Maxkin SP-S01 PLUS Manuel utilisateur
Description
This indoor siren designed with unique, concise and stylish
appearance, which is suitable for different decoration style of
home and office. It can used as an indoor siren or work as a
standalone alarm system. With low-consumption, stable
function, strong anti-interference ability, it can effectively
protect your life and property safety. Once any detector has
been triggered, the control panel will receive the signal and
be alarming immediately, the alarm indicator will deter the
intruders as well. The siren adopt wireless transmission
technology, it is portable device and easy to install. This siren
is widely used at home, villa, office, warehouse, shops...
1. Siren
2. LED Indication
Red LED Flashes On: Enrolling
Green LED On: System disarmed
Blue LED On: System armed in away mode.
Blue LED Flashes: System armed in stay mode
3. Enroll Button
4. Plug Handle ( Press the handle, counter clockwise rotate to
change the plug)
5. Interchangeable Plugs
1
2
3
5
4
Specifications:
Voltage: AC110-240V 50/60Hz
Max Current: 20mA/220V
Power Rating: ≤5W(220V)
Maximum standby time: ≥ 20h
Back-up Battery: 600mAh/3.7V
Wireless Receiving Distance: 100M(Open Area)
Siren Volume: 90dB
Working Temperature: -25℃ -55℃
Operating Humidity: ≤95%(Non-condensing)
Housing Material: ABS
Siren Measurement:
Plug Type: EU/UK/US/AU
Compact and fashionable design
Wireless transmission technology, easy to install
Different color LED indicator shows arm/disarm status
Siren and strobe, more safety
Built-in 600mAh/3.7V back-up battery can last 12 hours
Keep connected with extented range up to 100M
Changeable plug, meet different customer needs
Features
General View/LED Indication
Printed in China
2016 V 1.0
SP-S01 (PLUS) Indoor Siren
User Manual
Notice:
1. The back-up is battery only for emergency use, AC power
should be the main supply.
2. Do not hit or drop the indoor siren in case of damage
component inside.
3. The strobe siren should be tested regularly, so that all fault
can be fixed in time.
Installation
1. Fix the the adapter on detector properly by rotating.
2. Power on
In network mode, the siren is a control panel based system
which should be connected to the control panel. Once
the enrollment is successful, when alarm panel is alarming,
the wireless siren will hoot loudly and the red LED will be
flashing continuously.
Wireless Siren Network Mode
As a standalone alarm system, all accessories should be enrolled to
the siren. Any detector triggered will activate the siren immediately.
Standalone Alarm System Mode
1. Press the enroll button, system beeps once and
LED indicator light up in red.( System will exit
automatically after 30 seconds or press the
enroll button again to exit )
2. Trigger the sensors (for example, press the arm
button of the remote control, depart the
transmitter and magnet of door sensor etc.)
Connect Expandable Accessories to the Siren
Press and hold the enroll button for 5 seconds until one beep is
heard, all accessories will be cleared.
Clear All Enrolled Accessories
The siren can work with the door bell, press the enroll button of
the siren, then press the smart button to enroll, When a visitor
presses a button, the bell rings in "Dingdong" sound to alert
home owner.
Work with Door Bell
1. Press the enroll button, system beeps once and
LED indicator light up in red.( System will exit
automatically after 30 seconds or press the
enroll button again to exit )
Connect Siren to the Alarm Panel 1
2
3
The siren beeps once, the red LED indicator
flashes once, the enrollment is successful.
The siren beeps twice, the red LED indicator
flashes once, the sensor has been enrolled
before.
The siren beeps three times, the red LED
indicator flashes once, the storage is full.
Button Operation
Function Opcration
Turn On Siren
Status
Turn Off Siren
Turn On/Off LED
Indicator
Turn On/Off Beeps
Sound
Enters into Enroll
State
Delete Enrolled
Wireless
Accessories
Press Enroll Button
for 3 seconds
The siren beeps once,
the LED indicator light up
in green color.
The siren beeps once,
the LED indicator blacks out.
The siren beeps once,
the LED indicator blacks
out or light up.
The siren beeps once.
The siren beeps once,
LED indicator light up in red.
The siren beeps once.
Press Enroll Button
for 3 times
Press Enroll Button
once
Press Enroll Button
for 5 seconds
Press Enroll Button
for 5 times
Press Enroll Button
for 10 times
Note:Please do not trigger any other accessories during connecting with the
control panel.
2. Trigger the control panel tamper switch, the enrollment is
successful.
the siren beeps once, the red LED indicator
flashes once, enrolled successfully.
The siren beeps twice, the red LED indicator flashes once,
the sensor has been enrolled before.
The siren beeps three times, the red LED indicator flashes
once, the storage is full.
3
1
2
