Maximum 054-4297-2 Manuel utilisateur

INSTRUCTION

MANUAL

Model No. 054-4297-2

IMPORTANT:

Please read this manual carefully before

using this product, and save it for reference.

TABLE OF CONTENTS

Technical Specifications 4

Safety Guidelines 5

Key Parts Diagram 11

Important Information 12

Assembly Instructions 13

Operating Instructions 16

Maintenance 18

Troubleshooting 20

Parts List 21

Warranty 23

NOTE: If any parts are missing or damaged, or if you

have any questions, please call our toll-free helpline at

1-888-670-6682.

SAVE THESE INSTRUCTIONS

• This manual contains important safety and

operating instructions. Read all instructions

and follow them with use of this product.

TABLE OF CONTENTS

model no. 054-4297-2 | contact us 1-888-670-6682

TECHNICAL SPECIFICATIONS

Rated Voltage 120V~, 60 Hz

Rated Power Input 13A

Rated Speed 10,500 RPM*

Compatible wheel sizes 5" (125 mm) & 4 1/2" (115 mm)

Wheel guard sizes 5" (125 mm) & 4 1/2" (115 mm)

Arbour Size 5/8" (16 mm)

Weight 6 lb 5 oz (2.87 kg)

Supply cord 10' (3 m) SJOW

*Tool’s rated speed is 10,500 RPM; using constant speed control (CSC) the

optimized speed is 9000 RPMs.

TECHNICAL SPECIFICATIONS

RULES FOR SAFE OPERATION

KNOW YOUR TOOL

To operate this angle grinder, carefully read this instruction manual and all labels

affixed to the tool. Keep this manual available for future reference.

IMPORTANT

This angle grinder should only be serviced by a qualified service technician. For

more information, call the toll free helpline at 1-888-670-6682.

READ ALL INSTRUCTIONS CAREFULLY

SAVE THESE INSTRUCTIONS

GENERAL POWER TOOL SAFETY WARNINGS

WARNING!

Read all safety warnings and instructions. Failure to follow the warnings

and instructions may result in electric shock, fire and/or serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE

REFERENCE.

The term “power tool” in the warnings refers to your mains-operated (corded)

power tool or battery-operated (cordless) power tool.

WORK AREA SAFETY

• Keep work area clean and well lit. Cluttered or dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence

of flammable liquids, gases or dust. Power tools create sparks which may

ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool. Distractions

can cause you to lose control.

ELECTRICAL SAFETY

• Power tool plugs must match the outlet. Never modify the plug in any way. Do

not use any adapter plugs with earthed (grounded) power tools. Unmodified

plugs and matching outlets will reduce risk of electric shock.

• Avoid body contact with earthed or grounded surfaces, such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric shock

if your body is earthed or grounded.

• Do not expose power tools to rain or wet conditions. Water entering a power

tool will increase the risk of electric shock.

• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging

the power tool. Keep cord away from heat, oil, sharp edges or moving parts.

SAFETY GUIDELINES

model no. 054-4297-2 | contact us 1-888-670-6682

Damaged or entangled cords increase the risk of electric shock.

• When operating a power tool outdoors, use an extension cord suitable for

outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric

shock.

• If operating a power tool in a damp location is unavoidable, use a ground-fault

circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of

electric shock.

PERSONAL SAFETY

• Stay alert, watch what you are doing and use common sense when operating a

power tool. Do not use a power tool while you are tired or under the influence

of drugs, alcohol or medication. A moment of inattention while operating

power tools may result in serious personal injury.

• Use personal protective equipment. Always wear eye protection. Protective

equipment such as dust mask, non-skid safety shoes, hard hat, or hearing

protection used for appropriate conditions will reduce personal injuries.

• Prevent unintentional starting. Ensure the switch is in the off-position before

connecting to power source and/or battery pack, picking up or carrying the

tool. Carrying power tools with your finger on the switch or energising power

tools that have the switch on invites accidents.

• Remove any adjusting key or wrench before turning the power tool on. A

wrench or a key left attached to a rotating part of the power tool may result in

personal injury.

• Do not overreach. Keep proper footing and balance at all times. This enables

better control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewellery. Keep your hair,

clothing and gloves away from moving parts. Loose clothes, jewellery or long

hair can be caught in moving parts.

• If devices are provided for the connection of dust extraction and collection

facilities, ensure that these are connected and properly used. Use of these

devices can reduce dust-related hazards.

POWER TOOL USE AND CARE

• Do not force the power tool. Use the correct power tool for your application.

The correct power tool will do the job better and more safely at the rate for

which it was designed.

• Do not use the power tool if the switch does not turn it on and off. Any power

tool that cannot be controlled with the switch is dangerous and must be

repaired.

• Disconnect the plug from the power source and/or the battery pack from the

power tool before making any adjustments, changing accessories, or storing

power tools. Such preventive safety measures reduce the risk of starting the

power tool accidentally.

SAFETY GUIDELINES

• Store idle power tools out of the reach of children and do not allow persons

unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained users.

• Maintain power tools. Check for misalignment or binding of moving parts,

breakage of parts and any other condition that may affect the power tool’s

operation. If damaged, have the power tool repaired before use. Many

accidents are caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly maintained cutting tools with

sharp cutting edges are less likely to bind and are easier to control.

• Use the power tool, accessories, tool bits, etc. in accordance with these

instructions, taking into account the working conditions and the work to be

performed. Use of the power tool for operations different from those intended

could result in a hazardous situation.

SERVICE

• Have your power tool serviced by a qualified repair person using only

identical replacement parts. This will ensure that the safety of the power tool

is maintained.

SAFETY GUIDELINES FOR ANGLE GRINDER

• This power tool is intended to function as a grinder. Read all safety warnings,

instructions, illustrations and specifications provided with this power tool.

Failure to follow all instructions listed below may result in electric shock, fire

and/or serious injury.

• Operations such as sanding, wire brushing, polishing or cutting-off are not

recommended to be performed with this power tool. Operations for which the

power tool was not designed may create a hazard and cause personal injury.

• Do not use accessories that are not specifically designed and recommended

by the tool manufacturer. Just because the accessory can be attached to your

power tool, it does not assure safe operation.

• The rated speed of the accessory must be at least equal to the maximum

speed marked on the power tool. Accessories running faster than their rated

speed can break and fly apart.

• The outside diameter and the thickness of your accessory must be within the

capacity rating of your power tool. Incorrectly sized accessories cannot be

adequately guarded or controlled.

• Threaded mounting of accessories must match the grinder spindle thread. For

accessories mounted by flanges, the arbour hole of the accessory must fit the

locating diameter of the flange. Accessories that do not match the mounting

hardware of the power tool will run out of balance, vibrate excessively and may

cause loss of control.

SAFETY GUIDELINES

model no. 054-4297-2 | contact us 1-888-670-6682

• Do not use a damaged accessory. Before each use, inspect the accessory,

such as abrasive wheels, for chips and cracks. If the power tool or accessory

is dropped, inspect it for damage or install an undamaged accessory. After

inspecting and installing an accessory, position yourself and bystanders away

from the plane of the rotating accessory and run the power tool at maximum

no-load speed for one minute. Damaged accessories will normally break apart

during this test time.

• Wear personal protective equipment. Depending on the application, use a

face shield, safety goggles or safety glasses. As appropriate, wear a dust

mask, hearing protectors, gloves and a workshop apron capable of stopping

small abrasive or workpiece fragments. The eye protection must be capable

of stopping flying debris generated by various operations. The dust mask or

respirator must be capable of filtering particles generated by your operation.

Prolonged exposure to high intensity noise may cause hearing loss.

• Keep bystanders a safe distance away from the work area. Anyone entering

the work area must wear personal protective equipment. Fragments of a

workpiece or of a broken accessory may fly away and cause injury beyond the

immediate area of operation.

• Hold the power tool by insulated gripping surfaces only, when performing an

operation where the cutting accessory may contact hidden wiring or its own

cord. Cutting accessory contacting a "live" wire may make exposed metal

parts of the power tool "live" and could give the operator an electric shock.

• Position the cord clear of the spinning accessory. If you lose control, the cord

may be cut or snagged and your hand or arm may be pulled into the spinning

accessory.

• Never lay the power tool down until the accessory has come to a complete

stop. The spinning accessory may grab the surface and pull the power tool out

of your control.

• Do not run the power tool while carrying it at your side. Accidental contact

with the spinning accessory could snag your clothing, pulling the accessory

into your body.

• Regularly clean the power tool’s air vents. The motor’s fan will draw dust

inside the housing and excessive accumulation of powdered metal may cause

electrical hazards.

• Do not operate the power tool near flammable materials. Sparks could ignite

these materials.

• Do not use accessories that require liquid coolants. Using water or other liquid

coolants may result in electrocution or shock.

• Use the right size of wheel guard when grinding with different size wheel.

Misuse of wheel guard will possibly cause personal injury.

SAFETY GUIDELINES

• The label on your tool may include the following symbols. The symbols and

their definitions are as follows:

V ..................... Volts

A ..................... Amperes

Hz ................... Hertz

W .................... Watts

min ................. Minutes

............... Alternating current

............. Direct current

n ................... Rated speed

n0 ................... No-load speed

............... Class II Construction

…/min ........... Revolutions or reciprocations per minute

............... Grounding terminal

BPM ............... Beats per minute

RPM ............... Revolutions per minute

.............. WARNING – To reduce the risk of injury, user must read

instruction manual.

.............. WARNING – To reduce the risk of injury always wear eye

protection.

.............. WARNING – To reduce the risk of injury always wear ear

protection.

ADDITIONAL SAFETY INSTRUCTIONS FOR GRINDING OPERATIONS

• Use only wheel types that are recommended for your power tool and use

only the specific guard designed for the selected wheel. Wheels for which the

power tool was not designed cannot be adequately guarded and are unsafe.

• The grinding surface of centre-depressed wheels must be mounted below the

plane of the guard lip. An improperly mounted wheel that projects through the

plane of the guard lip cannot be adequately protected.

• The guard must be securely attached to the power tool and positioned

for maximum safety, so the least amount of wheel is exposed towards

the operator. The guard helps to protect the operator from broken wheel

fragments, accidental contact with wheel and sparks that could ignite clothing.

• Wheels must be used only for recommended applications. For example:

do not grind with the side of a cut-off wheel. Abrasive cut-off wheels are

intended for peripheral grinding; side forces applied to these wheels may

cause them to shatter.

SAFETY GUIDELINES

model no. 054-4297-2 | contact us 1-888-670-6682

• Always use undamaged wheel flanges that are of correct size and shape for

your selected wheel. Proper wheel flanges support the wheel, thus reducing

the possibility of wheel breakage. Flanges for cut-off wheels may be different

from grinding wheel flanges.

• Do not use worn down wheels from larger power tools. Wheels intended for

larger power tools are not suitable for the higher speed of a smaller tool and

may burst.

KICKBACK AND RELATED WARNINGS

Kickback is the result of power tool misuse and/or incorrect operating

procedures or conditions and can be avoided by taking proper precautions, as

given below.

• Maintain a firm grip on the power tool and position your body and arms

to allow you to resist kickback forces. Always use the auxiliary handle, if

provided, for maximum control over kickback or torque reaction during start-

up. The operator can control torque reactions or kickback forces if proper

precautions are taken.

• Never place your hand near the rotating accessory. The accessory may

kickback over your hand.

• Do not position your body in the area where the power tool will move if

kickback occurs. Kickback will propel the tool in the direction opposite to the

wheel’s movement at the point of snagging.

• Use special care when working corners, sharp edges, etc. Avoid bouncing and

snagging the accessory. Corners, sharp edges or bouncing have a tendency to

snag the rotating accessory and cause loss of control or kickback.

• Do not attach a saw chain, wood carving blade or toothed saw blade. Such

blades create frequent kickback and loss of control.

SAFETY GUIDELINES

Table des matières

Autres manuels Maximum Broyeur

Maximum

Maximum 058-9367-8 Manuel utilisateur

Manuels Broyeur populaires d'autres marques

Parkside

Parkside PWS 230 C3 Manuel utilisateur

SUHNER ABRASIVE

SUHNER ABRASIVE ASC 9 Manuel technique

PTA

PTA P1322 Manuel utilisateur

Crown

Crown CT13313 Manuel utilisateur

Parkside

Parkside 280250 Manuel utilisateur

Climax

Climax VM2150 Series Manuel utilisateur

Jet

Jet JPSG-618M1 Manuel de service

Makita

Makita GA4030 Manuel utilisateur

DeWalt

DeWalt DWEN202 Manuel utilisateur

Grizzly

Grizzly G2790 Manuel utilisateur

Fein

Fein MSf843-1a Manuel utilisateur

Bosch

Bosch GWS 14,4 V PROFESSIONAL Manuel utilisateur

RAMSET

RAMSET CBAGR18 Manuel utilisateur

Bosch

Bosch 8-115 Z Manuel utilisateur

STEELE PRODUCTS

STEELE PRODUCTS SP-PB008 Manuel utilisateur

MW TOOLS

MW TOOLS ME15W Manuel utilisateur

Caravaggi

Caravaggi SP 20 Mode d'emploi

SUHNER ABRASIVE

SUHNER ABRASIVE UWK 10-R125 Manuel technique
