FAMILY FRYER

M18FFW09

INSTRUCTION MANUAL

Safety Warnings Operation Cleaning and

Maintenance

SpecificationBefore Use

GB-2

Safety

When using electrical appliances, basic safety precautions should always be fol-

lowed, including the following:

1. Read all the instructions and retain them.

2. During and after use, parts of the appliance are HOT. Do not touch oil tank of

the appliance until it is cool.

3. Unplug the appliance from the mains socket after use and allow it to cool

before handling or cleaning any parts.

4. The oil or fat in the appliance will stay hot for some time after use. Do not

move the appliance until it is completely cool. To lift the appliance, use the

recessed handle grips at the sides.

5. Do not touch hot surfaces, use oven gloves.

6. Do not pour oil out of the appliance when the oil and the appliance are hot.

Allow them to cool rst. This can take at least 3 hours depending on ambient

temperatures and the oil temperature.

7. Never connect the appliance to the mains socket without placing the oil in the

tank.

8. Never operate the appliance when the oil in the tank is above the maximum or

below the minimum mark. The maximum amount of oil is 1.8 litres.

9. Do not immerse the body of the appliance or the mains cable or, mains plug in

water or liquids.

10. Never place the appliance on or near a source of heat such as a hot gas, electric

burner or heated oven. Do not allow it to touch curtains, wall coverings, cloth-

ing, dishtowels or other ammable materials during use.

11. Ensure ample clearance around and above the appliance so you can work

safely.

12. Use the appliance on stable heat-resistant surface.

13. Do not exposed the appliance to direct sunlight.

14. Operate the appliance with the controls facing you. Do not reach across the

appliance while it is operating or when it is hot.

15. Steam will build up during cooking, and it will escape when you open the lid.

Stand back when opening the lid. Always open the lid away from you.

16. Never leave the appliance unattended when it is connected to the mains.

17. Make sure that the mains cable does not touch any hot surface or overhang on

a table edge.

18. Do not use the appliance outdoors.

19. Do not place the appliance under any overhead cupboards when in use.

20. Do not use attachments or accessories not recommended by the

manufacturer.

21. Close supervision is necessary when an appliance is used near children.

Parents must warn children not to touch the hot appliance parts. Children

should not operate this appliance.

Safety WarningsOperationCleaning and

Maintenance

Specification Before Use

GB-3

22. This appliance is not intended for use by persons (including children) with

reduced sensory or mental capabilities, or lack of experience and knowledge

unless they have been given supervision or instruction concerning the use of

the appliance by a person responsible for their safety.

23. Children should be supervised to ensure that they do not play with the

appliance.

24. Do not use the appliance with a damaged mains cable or mains plug or fry-

ing basket. Seek expert advice.

25. If the mains cable is damaged it must be replaced by the manufacturer, its

service agent , or similarly qualied persons in order to avoid a hazard.

26. Do not use extension cables with kitchen equipment as they increase the risk

of accidents.

27. If you are using a solid fat, melt this gently in a separate pan and pour it into

the oil tank before switching on. Do not melt solid fat in the appliance by

placing it in the basket or you may damage the appliance.

28. Renew the cooking oil regularly. Used oil may contain contaminants, lower

smoking temperatures and cause excessive foaming and spattering.

29. Always dry food before frying as moist foods cause excessive foaming and

spattering. Even small amounts of water may cause the oil to spatter.

30. Never overload the frying basket. If too much food is fried at the same time,

the food will not get crisp and may cause excessive foaming and spattering.

31. After completion of frying, allow the food to drain before removing it from

the basket.

32. Ensure the Timer Knob is set to OFF before connecting or disconnecting the

appliance.

33. This appliance is for household use. Do not use for any purpose not expressly

specied in this manual.

34. The appliance must not be left unattended while it is connected to the mains

socket.

Safety Warnings Operation Cleaning and

Maintenance

SpecificationBefore Use

GB-4

Introduction

Your family fryer features a cool-wall body, a removable lid and a dual action lter in

the lid for easy cleaning. The dual action lter in the lid absorbs cooking vapours and

smells.

Please read all the instructions before using the appliance. Read all the safety notes

carefully.

If you pass the fryer on to a third party, please include these instruction manual.

Unpacking the Family Fryer

Remove all packaging from the family fryer. Retain the packaging. If you dispose of it

please do so according to any recycling regulations.

If items are missing or damaged, please contact Partmaster (UK only).

Tel: 0870 6001 338 for assistance.

Frying Basket with hinged

handle X 1

part number 31BZ0-01-W-1

Plain Filter X 1

part number 96BZ0-01-W

FAMILY FRYER

M18FFW09

INSTRUCTION MANUAL

Instruction Maunal X 1

part number 62BZ0-1982

Charcoal Filter X 1

part number 96BZ0-01-B

Safety WarningsOperationCleaning and

Maintenance

Specification Before Use

GB-5

TIMER

Your Family Fryer Components

Controls & Indicators

Viewing

Window

Grease

Trap

Oil

Tank

Frying Basket

in Raised

Position

Frying Basket

in Lowered

Position

Hinged

Lid

Frying

Basket

Handle

Frying

Basket

Release

Fryer Lid

Open button

Timer

Knob

Temperature

Settings

Variable

Thermostat

Lever

Power

Indicator

Safety Warnings Operation Cleaning and

Maintenance

SpecificationBefore Use

GB-6

Positioning the Fryer

• Site your family fryer on a rm, at, heat-resistant work surface. Steam given

o by the cooking process may mark or damage anything above or around

the fryer, ensure these areas are kept clear.

• In order to avoid possible re hazards, keep the area above and around the

fryer clear. Leave a clear space all around the fryer, and keep it as far back from

the front edge of the work surface as possible.

• Do not put the fryer or the mains cable close to any other cooking or heating

appliance.

• Place the fryer close to a switched mains socket. Do NOT use mains sockets

without switches or extensions.

Preparation

Before using your fryer for the rst time, you should carefully wash the appliance.

Open the lid by pushing the button marked OPEN. The lid is spring loaded and

will open automatically. Remove the frying basket and the lid.

1. Remove the frying basket

You may raise and lower the basket with the lid

open or shut. Carefully lift up the handle of the

frying basket until it latches into position.

Holding the basket

NEVER place your thumb on the button when

moving the basket as the basket may release

unexpectedly and spill any contents.

OPEN

Only when the handle is in the locked

position should you remove the basket!

Safety WarningsOperationCleaning and

Maintenance

Specification Before Use

GB-7

2. Remove the lid

With the lid fully open, hold the lid at both sides and ease the lid o the spring

catch.

Remove the grease trap cover and lters

Grip the catch on the lter trap cover between thumb and forenger. Press the

catch down and lift out the lid.

3. Wash the fryer components

• Wash the fryer lid, the grease trap cover and the basket by hand in warm

soapy water. Rinse and allow to dry.

• Pour warm soapy water into the oil tank and wash it with a damp cloth.

Rinse with fresh hot water and dry well.

• Wipe the exterior of the fryer with a damp cloth. Do NOT immerse the body

of the fryer in water.

4. Replace the grease trap cover

• Dry the fryer lid and replace the grease lters. Place the plain lter in the trap

rst, followed by the charcoal lter.

• Replace the grease trap cover back into position.

5. Replace the fryer lid

Stand in front of the fryer. Hold the lid on

each side and place the lid spring in front

of the metal catch at the rear of the fryer.

The two metal shafts in the lid should be

situated right at the plastic housing.

Now lift out the two lters.

Safety Warnings Operation Cleaning and

Maintenance

SpecificationBefore Use

GB-8

Cooking with the Fryer

Cooking with the fryer is a two part process.

First the tank must be lled with the correct amount of oil and be preheated to

the correct temperature. Only when this process is complete should you proceed

to the COOKING stage.

PART 1

1. Fill the Tank with Oil

• On the inside of the oil tank at the back, there are two marks MIN and

MAX. Pour in sucient oil to reach the MAX marks. Do not overll.

• The maximum capacity of the tank is 1.8 litres. There should always be suf-

cient oil in the tank to cover the MIN mark.

• Corn oil, sunower oil, ground nut oil and vegetable oil are all suitable for

use with the fryer. If you wish you may use solid vegetable fat but this is

much more dicult to handle. Solid fat should be melted in a separate

pan before transferring it to the tank.

• Lightly smear the viewing window with a little oil. This will prevent it from

getting fogged by condensation and allow you to view the food while it

cooks.

2. Replace the frying basket

Hold the basket as described earlier. Align the groove

in the basket handle over the raised lip at the front of

the fryer and press down to make sure the basket is

rmly seated.

3. Close the lid

Close the lid of the fryer by pressing down at both

sides. This will prevent steam from escaping.

4. Lower the basket into the oil

Pull back the button on the handle to release the

catch and fold the handle down.

5. Plug the fryer into the mains

Plug the fryer into the mains socket and switch on

the power at the mains.

Do not use margarine, butter or olive oil. Do not mix different oils and fats.

OPEN

Safety WarningsOperationCleaning and

Maintenance

Specification Before Use

GB-9

6. Preheat the Oil

Preheating will take 15 minutes.

• Set the correct oil temperature for the food - the frying guide on page

11 will assist you.

• Set the timer to the 15 minute mark. The POWER indicator will light on.

After 15 minutes a bell will ring and the POWER indicator will go o.

PART 2 - Cooking

1. Raise the basket and lock it in the raised

position

2. Open the fryer lid

3. Place the food into the raised basket

Place the food to be cooked (which should be

as dry as possible) in the basket.Always have the

basket in the raised position when lling it with

food. Do not overll the basket.

4. Set the Cooking Timer

Set the time for cooking the food according to

the frying guide on page 12. The POWER

indicator will light on.

5. Close the fryer lid

6. Lower the lled basket into the oil

Lower the lled basket into the oil by slowly

returning the handle to the recessed posi-

tion, as described earlier.

When using for the first time, the fryer may emit a slight odour.

This is harmless and quite normal. The odour will cease after a very

short time.

Do not omit the Preheating process!

Safety Warnings Operation Cleaning and

Maintenance

SpecificationBefore Use

GB-10

Cooking Home-Battered Foods

This alternative method requires extreme care.

• If you place wet batter in the basket prior to cooking, the food may stick. Coat

the food in batter and leave it to drain slightly to remove any excess.

• Ensure the correct cooking temperature has been reached. Set the frying time

but leave the basket in the lowered position.

• Open the lid of the fryer.

Hints on Using your Fryer

• Use a recommended oil - do not mix oils or fats.

• Take into account the type of food when you set the frying temperature. Gener-

ally, precooked foods need a higher cooking temperature than raw foods.

• If you need to add oil, do so between batches. Allow a short time for the oil to

heat up to the right temperature.

• Use the timer to help you cook food for the correct time.

• Ensure there is enough room to open the appliance lid and operate the frying

basket.

• Cook food thoroughly. Remember that food may turn golden brown before it

has cooked through.

• Use the fryer in well ventilated conditions. All food contains moisture which

turns to steam during frying. Most of this steam escapes through the lter in the

lid.

• Do not lean over the fryer when cooking food or when opening the lid.

• Check the progress of the food during cooking by raising the basket using the

handle and view the food through the viewing window.

Table des matières

Autres manuels Matsui Friteuse

Matsui

Matsui MDF100E Manuel utilisateur

Manuels Friteuse populaires d'autres marques

Innsky

Innsky 55SA1US Manuel utilisateur

Falcon

Falcon G350/11 Guide de l'utilisateur

GoWISE USA

GoWISE USA GW22612 Manuel utilisateur

Wolf

Wolf IF15/S Manuel utilisateur

Electrolux

Electrolux Thermetic 9CHG583284 Guide rapide

Gourmia

Gourmia GAF799 Manuel utilisateur

DeLonghi

DeLonghi D677UX Manuel utilisateur

SEVERIN

SEVERIN DEEP FRYER - Guide de l'utilisateur

Toastmaster

Toastmaster TMFG18-NAT Manuel utilisateur

Domo

Domo DO465FR Manuel utilisateur

Henny Penny

Henny Penny PFG-691 Manuel utilisateur

Farberware

Farberware FBW FT 43721 B Manuel utilisateur

GERMANICA

GERMANICA GEAF5L3LD Manuel utilisateur

Roller Grill

Roller Grill MF 120 R Manuel d'utilisation

Philips

Philips HD9211 Manuel utilisateur

Linea 2000

Linea 2000 Domo DO536FR Manuel utilisateur

Lakeland

Lakeland 31796 Manuel utilisateur

Dash

Dash Tasti-Crisp DFAF755 Manuel utilisateur
