TECHNICAL SPECIFICATIONS

Model P4SA Series

Single Packaged Air Conditioning,

10 SEER - 3, 4 and 5 Ton Units

M1000 Product Line

The P4SA Series single packaged air conditioners are high effi-

ciency self contained cooling units that can be installed on a roof

or on a slab. The convertible unit design makes installations

simple in all applications. Units are ETL and ETLc listed. The unit

is truly designed with the contractor and the consumer in mind.

Features and Benefits

•Compact Footprint/Low Profile

Easy to handle and transport.

• Five Minute Restart Time Delay – When the unit shuts down, a five

minute delay keeps the unit from restarting, eliminating the highest

cause for compressor failure.

•Heavy-Gauge, Full Perimeter Base Rails

Facilitates forklift handling and curb mounting.

•Convertible Air Delivery

Horizontal or downflow to accommodate rooftop or horizontal

application.

•Galvanized Steel Cabinet

Polyurethane finish provides 950 hours salt spray protection.

•Plastic Coated Coil Guard and Mesh Hail Guard

Will never rust and protects the coil from being damaged by balls,

lawnmowers, hail etc.

•Externally Accessible Service Ports

Quick access to refrigerant system without disrupting operation.

•Access to Controls and Major Components

Easy in and out service.

•Corrosion-Resistant Drain Pan

Quickly drains away evaporator condensate.

•Service Access Panels

Allows easy access to all major components and the compressor.

Designed to make servicing easier for the Contractor.

•Easy to Install

Electric heat strip provides up to 20 KW of heat output.

•Proven, Industry Standard Components

Easier service and availability.

•Quiet Operation and Low Vibration

20" fan blade combined with custom venturi condenser fan.

• Accessories

Roof curbs and more.

• 10 Year Residential Parts Warranty

The best warranty in the business.

•10 YEAR

WARRANTY

•WORRY-FREE

PERFORMANCE

SPECIFICATIONS

Application

Packaged AC

A = 10 SEER

Electrical Code

K = 208/230-60-1

IDENTIFICATION CODE

Nominal Capacity

x 1000 Btu

P 4 S A 024 K

Series

Square Duct

BLOWER PERFORMANCE

Model External Static Pressure Drop - inches water column

P4SA-Speed0.10.20.30.40.50.60.70.8

High 1600 1510 1410 1310 1200 1070 930 760

Medium* 1410 1330 1250 1150 1050 940 820 670

Low 1130 1070 1000 930 850 760 650 530

High 2000 1930 1850 1770 1690 1600 1510 1410

Medium* 1760 1700 1630 1560 1490 1410 1330 1250

Low 1410 1360 1310 1250 1200 1130 1070 1000

High 2200 2140 2070 2000 1930 1850 1770 1690

Medium* 1940 1890 1830 1760 1700 1630 1560 1490

Low 1560 1510 1460 1410 1360 1310 1250 1200

036

048

060

036K 048K 060K

Performance

Capacity -Cooling BTUH

36,000 47,000 61,000

Efficiency - SEER

10.00 10.00 10.00

EER (Btuh/watt)

9.50 9.40 9.60

Electrical Rating - 60 Hz

Phase

111

Operating Voltage Range

187 - 253 187 - 253 187 - 253

Compressor Data

Volts

208 / 230 208 / 230 208 / 230

Rated Load Amps

14.8 21.8 27

Lock Rotor Amps

96 131 144

Indoor Blower

Type /No.ofSpeeds

DD / 3 DD / 3 DD / 3

Motor - HP / RPM

1/4 - 1100 1/2 - 1100 1/2 - 1100

Motor - Amps

1.3 3.1 3.1

Outdoor Fan

Motor - HP / RPM

1/4 - 825 1/4 - 825 1/4 - 825

Motor - Amps

1.2 1.2 1.2

Fan Diameter / CFM

20/3600 20/3600 20/3600

Refrigerant Charge - Oz.

61 80 104

Shipping Weight

340 355 390

Model

Number P4SA-

* Factory Set Speed

DIMENSIONS

Top View

24.9

13.5

16.0

23.5

12.0

13.3

13.5 16.0

12.0

47.5

3/4" NPT Female

Drain Connector

SUPPLY

RETURN

Center of Gravity Height (in inches)

with base rails without base rails

330 27.5 26.5 36 31.3

345 28.0 26.0 36 31.3

380 28.5 26.5 40 35.3

Unit

Weight

Model

Number

P4SA-

036

048

060

DIMENSIONS continued

Side View

1.25 Ø Power Entry

1.75 Ø Power Entry (Capped)

0.88 Ø ControlWiring Entry

24.6

28.2

31.0

1.8

4.00

13.5

16.0

14.7

13.5

16.0

13.45

11.75 22.75 55.8

SUPPLY RETURN

4.0

CONDENSING

COIL

5.0

Back (Duct) View

ELECTRICAL DATA

*When overcurrent rating exceeds 60, internal circuit breakers must be installed in addition to branch circuit protection at distribution panel.

P4SA-036K

21.0 10 10 10 35 - - - - -

5 26.6 10 10 10 35 - - - - -

841.2688 45 ---- -

10 51.6 6 6 8 60 - - - - -

P4SA-048K 0 31.6 8 8 8 50 - - - - -

531.6888 50 ---- -

843.5688 50 ---- -

10 53.9 6 6 8 60 - - - - -

15 78.9 3 4 4 80 50.0 6 8 8 50

103

110

P4SA-060K 0 38.4 8 8 8 60 - - - - -

538.4888 60 ---- -

843.5688 60 ---- -

10 53.9 6 6 8 60 - - - - -

15 78.9 3 4 4 80 50 6 8 8 60

103

110

---- - ---- -

---- -

---- - ---- -

28.6 10 10 10 30 - - - - -

---- -

---- - ---- -

28.6 10 10 10 30 - - - - -

Multi

le Su

Circuit O

tion

Circuit B

(

Blower & Heater

)

Circuit C

(

Heater Onl

Minimum Rec Wire Rec Wire Rec Wire Maximum Minimum Rec Wire Rec Wire Rec Wire Maximum

Circuit Gauge Gauge Gauge Over-current Circuit Gauge Gauge Gauge Over-current

Amp. (60°C Cu) (75°C Cu) (90°C Cu) Rating* Amp. (60°C Cu) (75°C Cu) (90°C Cu) Rating*

Mlil Ci i

Sin

le Su

Circuit

tion Circuit A

(

Com

ressor & Fan

)

ode

Heater Minimum Rec Wire Rec Wire Rec Wire Maximum Minimum Rec Wire Rec Wire Rec Wire Maximum

Installed Circuit Gau

eGau

e Over-current Circuit Gau

eGau

e Over-current

Nom. KW Amp. (60°C Cu) (75°C Cu) (90°C Cu) Rating* Amp. (60°C Cu) (75°C Cu) (90°C Cu) Rating*

H 3 HK 008 - H 0 1

Heater

Heater Kit

3-P4 Pkgd. Units Electric

Heater KW

No. of Breakers

Electric Code

H=240-1-60

Stages

IDENTIFICATION CODE

HEATER APPLICATION MATRIX

NA = Not Applicable.

( ) = Number of internal circuit breaker kits required.

H3HK-005H-01A H3HK-008H-01A H3HK-010H-01A H3HK-015H-01A H3HK-020H-01A

917166A 917167A 917168A 917169A 917170A

P4SA-036K X X X(2) X(2) NA

P4SA-048KX(2)X(2)X(2)X(3)X(3)

P4SA-060KX(2)X(2)X(2)X(3)X(3)

Model

Number

H3HK-015H-21A H3HK-020H-21A

917172A 917173A

XNA

X(1) X(1)

ACCESSORIES

Description Part Number

Roof Curb (8") 547830

Roof Curb (14") 547831

Roof Curb (18") 547850

Roof Curb (24") 547851

Manual Fresh Air Damper 547832

Filter Rack, All Downflow Applications (not required with economizer) 547885

Filter Kit (not required with economizer) for Horizontal Applications

P4SA 036 547886

Filter Kit (not required with economizer) for Horizontal Applications

P4SA 048 547887

Filter Kit (not required with economizer) for Horizontal Applications

P4SA 060 547888

Universal Hard Start Kit 912933

Low Pressure Switch Kit 913551

High Pressure Switch Kit 913550

Low Ambient Kit 913549A

P-Trap Kit 913810

U.S. LP Gas Conversion Kit (0 ft to 10,000 ft above sea level) 903616

Canadian LP Gas Conversion Kit (0 to 4,500 ft above sea level) 903617

Outdoor Thermostat Kit 913852

Before purchasing this appliance, read important energy cost and efficiency

information available from your retailer. Specifications and illustrations subject

to change without notice and without incurring obligations.

Maytag is a registered trademark of the Maytag Corporation and is used under license to NORDYNE Inc.

302B-0303 (Replaces 302B-0802)

Printedin U.S.A. (03/03)
