Commercial Display
Quick Start Guide
All the pictures in this manual are for reference only, subject to our available products.
Thank you for choosing MAXHUB product.
To ensure that you are able to fully utilize the capabilities of the product, we ask that you
please read this user manual carefully and thoroughly before using the device. Should you
have any questions or require assistance, please do not hesitate to contact our technical
support team for guidance.
Safety Warnings
Placement
(1) Please do NOT place the product on a slope, mount on an unstable stand or an insuiciently
robust wall, a table nor a shelf.
(2) Please do NOT expose the product to direct sunlight or any other heat source.
(3) Please do NOT put the product near devices that generate strong magnetic fields.
(4) Remove water splashes immediately with a clean dry cloth.
(5) Please do NOT place any other heavy objects on the product.
Power Supply
(1) Please check the product’s operating voltage and frequency matches the local power
configuration.
(2) Please unplug the device during storming or thundering weather.
(3) Please unplug the power should the product is left unused for long time.
(4) Please keep the power cable from physical or mechanical damage.
(5) Please use the original power cable from the accessory bag, don't modify or lengthen it.
(6) Please make sure the AC is grounded.
(7) This power cable comes with the device exclusively for this device only.
LCD Screen
(1) Do NOT use hard nor sharp objects on the screen other than MAXHUB stylus.
(2) Please unplug the power before cleaning the product.
Please clean the screen with a soft, dustless and dry cloth.
(3) Please do NOT use water or liquid detergent to clean the product.
(4) Please contact the authorised reseller for thorough cleaning.
(5) Please do NOT display a high-brightness image on the screen for too long time.
Viewing Distance
For optimal viewing experience, it is recommended to position the commercial display at a
distance that is 3-4 times the diagonal length of the screen.
Temperature & Humidity
(1) Please do NOT put the product near a heater nor a radioactive source.
(2) If the product is moved from a cold place to a warm one, please unplug the power cable
and allow the product to gradually warm up for at least two hours to reduce the moisture.
(3) Operating temperature of the product is 0°C-40°C, operating humidity is between
0%-90%RH.
(4) avoid exposing the unit to rain or placing it in high humidity areas. Additionally, it is
crucial to keep the unit in a dry and cool indoor environment.
01
Ventilation
Please ensure that the commercial display is placed in an area with adequate ventilation
to allow for proper heat dissipation. It is recommended to leave a minimum of 10cm of space
on the left, right, and back of the device, and 20cm of space above it to ensure proper airflow
and optimal performance.
Earphone
When using the earphones, it is important to be aware that prolonged listening at high
volumes may cause temporary or permanent hearing loss. To prevent this, we strongly
recommend turning down the volume before inserting the earphones into your ears.
Energy Saving
Please note that pressing the power button briefly will not fully shut down the commercial
display. Instead, it will enter standby mode, with only the screen turning o. To properly shut
down the device, press and hold the power button for approximately 3 seconds and confirm
the shut down command that appears on the center of the screen.
Notes for Cleaning
Please do not block or cover the heat vents on the back panel and do not spray liquids on the
device.
Power Switch Status Signs
“I” means power on, “O” means power o.
Maintenance
Please contact authorised reseller for maintenance or repairing.
Warranty Exclusions
MAXHUB does not warranty Products that match any one or few of the following descriptions:
(1) Product damage caused by violating the user manual.
(2) Hardware damage caused by improper setup.
(3) Product damage caused by unauthorised modification or maintenance.
(4) Product damage caused by using in an unsuitable environment.
(5) Product damage caused by abnormal external force.
(6) Product damage caused by natural disasters or other force majeure.
(7) Damaged Warranty Sticker.
(8) Unable to provide eective purchase certificate.
I. Unboxing Checklist
Wall Mounting ×1 Quick Start Guide×1
Commercial Display ×1
Commercial Display
Quick Start Guide
Model: ND43CMA / ND55CMA / ND65CMA
ND75CMA / ND86CMA / ND98CMA
All the pictures in this manual are for reference only, subject to our available products.
02
II. Installation Guide
1.Confirm the panel installation position.
Align the wall-mounted screw holes with the studs on the back panel and fasten with 2
wall-mounted strips.
First, fasten the screws on the top side, then fasten the screws on the bottom side. A total
of four screws are required.
Refer to the table below for the position of the lock hole.
Note:【*】Power cord could be dierent for dierent regions , pls refer to the actual product.
Power Cord*×1
WiFi Module (SI07B) ×1 HDMI Cable ×1
Remote Control×1
Size
55"
65", 75"
BracketSeries
WIB4722A
ND** CMA-T WIB9080A
Step 1:fasten the screws
on the top
Step 2:fasten the screws
on the bottom
03
Take 8 pcs of expansion rubber plug b
and screw it into the wall. It is recommended
to use 10 mm impact drill bit.
Fix the wall bracket on 8 pcs expansion
plug b with a combination of 8 pcs screw C
and gasket d.
Note: At this moment please install the WiFi
module if WiFi is required for this installation.
(See III Installing the WiFi Module)
Ø 10
b×8
c×8 d×8
Take the panel out of the box and place it on a soft surface, such as a mat, to protect it
during installation.
2
wall wall
2.Steps to install the wall mount
Take out the wall mount plate accessory package from the accessory box.
b-8pcs c-8pcs d-8pcs
a-1pcs
1
04
3.Reference On Wall Mount
When planning for wall mounting, it is important to take into consideration the physical
dimensions of the panel. To ensure ease of use, it is recommended to maintain a proper
distance between the wall and the back of the panel.
NOTE: The table and diagram are only for reference.
Series
L
H
W
Dimension
Commercial Display
1463.3 mm
838.3 mm
81.6 mm
65"
1685.6 mm
963.7 mm
81.6 mm
75"
1233 mm
703.5 mm
71.4 mm
55"
5 Tighten the safety screw counter-clockwise
to make the top of screw reach the second
screw hole.
6 Hang the panel vertically on the bracket
and then finish installation.
Tilt the Device Mounting arms
& Screen
Wall Plate
Note: This step is especially important for
installation on the mobile stand. Tightening
the safety screws will make device more stable.
Note: Please keep the panel in the center of
the bracket.
L
H
W
05
III. Installing the WiFi Module
Please make sure that the following items are ready before setting up the wireless module.
1×Commercial Display
1×WiFi Module
Please make sure the power cord of the Commercial Display is disconnected before
installation.
Step1: Use a Phillips screwdriver toloosen two screws and remove the cover.
Step2: Insert the WiFi module into the wireless module slot.
Note: This WiFi Module only works for the Commercial Display by plugging it into
the above slot.
WiFi Module
WiFi Module
06
IV. Installing the OPS module
Please make sure the power cord of the Commercial Display is disconnected before
installation.
Step1: Unscrew and remove the cover. Step 2: Prepare the OPS module.
OPS module
Step4: Installation of OPS module.
Rail up
Insert the module
Step3: Unscrew and remove the cover.
Slot
Up
07
Plug the power cable into the power socket of the product.
Plug the power cable into the power supply.
Flip the rocker switch and press the power button. The indicator light will turn white when the product
is powered on.
V. Removing the OPS module
Please make sure the power is o before proceeding with the removal.
VI.Power On/0
To remove the module, loosen the screws and
release the lock.
08
VII. Control Panel
(1) Please check connections are correct before starting.
2
1
3
4
5
6
7
8
9
Number
Power indicator light
Items
: Tap to enter energy-saving, press at least 2 seconds to enter standby mode
MENU: Pop up Settings menu
: Press to scroll left
: Press to scroll right
INPUT: Pop up channel Setting
: Press to scroll up / Volume up
Loudspeaker
1
2
3
5
6
4
8
: Press to scroll down / Volume down7
9
Note: Dierent sizes of product horn position is not the same,subject to our available products
09
