MEN Mikro Elektronik NM50 Manuel utilisateur

User Manual

2016-05-1720NM50-00 E2

NM50

Mobile Gateway & WLAN Access Point

Industrial Stand-Alone Device

20NM50-00 E2 2016-05-17 Page 2

NM50 Mobile Gateway & WLAN Access Point

Maintenance Free and Extremely Rugged

The NM50 is a fanless and maintenance-free wireless access point, specifically designed

for use in railway cars and automotive applications operating in rugged environmental

conditions.

High Speed Internet and OpenWrt Firmware

The NM50 Access Point can support up to two WLAN modules, and provides reliable high

speed internet and local data connection to multiple WLAN compatible devices. A

configurable firewall protects WLAN clients and supports secure and uninterrupted

internet data access. The full-featured and modifiable firmware OpenWrt, allows easy

configuration of features.

High Performance Processor

The NM50 Access Point is based on QorIQ Power PC CPU technology from NXP. The

system is designed for fanless operation in temperatures ranging from -40 to +70°C

(+85°C for up to 10 minutes). Its special aluminum housing with cooling fins serves as a

heatsink for the internal electronics, and in this way provides conduction cooling. As a

member of the MEN family of extremely rugged industrial box PCs, the NM50 provides

the same flexibility and scalability, as well as a look and feel which is common to the

family.

Extended Coverage and Service Availability

A redundant upstream connection to a local server, or downstream to other access

points, to extend coverage and increase availability of service, is achieved via the two

Gigabit Ethernet ports available on 8-pin M12 connectors.

Compliant to Railway and Automotive Standards

The voltage supply for the fully configured NM50 Access Point is designed for maximum

flexibility and supports wide range input supply voltages from 14.4 to 154 VDC, and

meets all EN 50155 requirements for voltages ranging from 24 to 110 VDC. It is also fully

compliant to ISO 7637-2 (E-mark for automotive) standard.

Adaptable to Specific Application Needs

The NM50 comes in two standard versions and can be adapted to meet specification

application needs. Some of the most important configuration options include the

number of WLAN radios and type of upstream link.

20NM50-00 E2 2016-05-17 Page 3

Diagram

USB2.0SeriesAInterface

DiscreteI/O

USB2.0SeriesBInterface

Status/ActivityLEDs

AntennaRP‐TNCConnectors

EarthingStud

PowerSupplyConnector

GigabitEthernetM12A‐CodedConnectors

AntennaRP‐TNCConnectors

MountingHoles

Frontpanelismodeldependent.

20NM50-00 E2 2016-05-17 Page 4

Technical Data

Supported Port Types

The following configurations are available:

-Entry: 1x 10/100/1000BASE-T M12 connector, wide range power input,

1x WLAN Radio, 2x RP-TNC antenna connectors (Model: 09NM50-00)

-High End: 2x 10/100/1000BASE-T M12 connectors, wide range power input,

2x WLAN radio, 4x RP-TNC antenna connectors, 1x USB 2.0 series A,

1x USB 2.0 series B, 2x discrete I/O) (Model: 09NM50-01)

CPU

NXP QorIQ P1013

-One high-performance Power Architecture e500v2 core

-800 MHz processor core frequency

Memory

32 KB L1 instruction cache

32 KB L1 data cache

256 KB L2 cache/SRAM

1 GB DDR3 SDRAM system memory

-Soldered

32 MB NOR Flash

Mass Storage

Via USB 2.0 host port at the front (Model: 09NM50-01)

Protocols and Functionality

Management I/F

-Integrated FW WEB/browser based setup and maintenance

-Local interface

-Firmware update from USB and Ethernet

Firewall

-Full featured firewall

-SSID show/hide

-MAC/IP/port filtering

-Multiple zone

Please contact MEN sales for configuration possibilities.

20NM50-00 E2 2016-05-17 Page 5

Technical Data

Security

-WEP 64 and 128 bit

-WPA/WPA2 Personal and Enterprise

General Protocols

-Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, PPPoE,

DHCP

AP Protocols

-A R P, B O OT P, D H C P, S T P / R S T P ( I E E E 8 0 2 . 1 D / w )

Routing

-Optional feature when Cellular upstream option is selected

-Static and dynamic routing, IPv46 IPv6, TCP/IP, UDP, ICMP, STP, RSTP, MSTP, RIPv1,

RIPv2, RIPng

Remote monitoring and maintenance via Ethernet and WLAN

Local monitoring and maintenance via USB device port (Model: 09NM50-01)

Software initiated restart

Watchdog

Connectivity

USB host at front for mass storage (Model: 09NM50-01)

USB device for maintenance (Model: 09NM50-01)

WiFi Network

-Up to two WiFi 802.11b/g/n/ac modems (UC-Option)

-2x2 MIMO supported

-Optional antenna diversity for each radio

-Maximum data rate 300 Mbit/s (n); 54 Mbit/s (g), 11 Mbit/s (b)

-Both 2.4GHz and 5GHz supported (depending on configuration)

-Unlimited parallel users; Bandwidth-limited to 60 per WiFi RF interface

Cellular Network (Available on request only)

-3.5G/4G modem (UC-Option)

Discrete I/O (Model: 09NM50-01)

Opto-isolated output (open collector) user programmable status output

-Reports device status to external devices

-Freely programmable via Web browers or console I/F

-Report sevice error signal/flag to host option

Opto-isolated output user programmable input

-Freely programmable via Web browers or console I/F

-Report external device status to Access Point option

-Report 'engine off' in bus applicaion option

One dedicated W_Disable input

-Active low signal to disable RF operation

-Direct disable of radio operation on either WLAN or cellular cards

Discrete input levels

-Input current for high:

-Input current for low: <1 mA

-Input switching level: 40 to ±5%

Independent input reference voltage range 0 to 154 V

Optocoupler shutter control option

Only available on the NM50 version with full configuration

20NM50-00 E2 2016-05-17 Page 6

Technical Data

Front Interfaces

One USB 2.0 series A, host port (Model: 09NM50-01)

-Series A connector at front panel

-Firmware and configuration update support

One USB 2.0 series B, device port (Model: 09NM50-01)

-Series B connector at front panel

-Console-mode maintenance support

Ethernet 1

-10/100/1000Base-T Ethernet channels

-M12 8-pin A-coded connector

-Two LEDs to signal LAN link and activity status

Ethernet 2 (Model: 09NM50-01)

-10/100/1000Base-T Ethernet channels

-M12 8-pin A-coded connector

-Two LEDs to signal LAN link and activity status

Antenna

-Two Type RP-TNC antenna connectors (Model: 09NM50-00)

-Four Type RP-TNC antenna connectors (Model: 09NM50-01)

Discrete I/O (Model: 09NM50-01)

-6-pin double row connector, 3.5 mm

LEDs

-Power status

-Fault LED: Indicates error codes from the board controller

-Ethernet link and activity status

-User LEDs for WLAN activity

Power Input

-RM3.5 3-pol plug-in connector

In-System Interfaces

One PCI Express Mini Card slot (09NM50-00)

Two PCI Express Mini Card slots (09NM50-01)

One SIM card slot on PCI Express Mini Card slot 2

Electrical Specifications

Primary power supply

-14.4 to 154 VDC, nominal voltages 24, 36, 48, 72, 96 and 110 VDC according to

EN50155

Power consumption: Less than 15 W

Power interruption class S2 (10 ms)

Mechanical Specifications

Dimensions: Height 44 mm x Width 125 mm x Length 220 mm

Weight: approx. 1.5 kg (depending on configuration)

Mounting

-Wall mount or top mount

20NM50-00 E2 2016-05-17 Page 7

Technical Data

Environmental Specifications

Temperature range (operation):

--40 to 70°C, with up to 85°C for 10 minutes according to class Tx (EN 50155)

-Natural convection, fanless operation

Temperature range (storage): -40 to +85°C

Relative humidity (operation): max. 95% non-condensing

Relative humidity (storage): max. 95% non-condensing

Altitude: -300 m to +3000 m

Shock: 50 m/s², 30 ms (EN 61373)

Vibration (function): 1 m/s², 5 Hz – 150 Hz (EN 61373)

Vibration (lifetime): 7.9 m/s², 5 Hz – 150 Hz (EN 61373)

Conformal coating of internal components

MTBF

70 000 h

Safety

Flammability

-UL 94V-0

Fire Protection

-EN 45545-2

Electrical Safety

-EN 60950-1, class I equipment

EMC Conformity (Automotive)

ISO7637-2 (E-mark)

Software Support

OpenWrt Firmware

See the MEN website for ordering information.

20NM50-00 E2 2016-05-17 Page 8

Product Safety

Electrostatic Discharge (ESD)

Computer boards and components contain electrostatic sensitive devices.

Electrostatic discharge (ESD) can damage components. To protect the

board and other components against damage from static electricity, you

should follow some precautions whenever you work on your computer.

Power down and unplug your computer system when working on the

inside.

Hold components by the edges and try not to touch the IC chips, leads,

or circuitry.

Use a grounded wrist strap before handling computer components.

Place components on a grounded antistatic pad or on the bag that came

with the component whenever the components are separated from the

system.

Only store the board in its original ESD-protected packaging. Retain the

original packaging in case you need to return the board to MEN for

repair.

20NM50-00 E2 2016-05-17 Page 9

About this Document

This user manual is intended only for system developers and integrators, it is not

intended for end users.

It describes the design, functions and connection of the product. The manual does not

include detailed information on individual components (data sheets etc.).

History

Issue Comments Date

E1 First issue 2016-04-18

E2 Updated system map, pinning information and

grounding conductor information.

2016-05-17

20NM50-00 E2 2016-05-17 Page 10

About this Document

Conventions

Indicates important information or warnings concerning situations which

could result in personal injury, or damage or destruction of the

component.

Indicates important information or warnings concerning the use of

voltages that could lead to a hazardous situation which could result in

personal injury, or damage or destruction of the component.

Indicates important information concerning electrostatic discharge which

could result in damage or destruction of the component.

Indicates important information or warnings concerning proper

functionality of the product described in this document.

The globe icon indicates a hyperlink that links directly to the Internet.

When no globe icon is present, the hyperlink links to specific information

within this document.

Italics Folder, file and function names are printed in italics.

Mono A monospaced font type is used for hexadecimal numbers, listings, C

function descriptions or wherever appropriate. Hexadecimal numbers are

preceded by "0x".

Comment Comments embedded into coding examples are shown in green text.

IRQ#

/IRQ

Signal names followed by a hashtag "#" or preceded by a forward slash "/"

indicate that this signal is either active low or that it becomes active at a

falling edge.

In/Out Signal directions in signal mnemonics tables generally refer to the

corresponding board or component, "in" meaning "to the board or

component", "out" meaning "from the board or component".

Ce manuel convient aux modèles suivants

Table des matières

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
