MB QUART RLP204 Manuel utilisateur

MAXXSONICS USA, INC

1290 Ensell Road

Lake Zurich, Illinois 60047 USA

E-Mail: [email protected]

Website: www.maxxsonics.com

www.mbquart.com

REFERENCESUBWOOFER

RLP204/RLP254/RLP304

The diagram below shows a screw pattern for mounting your subwoofer. It is very important

that you follow this pattern as indicated or your cosmetic trim ring will not fit properly.

RLP204/RLP254/RLP304

RLP204

2.77”/70.3mm

0.57”/14.38mm

8.43”/214mm

7.17”/182mm

RLP204

RECOMMENDED ENCLOSURE (SEALED)

Optimal Sound Quality

(Flat Response)

8.5” Deep

11.75” Wide

11.75” Tall

Total Internal Volume:

.50 Cubic Feet

Qtc: 0.866

F3: 46Hz

Heavy Polyfill

SMALL BOX

(Tight Bass)

5.5” Deep

10.75” Wide

10.75” Tall

Total Internal Volume:

.25 Cubic Feet

Qtc: 1.013

F3: 53Hz

Heavy Polyfill

* Boxes have been designed using 1/2” MDF.

Dimensions can be changed as long as recommended volumes

remain the same.

Subwoofer Displacement is .035 Cubic Feet

T/S PARAMETERS

Fs: 41.5 Hz

Qms: 4.66

Vas: 12.19 liters

Cms: 192.42um/N

Mms: 76.26 g

Xmax: 8.15 mm

Dia: 163.98 mm

Sd: 0.021 sq.m

Vd: 0.172 liters

Qes: 1.01

Re: 6.2 ohms

NomZ: 7.44 ohms

BL: 11.04 Tm

QTS: 0.83

no: 0.081 %

1W/1M: 81.23 dB

(coils in series)

RLP254

2.93”/74.3mm

0.67”/17.1mm

10.31”/262mm

9.06”/230mm

DVC

25.4 cm / 10” 25.4 cm / 10”

25.4 cm / 10”

DVC

RLP254

RECOMMENDED ENCLOSURE (SEALED)

Optimal Sound Quality

(Flat Response)

9.5” Deep

12.5” Wide

12.5” Tall

Total Internal Volume:

.65 Cubic Feet

Qtc: 0.959

F3: 42Hz

Heavy Polyfill

SMALL BOX

(Tight Bass)

6.25” Deep

12.5” Wide

12.5” Tall

Total Internal Volume:

.4 Cubic Feet

Qtc: 1.094

F3: 47Hz

Heavy Polyfill

* Boxes have been designed using 1/2” MDF.

Dimensions can be changed as long as recommended volumes

remain the same.

Subwoofer Displacement is .06 Cubic Feet

T/S PARAMETERS

Fs: 33.95 Hz

Qms: 5.44

Vas: 27.55 liters

Cms: 168.01 um/N

Mms: 130.81 g

Xmax: 8.65 mm

Dia: 208 mm

Sd: 0.034 sq.m

Vd: 0.294 liters

Qes: 0.963

Re: 6.9 ohms

NomZ: 8.28 ohms

BL: 14.137 Tm

QTS: 0.819

no: 0.108 %

1W/1M: 82.4 dB

(coils in series)

RLP304

3”/76.2mm

0.958”/24.33mm

12.28”/312mm

10.59”/269mm

DVC

RLP304

RECOMMENDED ENCLOSURE (SEALED)

Optimal Sound Quality

(Flat Response)

9.8” Deep

14” Wide

14” Tall

Total Internal Volume:

.75 Cubic Feet

Qtc: 1.10

F3: 40Hz

Heavy Polyfill

SMALL BOX

(Tight Bass)

7” Deep

14” Wide

14” Tall

Total Internal Volume:

.5 Cubic Feet

Qtc: 1.25

F3: 46Hz

Heavy Polyfill

* Boxes have been designed using 3/4” MDF.

Dimensions can be changed as long as recommended volumes

remain the same.

Subwoofer Displacement is .078 Cubic Feet

T/S PARAMETERS

Fs: 29.13 Hz

Qms: 6.928

Vas: 53.98 liters

Cms: 171 um/N

Mms: 174.42 g

Xmax: 9 mm

Dia: 245 mm

Sd: 0.047 sq.m

Vd: 0.424 liters

Qes: 0.952

Re: 7.05 ohms

NomZ: 8.46 ohms

BL: 15.38 Tm

QTS: 0.837

no: 0.135 %

1W/1M: 86 dB

(coils in series)

MAXXSONICS USA, INC

1290 Ensell Road

Lake Zurich, Illinois 60047 USA

E-Mail: [email protected]

Website: www.maxxsonics.com

www.mbquart.com

RLP204/RLP254/RLP304

MaxxsonicsLimitedWarranty

AsthemanufacturerofMaxxsonics,Autotek,Crunch,MBQuartandHifonicscaraudio

products,MaxxsonicsUSAInc.Warrantstotheoriginalconsumerpurchaserthe

amplifiertobefreefromdefectsinmaterialandworkmanshipforone(1)Yearfrom

dateofpurchase.

Allotherpartsandaccessoriesofthesystemarewarrantiedtobefreefromdefectsin

materialandworkmanshipforone(1)yearfromdateofpurchase.Maxxsonicswill

repairorreplaceatit’soptionandfreeofchargeduringthewarrantyperiod,anysystem

componentthatprovesdefectiveinmaterialsandworkmanshipundernormalinstallation,

useandserviceprovidedthattheproductisreturnedtotheauthorizedMaxxsonicsdealer

fromwhereitwaspurchased.Aphotocopyoftheoriginalreceiptmustaccompanythe

productbeingreturned.

Validpurchasereceiptswillcontainthenameandaddressoftheauthorizedreseller.

Anydamagetotheproductasaresultofmisuse,abuse,accident,incorrectwiring,

improperinstallation,alterationofdatecodeorbarcodelabels,revolution,natural

disaster,oranysneakystuffbecausesomeonemessedup,repairoralterationoutside

ofourfactoryorauthorizedservicecentersandanythingelseyouhavedonethatyou

shouldnothavedoneisnotcovered.

Thiswarrantyislimitedtodefectivepartsandspecificallyexcludesanyincidental

orconsequentialdamagesconnectedtherewith.Thiswarrantyisnottobeconstrued

asaninsurancepolicy.

Warrantyoninstallationlabor,removal,re-installationandfreightchargesarenotthe

responsibilityofMaxxsonicsUSAInc.

Warrantyproductsdamagedasaresultofinsufficientorimproperpackingmaterials

arenotcoveredbythislimitedwarrantyandsuchdamagedproductwillbereturned

“asis”attheexpenseoftheowner.
