Maxxus MX 8.0 Instructions d'installation
ENG
Massage Chair
MX 8.0
INSTALLATION & OPERATING MANUAL
2
Index
Index 2
Safety Instructions 3 – 5
Overview - Massage Chair 6
Overview - Remote Control 7
Operation 8 – 13
Assembly 13
Location & Storage 14
Technical Details 14
Care, Cleaning & Maintenance 15
Disposal 15
Recommended Accessories 16
Exploded Drawing and Parts List 17
Warranty 18
Service Contract 19
© 2019 MAXXUS Group GmbH & Co. KG
All rights reserved / All rights reserved
This publication may not be reproduced, stored in a retrieval system, or transmitted in whole or in part, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise without the prior written permission of Maxxus Group GmbH & Co. KG.
Errors, colour and technical modication subject to change, reproduction as well as electronic duplication only with written permission of MAXX-
US Group GmbH & Co. KG.
3
ENG
Safety Instructions
Before you use the massage chair, please make sure you are familiar with the contents of the entire Operating
Manual, in particular the safety instructions, maintenance & cleaning instructions and the training information.
Please also make sure that everyone who uses this massage chair is also familiar with all this information and
observes it.
Be sure to follow carefully the maintenance and safety instructions contained in this manual.
This massage chair may only be used for its intended purpose. Misappropriate use may pose a risk for possi-
ble accidents, damage to health or damage to the massage chair for which no liability will be accepted by the
distributor.
Mains Connection
−A mains voltage of 220-230V is required for the operation of the device.
−The massage chair may only be connected by the mains cable included in delivery to a grounded 16A
individually fused socket which has been installed by a professional.
− Always remember to rst remove the mains plug from the socket if you want to change the location of the
massage chair.
−Always remove the mains plug from the socket before starting any cleaning, maintenance or other works to
the massage chair.
−Do not connect the mains adapter plug to a socket strip or to a cable drum.
−If using an extension lead make sure that it conforms to VDE guidelines and regulations or the equivalent
in your country.
−Always lay the power cable in such a way that it cannot be damaged or cause a tripping hazard.
−Electrical appliances, such as smartphones, PC, TV (LCD, plasma, tube, etc.), game consoles, etc. trans-
mit electromagnetic radiation during operation and in stand-by mode. Keep these all these devices away
from this massage chair as they may cause malfunction or interferences.
−For safety reasons, always remove the mains cable plug from the electrical socket when the massage chair
is not in use.
Training Environment
− Choose an area for your massage chair that is level, clean and easily accessible. The area should oer the
largest free space and maximum safety possible.
−Ensure that the area is well ventilated during use and that you avoid drafts.
−The massage chair is not suitable for outdoor use and so it should only be stored and used in a tempered,
dry and clean room.
−The ambient temperature range for the operation and storage of the massage chair should be between at
least 10° to a maximum of 30°Celsius
−Do not operate or store the massage chair in wet areas such as in swimming pools, saunas or bathrooms
etc.
− Make sure that when in operation or when idle that the massage chair is kept on rm, level ground and that
any unevenness in the oor surface is removed or levelled out.
− To protect delicate oors, such as wood, laminates, tiles, etc. from damage such as scratches it is advisa-
ble to place a MAXXUS® oor protection mat permanently under the device.
−Make sure that the mat is secured against slipping.
−Do not place the massage chair directly on pale coloured or white carpets as the feet on the device can
cause staining.
− Make sure that the massage chair including the mains cable do not come into contact with hot objects and
that the massage chair is kept at sucient distance away from all sources of heat such as heating radia-
tors, open and res, ovens and stoves.
4
Personal Safety Instructions for Training
−Remove the power cable whenever the massage chair is not in use to prevent improper or uncontrolled
use by third parties such as children.
− You should consult and have a health check with your doctor before using the massage chair for the rst
time.
−Persons with the following medical conditions / diagnoses should consult their doctor in advance before
using a massage chair to discuss and receive medical clarication and advice:
−Osteoporosis
−Heart disease
−Pacemaker
−Fever
−Pregnancy
−Open wound
−Broken bones
−Bruises and contusions
−Skin diseases
−Back and spine problems
− For other diseases or diagnoses which are not listed above, please also consult your doctor before rst
use.
−For their own safety it is necessary that persons whose body, perception or psyche are impaired or
that those who are lacking in experience and knowledge about the use of massage chairs, should
use the chair under the supervision of an experienced and responsible person.
−If you feel physical discomfort, pain and / or experience breathing problems, stop the massage immediate-
ly.
−Always start your massage sessions with a low intensity and increase this slowly and gently throughout the
session.
−Each user should only use the massage chair 1 x per day maximum and for no longer than 20 minutes.
−Use the massage chair at the earliest 1 hour after eating.
−Make sure that you wear suitable clothing during the massage session.
−The massage chair may only be used if the user’s body is dry. If the body is damp such as directly after
showering or bathing, the chair must not be used.
−Do not use any other accessories while using the massage chair.
−This massage chair is only suitable for use by one person at a time.
−Before each time of using check that the massage chair and electrical cable are in perfect condition. Never
use the massage chair if it or the electrical cable show signs of being faulty or defective.
− Never use the massage chair if the cover or the articial leather is damaged.
−You may only carry out repair work independently if agreement and approval has been given by our Ser-
vice Department to do so. Only original spare parts may be used.
−The massage chair must be cleaned after each use. In particular, remove all impurities caused by body
perspiration or other liquids.
−Always make sure that liquids (drinks, body sweat, etc.) do not penetrate the massage chair as this leads
to corrosion and can lead to damage to the mechanical and electronic components.
−The massage chair is not suitable for use by children.
−During use, third parties - especially children and animals - must be kept at an adequate safety distance
from the massage chair.
− Before each use check that there are no objects under the massage chair or remove them if necessary.
−Always make sure that the massage chair is not used inappropriately by children as a toy or climbing
frame.
−Never carry out structural changes to the massage chair as this will result in the immediate expiry of all
warranty and guarantee claims.
The design of this massage chair is based on the latest technical and safety technology available.
This massage chair should only be used by adults!
Extreme, wrong and / or unplanned use can lead to health problems!
Safety Instructions
5
ENG
When the footrest is raised, do not exert any pressure on the footrest as this may cause the massage chair to
tip forwards and cause damage to the massage chair parts and/or injure people.
Do not press down.
Before you sit down in the massage chair make sure that the seat cushion is correctly positioned in the mas-
sage chair.
If the seat cushion is not correctly positioned, it can cause pain around the buttocks area or damage to the
massage sliding carriage.
Never remove the power cable or the control unit cable when the massage chair is switched on or in standby
mode. This may cause damage to the massage chair or cause an electric shock. Always switch o the massage
chair using the main switch and then remove the power cable or the control unit cable. The power cable should
always be removed when the massage chair is not in use to prevent unauthorized use by third parties, such as
children.
Always check before using if there are children, pets or objects under the massage chair. Please check for this
particularly around the foot rest and all around the back rest. Clear and remove anything which could obstruct
the device as this could cause damage to the massage chair or cause injury to people etc.
Safety Instructions
15
14
19 20 21 22
16
18
FUSE:
T5AL 250V POWER INPUT
CONTROLLER JACK ON/OFF
17
1
3
6
7
10
813
9
11
4
12
2
5
6
1. Head Cushion
2. Digital 3D Speaker
3. Airbag for Shoulder/Upper Arms
4. Airbag for Lower Arms
5. Remote Control
6. Seat Cushion
7. Airbag for Calves
8. Foot Massage Area
9. Cover for Foot Rest
10. Back Cushion
11. Arm Rest
12. Side Covers
13. Foot Rest
14. Back Cover
15. Storage Pocket for Remote Control
16. Main Housing
17. Transport Rollers
18. Mains Cable
19. Fuse
20. Remote Control Connection
21. Mains Switch
22. Mains Cable Connection
Overview - Massage Chair
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R
e
l
a
x
Manual Massage
7
ENG
Overview - Remote Control
1. LCD Display
2. On/O Key
To switch the massage chair on or o.
3. Pause Key
To stop or start all massage functions.
4. Key to Set the Time
5. Key to Adjust the Automatic Reclining Position
There are three automatic reclining position adjustments to
choose from.
6. Key to Select the Massage Programs
For information please read page 9 of this manual.
7. Air Pressure Mode Key (Airbag)
For information please read page 9 of this manual
8. Key to Select the Manual Massage Types:
−Shiatsu
−Kneading
−Tapping
−Knocking
−Combination of Kneading & Tapping Massage
9. Key for Foot Roller Massage
For information please read page 10 of this manual.
10. Key to Adjust the Neck Massage
Press this key to adjust the maximum height of the neck
massage.
(UP = higher, Down = lower)
11. Key to Set the Reclining Position I
Press this key to raise the back rest and lower the foot rest.
12. Key to Set the Reclining Position II
Press this key to lower the back rest and raise the foot rest.
13. Key to Regulate the Intensity of the Air Pressure
14. Infrared-Heater Key
To switch the infrared back-heater on or o.
Key Description Display
8
1. Mains Connection
Fuse T5AL
250V
Remote Control
Connection
ON/OFF Mains Cable Connection
Connect the mains cable to the connection on the massage chair.
Then connect the mains plug on the mains cable to a power socket.
CAUTION:
The massage chair may only be connected with the mains cable included in delivery to a power socket individu-
ally grounded with a 16A fuse and which has been installed by a professional electrician.
2. How to Start a Massage
2.1 Switch the massage chair on at the main switch. The mains switch is located directly next to the mains
cable connection (see Fig. above).
2.2 Activate the ON/OFF key on the remote control.
2.3 The massage chair will automatically do a body scan. Here the massage chair determines the shape of the
body, the optimum height of the neck / shoulder massage and the acupressure points.
2.4 If the height for the neck / shoulder massage determined by the massage chair is dierent to the actual
height of your shoulder/neck, then this can be adjusted by pressing the „UP“ and „DOWN“ keys. There are
10 dierent height levels here to choose from. If you do not change the adjustment within 10 seconds, the
massage chair will use the neck / shoulder position determined in the body scan for the massage.
Operation
During the body scan the symbol for neck / shoulder will be shown in the display and an acoustic signal will
be sounded. You can skip the body scan immediately when it starts by skipping directly to Step 2.5.
2.5 To start with a massage, select one of the 6 pre-set massage programs by pressing the program key.
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Shoulder position too high
Optimum shoulder position
Shoulder position too low
Shoulder/Neck
Adjustment
F1 Auto
F2 Auto
F3 Auto
F4 Auto
F5 Auto
F6 Auto
Comfort
Relax
Energy
Waist&
buttock
Neck &
shoulder
Full body
9
ENG
Massage Programs
Operation
Full body massage to the relax the muscles
Deep tissue massage of the most important acupressure points to relax and reduce muscle pain
Perfectly coordinated full body massage to increase energy. Ideal after getting up or taking a break.
This massage focusses on the waist and buttock areas
This massage focusses on the neck and shoulder areas
Full body massage for relaxation
Key Description Display
Function Key Massage Type Display Adjustment Options
Manual
Massage
Shiatsu Speed and Width
Kneading Massage Speed
Tapping Massage Width
Combination: Kneading & Tapping Speed
Knocking Massage Speed and Width
Adjustment Options
Speed Adjustable to 3 levels
Width Adjustable to 3 levels
Manual Massage
You can select the dierent manual massage types by pressing the mode key. With the „SPEED“ key you can
regulate the speed of massage types: Shiatsu, Kneading, Combination of Kneading and Tapping and Knocking
to 3 dierent levels. With the Knocking massage you can also adjust the distance between the massage rollers
to 3 levels.
H0 H1
H0 H1
H0
H1
H2
H3
H4
Fixed Point
Up
Down
Heating
10
Operation
Manual Massage Positions
Function Key Description Display Adjustment Options
Manual
Massage
Positions
Massage at a xed point yes
Partial massage in a particular area of the
body yes
Full body massage no
Partial massage of the upper body area no
Partial massage of the lower back area no
Adjustment Options
Massage
Higher Moves the massage higher
Massage
Lower Moves the massage lower
Air Pressure Massage (Airbags)
Function Key Description Display Adjustment Options
Air Pressure
Massage
Air pressure massage of the legs and
arms To 3 levels or o
Air pressure massage arms To 3 levels or o
Air pressure massage of the legs To 3 levels or o
Intensity Adjustment of the Air Pressure Massage
Intensity On/O of the Air Pressure Massage and
adjustment of the intensity To 3 levels or o
Foot Massage
Function Key Description Display Adjustment Options
Foot Mas-
sage
On/O of the Foot Sole Massage and
adjustment of the intensity of the rollers To 3 levels or o
Infrared Back-Heater
Function Key Description Display Adjustment Options
Back-Heater On/O of the Back-Heater Fully heated after 3 minutes
Table des matières
Autres manuels Maxxus masseur
