Memorex MMP8568-HIT Manuel utilisateur

TABLE OF CONTENTS

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 2

FCC Declaration . . . . . . . . . . . . . . . . . . . . . . 3

EIA Guidelines. . . . . . . . . . . . . . . . . . . . . . . . 4

Location of Controls . . . . . . . . . . . . . . . . . . . 6

Charging the Battery . . . . . . . . . . . . . . . . . . . 7

Downloading and Transferring Files . . . . . . . 8

Installing MP3 Player Utilities 5.10 . . . . . . . 12

Using MP3 Player Utilities 5.10

(Video Converter) . . . . . . . . . . . . . . . . . . . . 14

General Operation...................16

• Turning the Power On/Off. . . . . . . . . . . . 16

• MENU/Lock Button . . . . . . . . . . . . . . . . . 16

• Headphones Jack. . . . . . . . . . . . . . . . . . 17

• Volume Buttons . . . . . . . . . . . . . . . . . . . 17

Operation–Music Playback Mode ......18

• To Listen to MP3s/WMAs . . . . . . . . . . . . 18

• To Delete Songs from the Play Queue. . 20

• High-Speed Music Search . . . . . . . . . . . 21

• Forward/Reverse Skip . . . . . . . . . . . . . . 21

• Music Contextual Menu–Equalizer. . . . . 22

• Music Contextual Menu–Play Mode. . . . 23

• Music Contextual Menu–Color Theme . . 24

Operation–Video Playback Mode.......25

• To Watch Videos. . . . . . . . . . . . . . . . . . . 25

• High-Speed Video Search . . . . . . . . . . . 26

• Forward/Reverse Skip . . . . . . . . . . . . . . 26

Operation–Photo Playback Mode ......27

• To View Photos. . . . . . . . . . . . . . . . . . . . 27

• Thumbnail View . . . . . . . . . . . . . . . . . . . 28

• Slide Show View. . . . . . . . . . . . . . . . . . . 28

Settings Menu ......................29

Troubleshooting Guide...............40

Formatting the Player ................42

Resetting the Unit ...................43

Updating the Firmware ...............43

Specifications ......................44

• Distributing copies of MP3, WMA with DRM or WAV tracks without permission is a

violation of international copyright laws.

SAFETY:

• Vibration experienced during walking or exercising will not affect the player. However,

dropping the player or dropping a heavy object on the player may result in damage or

sound distortion.

• Avoid spilling any liquid onto or into the player.

• Do not leave the player in a location near heat sources; in a location subject to direct

sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel

surface; or in a car with the windows closed during periods of excessive heat.

ROAD SAFETY:

• Do not use headphones while driving, cycling or operating any motorized vehicle. It

may create a traffic hazard and it is illegal in some areas. It can be potentially

dangerous to play your headset at a high volume while walking, especially at pedestrian

crossings. You should exercise extreme caution or discontinue use in potentially

hazardous situations.

FCC WARNING:

• This equipment may generate or use radio frequency energy. Changes or

modiﬁcations to this equipment may cause harmful interference unless the

modiﬁcations are expressly approved in the instruction manual. The user could lose

the authority to operate this equipment if an unauthorized change or modiﬁcation

is made.

PRECAUTIONS

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003

du Canada.

FCC DECLARATION

This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: 1) This device may not cause interference, and 2) This

device must accept any interference received, including interference that may cause

undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shield cable must be used with this unit to ensure

compliance with class B FCC limits.

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start

of your musical enjoyment. Now it’s time to consider how you can maximize the fun

and excitement your equipment offers. This manufacturer and the Electronic Industries

Association’s Consumer Electronics Group want you to get the most out of your

equipment by playing it at a safe level. One that lets the sound come through loud and

clear without annoying blaring or distortion and, most importantly, without affecting

your sensitive hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher

volumes of sound. So what sounds “normal” can actually be loud and harmful to your

hearing. Guard against this by setting your equipment at a safe level BEFORE your

hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without

distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.

After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.

Since hearing damage from loud noise is often undetectable until it is too late, this

manufacturer and the Electronic Industries Association’s Consumer Electronics Group

recommend you avoid prolonged exposure to excessive noise. This list of sound levels

is included for your protection.

Decibel

Level Example

30 Quiet library, soft whispers

40 Living room, refrigerator, bedroom away from traffic

50 Light traffic, normal conversation, quiet office

60 Air conditioner at 20 feet, sewing machine

70 Vacuum cleaner, hair dryer, noisy restaurant

80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower

100 Garbage truck, chain saw, pneumatic drill

120 Rock band concert in front of speakers, thunderclap

140 Gunshot blast, jet engine

180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

EST. 1924

EIA

LISTENING

For A Lifetime

Want You

LOCATION OF CONTROLS

1. Headphone Jack

(HEADPHONES PART NO.

261-32000-E010*)

2. Display

3. Navigation πButton

4. Navigation √/Skip/Search o

Button

5. Navigation †Button

6. USB Jack

(USB CABLE PART NO.

337-01000-E050*)

7. Reset Button

(Inside the Recess Hole)

8. Volume + Button

9. Volume - Button

10. MENU/Lock Button

11. Power On/Off Button

12. Enter/Play/Pause ®p Button

13. Navigation ®/Skip/Search n

Button

SOFTWARE DISC PART NO. PA-E558*

*Consumer Replaceable Part

(See page 45 to order.)

CHARGING THE BATTERY

This unit has a built-in Lithium Polymer rechargeable battery. When the bars

in the battery indicator (in the display) become low (see Figure 1) and

especially when the bars turn red, recharge the battery as follows.

1. Connect the USB cable to the USB

jack on the bottom of this unit and to

the USB port on your computer (as

shown); “✓OK to Remove” will

appear on the screen. When

charging, the battery indicator will

cycle from the current battery level to

full. Once the battery is fully charged,

the indicator will stop cycling.

NOTES:

• When you disconnect this unit from your computer, this unit will turn on and update the

playlist automatically.It will take several seconds to several minutes to update the

player's library depending on the number of files that you have transferred to the player.

• It takes approx. 6 hours to charge the battery from empty to full. When fully charged,

the unit can playback for approx. 12 hours in Music Playback mode. (Actual playback

times may vary.)

• For data transfer, please use the USB cable (included) to connect the unit to

your computer.

Computer

USB Cable

USB Jack

Figure 1

DOWNLOADING AND TRANSFERRING FILES

SUPPORTED OPERATING SYSTEMS

This unit is compatible with Windows XP (SP2) with Windows Media Player 10,

or above.

Please refer to the following pages to learn how to: transfer video, music and photo

files, convert music on an audio CD into MP3 or WMA format using Windows Media

Player 10, transfer MP3/WMA files and WMA files with DRM 9 or 10 using Windows

Media Player 10.

NOTE: Visit www.Microsoft.com to download the corresponding Windows Media

Player for your computer.

MEDIA FILES SUPPORTED FORMATS

AUDIO FORMATS: MP3, MPEG 1/2/2.5 Layer 3 with a bit rate up to 320 kbps

(max.), WMA files with DRM 9 or 10 with a bit rate up to 320 kbps.

VIDEO FORMATS: AVI support (decoder: xvid, size: 128 x 128 resolution, Frame

Per Second: 30fps max, Bit Rate: 768 kbps max, Frequency Range: 8-48kHz,

Audio Format: 128kbps, 48kHz, Stereo CBR); WMV support (decoder complexity:

simple profile, size 128 x 128 resolution, Frame Per Second: 30fps max, Bit Rate:

384 kbps max, Frequency Range: 8-48kHz, Audio Format: 128kbps, 48kHz,

Stereo CBR).

PHOTO FORMATS: Baseline JPEGs.

IMPORTANT! Make sure the video resolution is 128 x 128; otherwise, the video file

will not be able to be played.

DOWNLOADING AND TRANSFERRING FILES (CONT.)

For Windows XP, you can also utilize Windows Media

Player 10 software to convert music on an audio CD into

MP3 or WMA format as follows:

1. Open the Windows Media Player 10 Browser, then

click on the “Rip” icon on the top tool bar. Insert a

music CD into the CD-Rom drive of your computer.

2. Click on the “Tools” menu option at the top menu

bar, then click on “Options”; the Option setting

menu will appear. Click on Rip Music and set the

Rip Music to the desired location on your computer.

Then, set the desired format for the newly ripped

music (MP3 format or Windows Media Audio format). Adjust

the audio quality as desired. When finished, click “OK” to

confirm the settings.

3. Click on the “Rip Music” icon to start ripping the music to

your computer.

4. When the music tracks are ripped, you can transfer them to

your player using Windows Media Player 10 as described

on the next page.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Memorex Lecteur MP3

Memorex

Memorex MMP8565C - 1 GB Digital Player Manuel utilisateur

Memorex

Memorex NMP4101-SBS - Npower Fission SpongeBob 1 GB Digital... Manuel utilisateur

Memorex

Memorex MMP3642 Manuel utilisateur

Memorex

Memorex MMP8564 - 512 MB Digital Player Manuel utilisateur

Memorex

Memorex 8564 Manuel utilisateur

Memorex

Memorex MPD8507 Manuel utilisateur

Memorex

Memorex MMP3731 Manuel utilisateur

Memorex

Memorex MMP8020R-BLK - 2GB MP3 Player Manuel utilisateur

Memorex

Memorex TouchMP Manuel utilisateur

Memorex

Memorex MPD8861PLL Manuel utilisateur

Memorex

Memorex MMP8575 - 2 GB, Digital Player Manuel utilisateur

Memorex

Memorex MMP8556 Manuel utilisateur

Memorex

Memorex MMP8500 - Biomorph 128 MB Digital Player Manuel utilisateur

Memorex

Memorex MMP8585 Manuel utilisateur

Memorex

Memorex MMP8595 Guide de démarrage rapide

Memorex

Memorex MMP8556 Manuel utilisateur

Memorex

Memorex MMP8570 - 512 MB Digital Player Manuel utilisateur

Memorex

Memorex MMP8551 Manuel utilisateur

Memorex

Memorex MMP3780 - 1 GB Digital Player Manuel utilisateur

Memorex

Memorex MMP8550 Manuel utilisateur

Memorex

Memorex Touch MP Manuel utilisateur

Memorex

Memorex MPD8859 Manuel utilisateur

Memorex

Memorex MMP8585C - 4 GB Digital Player Guide de démarrage rapide

Memorex

Memorex MPD8845 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
