion can be collected , the indicator flashes once.
* Breathing signal:when no slight motion signal, only breathing signal can be collected, the indicator flashes for 3
times by detecting 3 effective breathing signals.
Built-in daylight sensor, MSA012 R adjusts the
luminaires illuminance automatically to maintain a
target illuminance, while detecting the natural light
intensity. Thus the purpose of complementing
natural light and artificial light is achieved. It can be
used in offices, airports, shopping malls and other
occasions where the brightness of lights needs to
be adjusted according to daylight during the day.
