ATS220
ATS CONTROLLER
USER MANUAL
Software Version
No.
Version
Date
Note
1
V1.0
2018-9-1
Original release.
2
V1.1
2019-10-8
The function of phase number selection for
generator and mains input is added.
ATS220 ATS CONTROLLER USER MANUAL
1
Symbol Description
Symbol
Description
Note
Remind operators to operate correctly, otherwise it may cause
the equipment not to work correctly.
Be care
It is indicated that potential hazards can damage equipment
without proper precautions.
Warning
It is indicated if appropriate preventive measures are not taken,
potentially dangerous situations may result in death, serious
personal injury or significant property losses.
Chongqing Mebay Technology Co.,Ltd
Add: No6-2,Building 4, Gangan Rd, Jiangbei District, Chongqing.
Tel：+86-23-6869 3061
Fax：+86-23-6765 8207
Web：http://www.mebay.cn
http://www.cqmb.cn
E_mail：[email protected]
ATS220 ATS CONTROLLER USER MANUAL
2
Warning
1. The installation of this equipment must be carried out by professionals.
2. When installing and operating the controller, please read the entire instruction
manual first.
3. Any maintenance and commissioning of the equipment must be familiar with all the
equipment, safety standards and precautions in advance, otherwise it may cause
personal injury or damage to related equipment.
4. The engine must have an overspeed protection device independent of the
controller system to avoid casualties or other damage caused by engine out of
control.
5. After the installation of the controller is completed, please verify that all protection
functions are valid.
Be Care
1. Please keep the good connection of the power supply of the controller. Do not
share the connection lines of the positive and negative electrodes of the battery
with the floating charger.
2. During the operation of the engine, do not disconnect the battery,otherwise it may
cause damage to the controller.
ATS220 ATS CONTROLLER USER MANUAL
3
Catalogue
1、Summary………………………………………………………………………4
2、Main Features…………………………………………………………………4
3、Parameters Display…………… ……………… …………… ………………4
4、Parameters……………………………………………………………………4
5、Overall Dimension and Wiring Diagram…………………… … … … ……5
6、Installation Instruction…………………………… ………… ………………7
7、Panel and Display Instruction………………………………………………8
8、Control and Operation Instruction…………………………… ……………8
9、Parameters Setting…………………………………… ……………………10
10、Fault finding………………………………………………………………12
Notes:
1. All rights reserved. No part of this duplication may be reproduced in any material
form(including photocopying or storing in any medium by electronic means or others)
without the written permission of the copyright holder.
2. MEBAY Technology reserves the rights to change the contents of this document
without prior notice.
ATS220 ATS CONTROLLER USER MANUAL
4
Summary
ATS220 is one controller with ATS system of Mains and genset power,which can
control the ATS switch by auto or manual mode to apply for mains and gens power.It
is with 4 digits LED tube which can display the single-phase gens voltage, gens
frequency, mains voltage, mains frequency. ATS switch working status can be also
shown by LED.
All the parameters can be set through the front face buttons or PC port.
Main Features
32 units Micro-procession technology is used.
Wide voltage range: 8-36V.
4 digits LED tube which can display mains, voltage, frequency.
Totally 7 relay’s output, max current is 5A(250VAC).
1 group programmable switch input.
Parameters can be set by front face buttons.
Standard water-proof rubber, the protection level can reach at IP54;
All the connection are installed by European style terminals.
Simulated mains function, crank conditions can be chosen.
Parameters Display
Mains phase voltage
Mains Frequency
Gens phase voltage
Gens Frequency
Parameters
Options
Parameters
Operation Voltage
DC8-36V Continuous
Power Consumption
Standby：24V：MAX 1W
Working：24V：MAX 3W
Mains AC Voltage Input
30VAC-300VAC(ph-N)
Gens AC Voltage Input
30VAC-300VAC(ph-N)
Gens Close Output
5Amp(AC250V) free output
Mains Close Output
5Amp(AC250V) free output
Gen Start Relay
5Amp(AC250V) free output
Switch Value Input
Available if connecting with Battery -
Working Condition
-30-70℃
Storage Condition
-40-85℃
Protection Level
IP54：when waterproof rubber gasket is added
between controller and its panel
Overall Dimension
78mm*78mm*55mm
Panel Cutout
67mm*67mm
Weight
0.3Kg
ATS220 ATS CONTROLLER USER MANUAL
5
Overall Dimension and Wiring Diagram
Overall Dimension:
Descriptions of terminal connection
No.
Function
Description
Cable cross
sectional area
1
Power Input B-
DC8-36V Continuous.
2.5mm2
2
Power Input B+
2.5mm2
3
Remote Start Input
Ground connection is active.
1.0mm2
4
Close Gens input
Ground connection is active.
1.0mm2
5
Close Mains input
Ground connection is active.
1.0mm2
6
Gens Start Output
Volts free, Relay contact, Normally
Open output，Max5A(250VAC)
1.0mm2
7
1.0mm2
ATS220 ATS CONTROLLER USER MANUAL
6
8
Gens Close Output
Volts free, Relay contact, Normally
Open output，Max5A(250VAC)
1.0mm2
9
1.0mm2
10
Gens Voltage Input L
Gens voltage Input，AC30-300V
1.0mm2
11
Gens Voltage Input N
1.0mm2
12
Mains Close Output
Volts free, Relay contact, Normally
Open output，Max5A(250VAC)
1.0mm2
13
1.0mm2
14
Mains Voltage Input L
Mains voltage Input，AC30-300V
1.0mm2
15
Mains Voltage Input N
1.0mm2
Typical Wiring Diagram
N2
7
4
3
21
BATTERY FUSE 10A SWITCH
10
11 14
15
6
MODEL: ATS220
-VE
+VE
N1
G M
5
W T
V S
UR
L1 L2 L3 N
8 9 12 13
LN
GEN VOLTS
CLOSE CLOSE
CLOSE GENS CLOSE MAINS
REMOTE START
LN
MAINS VOLTS
AC 30-300V
DC 8-36V
AC 30-300V
GENS IN MAINS IN
GENERATOR
AUTO START
MECHANICAL
INTERLOCK
Note:Please don’t move battery during running status or it may cause the
controller broken!
ATS220 ATS CONTROLLER USER MANUAL
7
Installation instruction
The controller should be installed by two accessories and screw.
Panel Cutout：W67mm*H67mm.
Note: If the controller is installed directly in the genset shell or other fluctuated
equipment, the rubber pad must be installed.
Panel and display
Panel Operation
Gens Freq.
Gens Voltage
Gens status
Gens Close
Gens Close
LED Display
Page Change
Auto Mode/ Manual Mode
Auto Mode Indicator
Mains Freq.
Mains Voltage
Mains status
Mains Close
Mains Close
ATS220 ATS CONTROLLER USER MANUAL
8
Panel instruction
Indicator name
Main function
Mains Voltage Indicator
Mains voltage.When the load is switched to the mains
supply, the display will display the mains voltage
Mains Frequency Indicator
Mains frequency
Gens Voltage Indicator
Gens voltage.When the load is switched to the gens
supply, the display will display the gens voltage
Gens Frequency Indicator
Gens Frequency
Mains status Indicator
LED will be on if the Mains normal and off if Mains off, flash
if there is low voltage or high voltage alarm.
Mains Close Indicator
LED will be on if the Mains loading is available.
Gens status Indicator
LED will be on if the Gens normal and off if Gens off, flash
if there is low voltage or high voltage alarm.
Gens Close Indicator
LED will be on if the Gens loading is available.
Auto Mode Indicator
LED will be on under auto mode and off under manual
mode.
Key Function Description
ICON
Button Name
Function Description
Mains Close
Decrease
Mains loading shall be output under manual mode if press
it.
Under display mode, parts of the page can move down.
Under edition mode, to move the digit or decrease the
numbers, press the button continuously to reduce the number
continuously.
Auto/manual
switching
Increase
Press it, working under auto mode if LED is on.
Press it, working under manual mode if LED is off
Under display mode, parts of the page can move up.
Under edition mode, to move the digit or increase the
numbers, press the button continuously to increase the
number continuously..
Gens Close
Revert
Gens loading shall be output under manual mode if press
it.
Under edition mode, pressing this key can cancel the
setting and back to upper class under edition.
Under display mode, pressing this key ,Parameters to be
saved under value checking page.
Page Change
Confirm
Change the display page.
Under display mode,Confirm entering parameter edition
mode.
Under edition mode, Confirm the change.
Control and operation instruction
Mode change
ATS220 ATS CONTROLLER USER MANUAL
9
Manual and Auto modes are available for this controller, press to
switch; when the LED is lighted like this , it means working under auto mode.
When the LED is lighted like this , it means working under Manual mode,
Manual Mode
When press and indicator is off, then it means working under Manual
mode.
Under manual mode, Mains loading shall be output under manual mode if press
.Gens loading shall be output under manual mode if press . There is no
output for genset crank relay.
Auto crank mode
When press and indicator is on, then it means working under Auto
mode.Under Auto Mode:
When the Mains becomes abnormal (power shortage, over voltage, under
voltage), then “Mains abnormal delay” starts, “Gens Start Delay”shall also start if the
Mains is still abnormal after the delay, then Gens relay output shall be closed and
start to crank. When the gens voltage becomes normal, “Gens normal delay”starts.
The ATS switch will transfer to Gens when the Gens loading output closed after
“Transfer interval delay”.
When the Mains becomes normal, then “Mains normal delay” starts,Gens
loading relay is off, the ATS switch transfer to Mains when the Mains loading is
closed after “Transfer interval delay” .
When the Mains is normal, then“Gens Stop Delay”starts, the genset shall be stop
after gens crank relay is off after delay.
Note: the default mode is Manual mode, Auto indicator is off.
Warning: please make sure that the controller is under manual mode if
you are going to maintain the equipment in order to avoid any accidents.
Parameters setting
Edition Page
Please operate as below steps:
1. Press and simultaneously, then loose, Then system comes into menu
setting.
