Maytag 6157WUA Manuel

Repair

Parts

List

MODEL NUMBER

6157WUA

When requesting service or ordering parts, always

provide the following information:

- Product Type - Part Number

- Model Number - Part Description

RANGE

Section: TOP ASSEMBLY

C15-279

Model: 6157WUA

TOP ASSEMBLY

No. Part No. Description

Section:

Series Qty

1 N 7712P186-60 PANEL, MANIFOLD (BLK) Note: PANEL, MANIFOLD 01 1

2 7112P102-60 CLIP, SPEED Note: CLIP 01 2

3 7602P119-60 CLOCK (BLK) Note: CLOCK 01 1

- N 7118P015-60 SCREW, HOUSING Note: SCREW 01 4

4 3801F332-45 BRACKET Note: BRACKET, CLOCK 01 2

- N 4005F415-51 COVER, MAINFOLD (REAR) Note: COVER, MAINFOLD (REAR) 01 1

5 7403P067-60 SWITCH, ROCKER (BLK) Note: SWITCH, ROCKER 01 1

- 3601F221-45 BAFFLE, VENT COVER Note: BAFFLE, VENT COVER 01 1

- 7706P301-60 EXTRUSION, FILLER 01 1

- N 3801F325-51 BRACKET, MAIN TOP Note: BRACKET, TOP 01 1

6 2001F089-84 TOP, MAIN (ALM) Note: (ALM) 01 1

- N 7724P051-60 COVER, VENT TRIM Note: COVER, VENT TRIM 01 1

7 2003W027-00 GRATE (BLK) Note: GRATE 01 4

8 7733P065-60 KNOB, VALVE Note: KNOB, VALVE 01 4

9 7731P071-60 KNOB, THERMOSTAT (BLK) Note: KNOB, THERMOSTAT 01 1

10 N 7724P051-60 COVER, VENT TRIM 01 1

- N 8113P012-60 MANUAL, USE & CARE Note: MANUAL, USE & CARE 01 1

- 8112P106-60 MANUAL, USE & CARE-INSERT Note: INSERT, MANUAL 01 1

- N 16000329 GUIDE, QUICK REF. - MAGIC CHEF Note: GUIDE, QUICK REFERENCE 01 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: GAS CONTROLS

C13-138

Model: 6157WUA

GAS CONTROLS

No. Part No. Description

Section:

Series Qty

1 N 7513P160-60 PIPE, MANIFOLD 01 1

2 N 7502P217-60 VALVE, TOP BURNER 01 4

3 7403P279-60 SWITCH, IGNITER 01 4

4 7404P087-60 THERMOSTAT 01 2

- 4005F433-51 COVER, VALVE 01 1

- 7101P280-60 SCREW W/WASHER (BLK) 01 2

5 7507P087-60 FITTING, ORIFICE Note: ORIFICE (REAR 9,200 BTU) 01 2

6 3412D018-09 SEALED BURNER ASSY. (BLK) 01 4

- N 3807F432-45 SUPPORT, SPARK MODULE 01 1

7 7431P023-60 MODULE, SPARK 01 1

7 7431P027-60 MODULE, SPARK 12 1

8 7432P076-60 IGNITER, OVEN 01 1

9 7501P099-60 VALVE, OVEN Note: VALVE, OVEN W/FITTING 01 1

- N 8020P007-60 BRACKET, REGULATOR 01 1

- 7507P123-60 PIPE, NIPPLE 01 1

10 7510P050-60 REGULATOR, PRESSURE W/FITTING 01 1

- 7103P130-60 NUT, LOXIT (3/8") 01 1

11 N 3414F104-44 TUBING - REGULATOR & PIPE 01 1

12 3403D023-45 BURNER, OVEN 01 1

13 7101P290-60 SCREW 01 1

14 W10124350 NOT REQUIRED PART OR SEE NOTE Note: IGNITER NOT SOLD SEPARATELY (MUST ORDER

SEALED BURNER- ITEM #6)

01 0

15 7101P315-60 SCREW 01 8

- 7101P343-60 SCREW 01 2

16 3807F451-45 SUPPORT, ORIFICE FITTING 01 2

17 7101P296-60 SCREW 01 4

18 7103P119-60 PALNUT 01 4

19 N 7201P050-60 GASKET, BURNER 01 4

20 7101P282-60 SCREW (10-24X5/16-NI) 01 2

21 7507P087-60 FITTING, ORIFICE Note: (REAR 9,200 BTU) 01 2

21 7507P089-60 FITTING, ORIFICE Note: (FRONT 12,000 BTU) 01 1

21 7507P086-60 FITTING, ORIFICE Note: ORIFICE (FRONT 9,200 BTU) 01 1

22 5187D037-60 ORIFICE FITTING ASSEMBLY Note: (RT) 14 1

22 5187D036-60 ORIFICE FITTING ASSEMBLY Note: ORIFICE FITTING ASSY. (LT) 14 1

- 5140D038-60 WIRES, IGNITER (4 OR) 01 1

- 5125A312-60 HARNESS, LOOSE/BURNER BOX 01 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: BODY

C14-396

Model: 6157WUA

BODY

No. Part No. Description

Section:

Series Qty

1 4002F188-80 BACK, MAIN 01 8

2 N 2618F095-74 PANEL, SIDE (LT-ALM) Note: (LT-ALM) 01 1

2 N 2618F096-74 PANEL, SIDE (RT-ALM) Note: (RT-ALM) 01 1

3 4011F224-80 BOX, BURNER 01 1

4 8010P088-60 SPACER, MAIN TOP (RT) Note: (RT) 01 1

4 8010P087-60 SPACER, MAIN TOP (LT) 01 1

5 7118P013-60 SCREW Note: SCREW, SPACER 01 2

6 N 4022W004-45 EXTENSION, VENT BOX 01 1

- 7101P124-60 SCREW W/WASHER Note: SCREW, VENT BOX 01 4

7 4006W113-45 BOX, VENT 01 1

8 N 3807F416-45 SUPPORT, OVEN BACK 01 1

9 N 4820F001-59 STRAP, RETAINER 01 1

10 8114P335-60 COVER, LOCK SLOT 01 1

11 7106P055-60 HINGE 01 2

12 7101P017-60 SCREW, HINGE 01 4

13 4804F032-60 INSULATION, OVEN WRAPPER 01 1

- 4804F031-60 INSULATION, OVEN BACK 01 1

14 N 3604F173-51 SHIELD, HEAT (LT) 01 1

14 3604F174-51 SHIELD, HEAT (RT) Note: (RT) 01 1

15 7401P037-60 BLOCK, TERMINAL 01 1

16 7402P043-60 CORD, POWER 01 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: OVEN/BASE

C12-178

Model: 6157WUA

OVEN/BASE

No. Part No. Description

Section:

Series Qty

1 4003W028-80 BASE, MAIN 01 1

2 7101P316-60 LEG, LEVELING 01 4

3 3801F218-51 BRACKET, ANTI-TIP 01 1

4 3404F018-51 TRACK, DRAWER (RT) 01 1

4 3404F021-51 TRACK, DRAWER (LT) Note: (LT) 01 1

5 8016P010-60 GLIDE, BROILER TRACK 01 2

6 8004P024-60 SPACER, SIDE PANEL 01 2

- 7101P334-60 SCREW Note: SCREW, SPACER 01 2

7 7801P040-60 RACK 01 2

8 2201F077-19 FRONT, BROILER 01 1

- 7101P290-60 SCREW Note: SCREW, BROILER 01 15

9 N 4016F039-45 SIDES, BROILER 01 1

10 7112P004-60 CLIP, THERMOSTAT 01 2

11 8114P335-60 COVER, LOCK SLOT 01 1

12 Y3401F02019 PAN, BROIL 01 1

13 Y3413F01619 INSERT, BROIL PAN 01 1

- 7101P290-60 SCREW 01 1

- 3804F010-50 RETAINER 01 1

14 5504A001-19 BOTTOM, OVEN 01 1

- 3601F234-45 BAFFLE, OVEN BOTTOM 01 1

15 7407P088-60 RECEPTACLE, BULB Note: RECEPTACLE/HOUSING, BULB 01 1

16 7407P095-60 BULB, OVEN 01 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
