Memorex MD6886 Manuel utilisateur

PERSONAL AM/FM STEREO/COMPACT DISC

PLAYER WITH 45 SECOND DIGITAL ANTI-SHOCK

PROTECTION

MODEL: MD6886

BEFORE OPERATING THIS PRODUCT, PLEASE READ THESE

INSTRUCTIONS COMPLETELY.

OPERATING INSTRUCTIONS

MD6886.O/M.QXD 2/11/03 8:14 AM Page 19

SAFETY PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

DANGEROUS VOLTAGE:

The lightning ﬂash with arrowhead symbol, within an equilateral

triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

ATTENTION:

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying

the appliance.

DANGER:

This product utilizes a Class 1 laser to read Compact Discs.

This laser Compact Disc Player is equipped with safety

switches to avoid exposure when the CD door is open and the

safety interlocks are defeated. Invisible and hazardous laser

radiation when open and interlock failed or defeated. Avoid

direct exposure to beam. Please do not attempt to defeat or

bypass the safety switches.

FCC WARNING:

This equipment may generate or use radio frequency energy. Changes

or modiﬁcations to this equipment may cause harmful interference

unless the modiﬁcations are expressly approved in the instruction man-

ual. The user could lose the authority to operate this equipment if an

unauthorized change or modiﬁcation is made.

SURGE PROTECTORS:

It is recommended to use a surge protector for AC connection.

Lightning and power surges ARE NOT covered under warranty for this

product.

MD6886.O/M.QXD 2/11/03 8:14 AM Page 1

INFORMATION:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interfer-

ence to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the fol-

lowing measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

• Do not open the CD compartment while the CD is rotating.

• Always keep the CD compartment closed when not in use.

• Keep all foreign objects out of the CD compartment.

• Place the unit on a stable surface.

• Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or close to heat radiating

appliances such as electric heaters.

• On top of other stereo equipment that radiates too much

heat.

• Places lacking ventilation or dusty places.

• Places subject to constant vibration.

• Humid or moist places.

SAFETY PRECAUTIONS (CONTINUED)

MD6886.O/M.QXD 2/11/03 8:14 AM Page 2

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of

your musical enjoyment. Now it’s time to consider how you can maximize the fun and

excitement your equipment offers. This manufacturer and the Electronic Industries

Association’s Consumer Electronics Group want you to get the most out of your equipment

by playing it at a safe level. One that lets the sound come through loud and clear without

annoying blaring or distortion and, most importantly, without affecting your sensitive

hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of

sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard

against this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

•Slowly increase the sound until you can hear it comfortably and clearly, and without

distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.

After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since

hearing damage from loud noise is often undetectable until it is too late, this manufacturer

and the Electronic Industries Association’s Consumer Electronics Group recommend you

avoid prolonged exposure to excessive noise. This list of sound levels is included for your

protection.

Decibel

Level Example

30 Quiet library, soft whispers

40 Living room, refrigerator, bedroom away from traffic

50 Light traffic, normal conversation, quiet office

60 Air conditioner at 20 feet, sewing machine

70 Vacuum cleaner, hair dryer, noisy restaurant

80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT

EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower

100 Garbage truck, chain saw, pneumatic drill

120 Rock band concert in front of speakers, thunderclap

140 Gunshot blast, jet engine

180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

EST. 1924

EIA

We

LISTENING

For A Lifetime

Want You

MD6886.O/M.QXD 2/11/03 8:14 AM Page 3

LOCATION OF CONTROLS

61 2 8 9 10 117

1312 1514 16 17 18

543

1. Battery Compartment (Inside

CD Compartment)

2. DC 4.5V Jack (Side of Unit)

3. SKIP/SEARCH/Tuning ( )

Button

4. SKIP/SEARCH/Tuning ( )

Button

5. STOP (■)/ POWER OFF

Button

6. PLAY/PAUSE ( ) /POWER

ON Button

7. Display

8. PRESET +/– Buttons

9. PROG (Program) Button

10. MODE Button

11. ESP/BAND Button

12. FUNCTION (CD/RADIO)

Switch

13. CD OPEN Switch

14. CD Compartment

15. DBBS (Bass Boost) Switch

16. VOLUME Control

17. PHONES (Headphones) Jack

18. LINE OUT Jack

–+

MD6886.O/M.QXD 2/11/03 8:14 AM Page 4

This CD player requires either two (2) “AA” cell batteries (not included) or

the AC adapter (not included).

BATTERY INSTALLATION

The battery indicator ( ) will appear in the CD display when the

batteries need replacing.

1. Open the CD Compartment, then open the

battery compartment door by pressing in on

the tab and then lifting it. To prevent the

possibility of losing the cover, it cannot be

removed.

2. Insert two (2) “AA” cell batteries (not included)

according to the polarity diagram inside the

battery compartment. Alkaline batteries are

recommended for the longest playing time.

AC OPERATION

To operate the unit using AC power, connect the AC adapter (not included) to

an AC outlet having 120V, 50/60Hz AC only. Plug the small end into the DC

4.5V jack on the side of the unit and connect the other end into the AC outlet.

The batteries are automatically disconnected when the AC adapter is used.

CAUTION: When not using AC power, disconnect the AC adapter from

the wall outlet by pulling the plug (not the cord). Do not touch the AC

adapter with wet hands. Fully insert the plug without exposing any part of

the blade.

DC 4.5V

–+

POWER SOURCES

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries speciﬁed.

2. Be sure to follow the correct polarity when installing the batteries as indicated next to the battery

compartment. Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with

fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or

injury from possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

(Follow battery manufacturer’s directions.)

–

MD6886.O/M.QXD 2/11/03 8:14 AM Page 5

To emphasize the bass, slide the

DBBS switch to the ON position. For

normal bass, slide the DBBS switch to

the OFF position.

To turn the unit on, press the

PLAY/PAUSE ( )/POWER ON

button ❶.

To turn unit off, Press the STOP (■)

/POWER OFF button ❷.

BASS BOOST TURNING POWER ON/OFF

AUTO POWER OFF

When the unit is stopped (Standby mode) for approximately one minute, the

power will automatically turn off.

OPERATION

Radio Sound Through a Home Audio System

By using a home audio connection cable (not included), superb radio sound can

be heard through your home audio system. Before making any connections, turn

off the power to all equipment.

Plug a connection cable (not included) between the LINE OUT jack on the side of

the CD player and the ampliﬁer’s AUX or CD input jack. (Do not connect it to the

ampliﬁer’s PHONO jack.)

NOTE: If the radio interferes with TV reception, move the unit away from the TV or

turn off the power to this unit.

MD6886.O/M.QXD 2/11/03 8:14 AM Page 6

RADIO OPERATION

Set the VOLUME control ❶ to minimum

and plug the headphone into the

PHONES jack. Press the PLAY/PAUSE

() /POWER ON button ❷to turn the

unit on.

TO LISTEN TO THE RADIO

Slide the FUNCTION switch ❶ to the

RADIO position. Press the ESP/BAND

button ❷ to select a band (AM or FM).

If listening to FM, press the MODE button

❸ to turn FM Stereo ON or OFF.



Press and release the SKIP/SEARCH/

Tuning ❶ or button ❷ to tune

a station. Press and hold the

SKIP/SEARCH/Tuning ❶ or

button ❷ for Auto Scan (see below).

Adjust the VOLUME control ❶ and DBBS

switch ❷ as desired. If FM STEREO

reception is weak/noisy, press the MODE

button ❸ to turn off Stereo, in this case

the reception will be monaural.



To turn the radio off, press the STOP

(■)/POWER OFF button.

5ANTENNAS

AM – This unit has a built-in ferrite bar

antenna, which provides adequate reception

in most areas. If reception is weak, turn the

unit to improve reception.

FM – The headphones act as an antenna for

FM. Extend the headphone wire for best FM

reception.

AUTO SCAN

Press and hold the SKIP/SEARCH/Tuning

or button for approximately one

second and the unit will automatically search

for the next available station.

MD6886.O/M.QXD 2/11/03 8:14 AM Page 7

RADIO OPERATION (CONTINUED)

Tune a desired station as described in

the previous section. Press the PROG

button; the PROG indicator will blink

and preset number will appear in the

display.

TO SET AND RECEIVE A STATION INTO MEMORY

While the PROG indicator is blinking,

select the desired preset using the

PRESET + ❶or – button ❷, then press

the PROG button ❸ to set the memory.

To recall a preset station, simply

press the PRESET + ❶or – button ❷to

select the desired preset.

You can set up to 10 AM and 10 FM stations into memory as follows:

MD6886.O/M.QXD 2/11/03 8:14 AM Page 8

CD OPERATION

Open the CD compartment lid by

sliding the CD OPEN switch ❶ to the

right. Gently press a disc, label side

up, onto the spindle until it locks in

place. Close the CD compartment lid.

Insert headphones into the PHONES

jack. Slide the FUNCTION switch ❷ to

the CD position.

While the unit is off, press the

PLAY/PAUSE ( )/POWER ON

button to start playback. To pause

PLAYBACK, press the PLAY/PAUSE

()/POWER ON button again, the

display will blink. Press once again to

resume playback.

TO PLAY A CD

Adjust the VOLUME control ❶ and

DBBS switch ❷ as desired. To skip

forward or backward through the tracks

on the disc, press the SKIP/SEARCH

❸or button ❹. To search

forward or backward through the tracks

on the disc, press and hold the

SKIP/SEARCH ❸or button ❹.

When the disc is through playing, it will

stop. Press the STOP (■)/POWER

OFF button to stop the disc before it is

ﬁnished; the total number of tracks will

appear. Press the STOP (■)/POWER

OFF button again while in the stop

mode to turn the unit off or wait

approximately 60 seconds and the unit

will automatically turn off.

MD6886.O/M.QXD 2/11/03 8:14 AM Page 9

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Memorex Lecteur MP3

Memorex

Memorex MMP3780 - 1 GB Digital Player Manuel utilisateur

Memorex

Memorex MPD8859 Manuel utilisateur

Memorex

Memorex MMP8560 Manuel utilisateur

Memorex

Memorex MMP8564 - 512 MB Digital Player Manuel utilisateur

Memorex

Memorex MPD8859 Manuel utilisateur

Memorex

Memorex MMP8620 Manuel utilisateur

Memorex

Memorex MMP3682 Manuel utilisateur

Memorex

Memorex MMP8568-ACM - 1 GB Digital MP3 Player Manuel utilisateur

Memorex

Memorex TouchMP Manuel utilisateur

Memorex

Memorex MMP3731 Manuel utilisateur

Memorex

Memorex MMP8001 Series Manuel utilisateur

Memorex

Memorex MPD8860 - CD / MP3 Player Manuel utilisateur

Memorex

Memorex MMP3774 Manuel utilisateur

Memorex

Memorex MMP3642 Manuel utilisateur

Memorex

Memorex MHD8021 - 2 GB Digital Player Manuel utilisateur

Memorex

Memorex MMP8570A Manuel utilisateur

Memorex

Memorex MMP8640 - 4 GB Digital Player Manuel utilisateur

Memorex

Memorex MMP8500 - Biomorph 128 MB Digital Player Manuel utilisateur

Memorex

Memorex MMP3642A Manuel utilisateur

Memorex

Memorex MPD8600 - Sports CD Player Manuel utilisateur

Memorex

Memorex MMP8567 - 2 GB Digital Player Manuel utilisateur

Memorex

Memorex MMP8500 - Biomorph 128 MB Digital Player Manuel utilisateur

Memorex

Memorex MMP8565C - 1 GB Digital Player Manuel utilisateur

Memorex

Memorex MHD8015 Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur

Kenwood

Kenwood M1GD50 Manuel utilisateur
