Maxell DMH1000 Manuel utilisateur
MODEL: DMH1000
POMANUAL DE USO
HUFELHASZNÁLÓI KÉZIKÖNYV
ESMANUAL DE USUARIO
ENUSER’S MANUAL
Points for Attention
Product Overview
Installation Filter
Specifications
Function Instruction
Methods of Pouring Water
Maintenance
FAQ
CONTENT
EN
Warning
POINTS FOR ATTENTION
Before using, please read this user manual carefully and keep it for future reference.
1. To avoid electric shock and fire, do not allow water, liquid or any flammable detergent to get into or
to clean the product.
2. Do not spray insecticide, perfume or other flammable spray around the products.
3. Before connecting the power supply, please check whether the voltage of the product is consistent
with the local power supply voltage.
4. This product can not replace normal ventilation, daily dust collection or oil pumping when cooking.
5. Ensure the product is used in condition of a stable and horizontal level.
6. Leave at least 30cm of space on the back and sides of the product, and at least 50cm of space
above the product when using.
7. Ensure both the filter and its cover are properly installed before using.
8. Do not insert finger or other things into the air outlet/inlet to prevent physical damage or trouble.
01
EN
02
Components
PRODUCT OVERVIEW
Air outlet
Tectum
Front shell
Purification air inlet
Filter
Filter cover
Power wire
Control panel
Back shell
Dehumidification air inlet
Water tank cover
Float
Buckle handle hole
Water tank
Tank handle
EN
Dehumidifier
Power
Full Tank
Air Purifier
WiFi
Low
High
Control Panel
03
EN
04
INSTALLATION FILTER
Pull and lift the filter
cover on the front shell.
Insert the new filter into
the machine.
Put the filter cover back to the machine:
Lock the bottom of the filter cover in the
bottom of the front shell (1).
Then push the cover toward the body
of machine (2).
After replacing the filter, please turn on
the machine and press the purification
button for seven seconds to reset.
Remove the packaging
on the new filter.
Remove the filter.
1. Turn off the machine, and disconnect with the power socket.
2. Ensure the handle of the filter is on the outside.
3. Please replace the filter which is specially designed for this product.
EN
05
SPECIFICATIONS
Model
Size
Rated input voltage
Power
Noise
Water tank capacity
DHM1000
195x215x315mm
AC 100-240V 50/60HZ
45W
<45dB
1L
Working capacity 750ml/d (30ºC, 80%RH)
Applicable ambient temperature 5ºC-50ºC
Coverage area Dehumidification<20m2, Purification<10m2
EN
06
FUNCTION INSTRUCTION
Purification dehumidifier combines with functions of dehumidification and purification,
providing three working models for users to enjoy fresh air and suitable humidity in the
meanwhile.
1. When the water tank is full, the machine will be auto-off and its indicator light will change
to red and keep flashing.
2. Put the water tank back to the machine after pouring the water to restart.
1. When the machine detects that the filter is needed replacing, the LED light
will change from green to orange and keep flashing.
2. Press the purification button for 7 seconds to reset after replacing a new filter.
Water full instruction
Reminder for replacing filter instruction
The running temperature for the machine is 5ºC to 50ºC, when the temperature is
above 5ºC, the machine will continue to work.
Low-temperature dehumidifier
EN
After the machine connects with power, the power indicator will turn on.
Button Instruction
Note:
1. Touch the purification button, its indicator lights on and the device starts
running with the LED lighting in green. It starts working in purification.
2. Touch it for second time, the LED light turns off but other functions are
normal operation.
3. Touch the button for third time, the device stops working with all lights off.
In the condition of dehumidification, touch the purification button, the dehumidification
is off but other functions are in normal operation; touch it for second time, the LED light
turns off but other functions are in normal operation; touch it for third time, the device
stops working with all lights off.
Purification Button
1. Touch the dehumidification button, its indicator lights on and the device
starts running with the LED lighting in green. It starts working in
dehumidification.
2. Touch it for second time, the LED light turns off but other functions are
normal operation.
3. Touch the button for third time, the dehumidification function turn off with the
corresponding indicator off but the air purifier continues running with its
indicator on.
Dehumidification Button
EN
High
08
Note:
In the condition of purification, touch the dehumidification button, the dehumidifiction turns on with its
corresponding indicator on; touch it for second time, the LED light is off but other functions are in normal
condition; touch it for third time, the dehumidification function turns off with its indicator off but the air
purifier continues running with its indicator lighting on.
3. Mode Button
(1) Press the button to set modes when the function of purification turns
on.
(2) This button can be set three modes circularly: High-Low grade. The
corresponding indicator will turn on after setting.
(3) Press mode button for 10 seconds to enter the WIFI connection mode.
At this time, the buzzer will beep 3 times and the WIFI indicator light will
flash green. When the device is successfully connected, the WIFI
indicator will be on.
EN
